2)
Press the screws into the front of the polystyrene tray to avoid loosing
them.
5.2
Splay angle adjustment
Omniline® modules are shipped with splay angles set at 0 degrees. Having
determined splay angles and mounting or suspension attachment points using the
Omniline® software, set the required inter-module splay angles as follows:
Tip!
Leave modules that require wall mounting or suspension attachments (see software
recommendations) until last as these brackets need to be orientated and fitted before
nearby link pins are inserted – see later...
1) Remove the rear cover
2) Remove the orange safety clip
3) Remove the linking pins from the splay angle holes
All material © 2009. Martin Audio Ltd. Subject to change without notice.
9
