Powering your
OmniLine
®
(For general system preparation, see the OmniLine
system preparation - preliminary guidance)
The Martin Experience
All material © 2008. Martin Audio Ltd. Subject to change without notice.

Advertisement

loading

Related Manuals for Martin Audio OmniLine Portable Speaker

Summary of Contents for Martin Audio OmniLine Portable Speaker

  • Page 1 Powering your OmniLine ® (For general system preparation, see the OmniLine system preparation - preliminary guidance) The Martin Experience All material © 2008. Martin Audio Ltd. Subject to change without notice.
  • Page 2 The Connector pcb also provides an input termination. This allows the installer to build an array of appropriate length (we recommend 6% of each plane to be covered for good spectral balance) with electrical characteristics best suited to the Martin Audio power amplifier chosen.
  • Page 3 (This chart is repeated full-size on the next page for easy reference) ClipLim settings Martin Audio loudspeakers are AES power rated. AES ratings allow for up to 6dB voltage (4 x power) instantaneous peaks. We therefore recommend that you set your DX1.5 or DX2 output channel ClipLims to +6dB.
  • Page 5 OmniLine array patches Single OmniLine modules are 16 ohm elements. Four modules are supplied in each carton. These four modules are connected in parallel to form a standard 4 ohm block but may be reconfigured, paralleled or series connected to provide a wide variety of series/parallel configurations chosen from the preceding chart.
  • Page 6 6 module array (2.67 ohms) 6 module array (10.67 ohms)
  • Page 7 8 module array (8 ohms) 12 module array (5.3 ohms)
  • Page 8 16 module array (4 ohms)
  • Page 9 24 module array (2.67 ohms)
  • Page 10 Two channel configurations 6 module array (5.34 ohms per channel) 8 module array (4 ohms per channel)
  • Page 11 12 module array (2.67 ohms per channel)
  • Page 12 16 module array (8 ohms per channel)
  • Page 13 24 module array (5.3 ohms per channel)
  • Page 14 Four channel configurations 16 module array (4 ohms per channel)
  • Page 15 24 module array (2.67 ohms per channel)
