A-61550
7J3795
i1400 Series Scanners
User's Guide on Installation CD
Guides de l'utilisateur sur le CD d'installation
Benutzerhandbücher auf der Installations-CD
Guida dell'utente sul CD di installazione
Guías de usuario incluidas en el CD de instalación
Guias do usuário no CD de instalação
Gebruikershandleidingen op installatie-cd
Kurulum CD'sindeki Kullanım Kılavuzları
Uživatelská pøíruèka na instalaèním disku CD
User's Guide
Maintenance

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i1400 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Kodak i1400 Series

Summary of Contents for Kodak i1400 Series

  • Page 1 Series Scanners User’s Guide Maintenance User’s Guide on Installation CD Guides de l'utilisateur sur le CD d'installation Benutzerhandbücher auf der Installations-CD Guida dell’utente sul CD di installazione Guías de usuario incluidas en el CD de instalación Guias do usuário no CD de instalação Gebruikershandleidingen op installatie-cd Kurulum CD'sindeki Kullanım Kılavuzları...

  • Page 2: Table Of Contents

    5 Maintenance Contents Opening the scanner cover............. 5-1 Cleaning procedures............... 5-2 Cleaning the rollers and transport ..........5-3 Cleaning the separator module ..........5-4 Cleaning the feed module ............5-5 Cleaning the imaging guides ............5-7 Running a transport cleaning sheet..........5-7 Replacement procedures ...............

  • Page 3: Cleaning Procedures

    Wash your hands with soap and water after performing maintenance procedures. Refer to the Material Data Safety Sheet (MSDS) for more information. The MSDS is available on the Kodak web site at www.kodak.com/go/MSDS. • The roller cleaning pad contains sodium lauryl ether sulfate and sodium silicate which can cause eye irritation.

  • Page 4: Cleaning The Rollers And Transport

    Cleaning the rollers and 1. Manually rotate and wipe the rollers with a roller cleaning pad. transport 2. Clean any dust or debris in the slots around the drive rollers. 3. Wipe the upper and lower transport areas with a roller cleaning pad. 4.

  • Page 5: Cleaning The Separator Module

    Cleaning the 1. Push up on the scanner cover release latch and open the scanner separator module cover. 2. Lift the separator module up and out of position. 3. Manually rotate and wipe the separator module tires with a roller cleaning pad.

  • Page 6: Cleaning The Feed Module

    Cleaning the feed module 1. Push against the raised edge on the left side of the front drive roller cover and pull the cover up and out to remove it. NOTE: You may need to lift the input tray slightly to remove the front roller cover.
  • Page 7 3. Manually rotate and wipe the feed module tires with a roller cleaning pad. 4. Inspect the feed module. If the feed module tires show signs of wear or damage, replace the tires or the feed module. See the section entitled, “Replacing the feed module and feed module tires”...

  • Page 8: Cleaning The Imaging Guides

    Cleaning the Clean the exposed (top side) surfaces of the imaging guides. You do imaging guides not need to remove the imaging guides for cleaning unless there is dust or dirt on the underside of the imaging guide. If you need to remove the imaging guides, follow the instructions for “Replacing the imaging guides”...

  • Page 9: Replacement Procedures

    • Imaging Guides: replace when guides are scratched or damaged NOTES: • Kodak Scanners use replaceable tires that can feed a wide range of document types, sizes and thicknesses. Tire life and performance will vary based on the customer’s document set, the frequency of cleaning the transport and tires, and following the recommended schedule for changing tires.

  • Page 10: Replacing The Feed Module And Feed Module Tires

    Replacing the feed module 1. Push up on the scanner cover release latch and open the scanner and feed module tires cover. 2. Push against the raised edge on the left side of the front drive roller cover to the side and pull the cover up and out to remove it. NOTE: You may need to lift the input tray slightly to remove the front roller cover.
  • Page 11 5. Lift and remove each core assembly and slide the tires off of the core. 6. Install each new tire by gently stretching it over the core. IMPORTANT: • Do not overstretch the tire; it may tear. • Make sure that the tire is centered on the core and lies flat. 7.

  • Page 12: Replacing The Separator Module And Separator Module Tires

    Replacing the 1. Push up on the scanner cover release latch and open the scanner separator module and cover. separator module tires 2. Lift the separator module up and out of position. 3. If you are just replacing the separator module, insert the new separator module by aligning the shaft ends and snapping it into position.
  • Page 13 4. Holding onto the separator module, rotate the release lever back so you can access the separator roller and remove the separator roller. NOTE: Use caution as the separator module is spring-loaded and will snap back if you do not hold it in place. 5.

  • Page 14: Replacing The Pre-Separation Pad

    Replacing the pre- 1. Remove the separator module as previously directed. separation pad 2. Locate the pre-separation pad on the separator module. 3. Hold the separator module in both hands and find the two pre- separation pad side tabs which protrude slightly from the back of the separator module.

  • Page 15: Replacing The Imaging Guides

    Replacing the imaging Replacing the upper imaging guide guides (for i1405, i1420 and i1440 Scanners only) 1. Open the scanner cover and locate the door on the right side of the scanner. Removing the side door will allow you to insert a screwdriver through the door opening to access the upper imaging guide.
  • Page 16 4. Pull gently on the end of the imaging guide and slowly remove it from the scanner. 5. Discard the used imaging guide. 6. Remove any dust or debris from the guide track. Do not allow debris to fall into the scanner. 7.
  • Page 17 Replacing the lower imaging guide (for all scanner models) 1. Locate the lower imaging guide. 2. Using a Phillips Head screwdriver, loosen the screw from the lower imaging guide. 3. Slide the imaging guide out of the bracket and remove it from the scanner.

  • Page 18: Supplies And Consumables

    Supplies and Contact your scanner supplier to order supplies. consumables Supplies/Consumables CAT No. Kodak Feeder Consumables Kit for i1400 Series Scanners 124 1066 Kodak Extra-Large Feeder Consumables Kit for 821 5808 i1400 Series Scanners Kodak Imaging Guide Set for i1400 Series Scanners...

  • Page 19: Troubleshooting

    Technical Support. Use the chart below as a guide to check possible solutions to problems you may encounter when using the Kodak i1400 Series Scanner. Problem Possible Solution Documents are jamming or multiple...
  • Page 20 The lamps shut off too soon The lamps in the i1400 Series Scanners will turn off after 15 minutes of no scanner activity. If the lamps are off, but the scanner has not yet gone into the Energy Star mode (default 15 minutes), there will be a delay of about 10 seconds for the lamps to warm up again.

  • Page 21: Indicator Lights And Error Codes

    Problem Possible Solution Documents are multifeeding Make sure that: • the leading edges of all batched documents are centered in the feeder so that each document will come in contact with the feed rollers. • the feed module and separator module are clean and not worn. •...
