Opening the scanner
cover
A-61550 February 2010

Opening the scanner cover............................................................. 5-1

Cleaning procedures....................................................................... 5-2
Cleaning the rollers and transport .............................................. 5-3
Cleaning the separator module .................................................. 5-4
Cleaning the feed module .......................................................... 5-5
Cleaning the imaging guides ...................................................... 5-7
Running a transport cleaning sheet............................................ 5-7
Replacement procedures ............................................................... 5-8
Replacing the feed module and feed module tires ..................... 5-9
Replacing the separator module and separator module tires.....511
Replacing the pre-separation pad ............................................ 5-13
Replacing the imaging guides................................................... 5-14
Supplies and consumables .......................................................... 5-17
1. Power down the scanner.
2. Remove any documents from the feeder area.
3. Push up on the scanner cover release latch and open the scanner
cover.
4. When finished cleaning the scanner or replacing a part, close the
scanner cover with both hands; push it down firmly until it latches
into place.
