Tip!
If the linking pins are difficult to remove, loosen the four link plate nuts and bolts for
that module. Don't forget to re-tighten them after you have positioned the link pins
Loosen the Link Plate Nuts and bolts if necessary
4) Angle the Omniline® modules to the required splay angle lining up the link
plate holes at the required angle positions marked on the bracket
Link plates holes lined up for 5deg splay
