  • Page 1 OmniLine ® System Preparation The Martin Experience All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 2 Every Omniline® loudspeaker must be fitted with a steel safety wire this can be fitted between an attachment bracket (provided) and a suitable supporting structure. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 3 Attaching Dog Grip Flying Bracket Allen Key/Socket Set Adding brackets to the array Allen Key/Socket Set Adding brackets to the array PZ = Pozidrive S = Straight/Flat head All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 4 5 years from the date of original purchase. During the warranty period Martin Audio will, at its discretion, either repair or replace products which prove to be defective provided that the product is returned in its original packaging, shipping prepaid, to an authorised Martin Audio service agent or distributor.
  • Page 5 There are three methods of installing an Omniline® Loudspeaker system. Choose the position and number of Omniline® modules required as indicated by the Omniline® software. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 6 4 x OmniLine® wall mounting kit Each 4 x OmniLine® wall mounting kit comprises the following parts: 4 x OmniLine® wall mounting kit All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 7 8-16 x OmniLine® wall mounting kit Each 8-16 x OmniLine® wall mounting kit comprises the following parts: 8-16 x OmniLine® wall mounting kit All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 8 We suggest that you retain the original packaging so that the system can be repacked at a future date if necessary. Please note that Martin Audio and its distributors cannot accept any responsibility for damage to any returned product through the use of non-approved packaging.
  • Page 9 If you are not using a magnetic screwdriver, we recommend covering the rear port holes with some tape as shown above to prevent dropping screws down the ports! All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 10 – see later… 1) Remove the rear cover 2) Remove the orange safety clip 3) Remove the linking pins from the splay angle holes All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 11 Remove the Orange Safety clip Remove the link Pins All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 12 4) Angle the Omniline® modules to the required splay angle lining up the link plate holes at the required angle positions marked on the bracket Link plates holes lined up for 5deg splay All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 13 5) Insert the four linking pins into the aligned link plate holes. 6) Replace the orange safety clip after positioning all four linking pins… Replace the orange safety clips! System wiring See separate document entitled Powering your Omniline®. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 14 Its final orientation will be determined by the required linking pin positions – one way round for 0-2 degrees, the other way round for 3-5 degrees. U-bracket (shown positioned for 4 degree linking pin position) All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 15 2) Fit the FAA08005 M8 x 60mm bolt (see kit identification pictures earlier) loosely to the collar as shown above Wire up the array. See separate document entitled Powering your Omniline®. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 16 Recheck everything! ALLWAYS double check that all Orange safety clips are in place as this is essential to ensure that the array will stay safely locked together All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 17 Fit link plates (supplied with each four modules) to the bottom of each block of four Fit 4-module blocks together by interlocking modules together near the front. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 18 Ensure that the tongues (right) are properly locked into the grooves (left) – see arrows in above illustration… Adding the linking pins Add the linking pins as shown in section 5.2 earlier. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 19 White = -ve and Orange = +ve Upper and lower block connections are marked on the pcb. Route the wires between the linking pins to avoid crushing them when the rear covers are replaced. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 20 Final U-bracket positioning will be determined by the required linking pin positions – one position for 0-2 degrees and the other position for 3-5 degrees. See illustration below… All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 21 – see section 5.2 earlier. U-bracket positioned for 5 deg lower module angle Fit a main HAM03192 tie-bracket to the Omniline® module indicated by the Omniline® software. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 22 Leave the U-bracket screw (right above) and clamping screw (left above) finger tight until the system is mounted onto the wall bracket – remembering to tighten them fully at that stage. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 23 Attach the Wire Rope assembly to the main tie bracket using the pin and R-clip. Note the R-clip washer. Roughly adjust the length of the wire using the wedge socket. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 24 HAM02026 The Omniline® software will indicate the recommended heights of these brackets. Lift the array and slot it down onto the bottom bracket Tighten the clamp screw (arrowed). All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 25 Recheck everything! ALLWAYS double check that all Orange safety clips are in place as this is essential to ensure that the array will stay safely locked together All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 26 OmniLine® modules – see kit picture at the beginning of this document. Fit link plates (supplied with each four modules) to the bottom of each block of four All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 27 Fit 4-module blocks together by interlocking modules together near the front. Interlock modules together Ensure that the tongues (right) are properly locked into the grooves (left) – see arrows in above illustration… Adding the linking pins All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 28 Wire the 4-module blocks together into bigger blocks of 8 or 12 modules* using the connector pcb supplied with each block of four OmniLine® modules. * See separate document entitled Powering your Omniline® for further details. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 29 Screw the pcb to the inside of the most convenient rear cover using the self tap screws provided with each set of four modules. Its orientation will depend on that module’s linking pin positions. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 30 The position and orientation of the bracket will be determined by the angle setting of the Omniline® module to which it is fitted. Attach the bracket – temporarily removing the linking pins if necessary. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 31 Fit the second HAM03192 tie-bracket to the Omniline® module indicated by the Omniline® software. Again, the bracket position and orientation will be determined by the angle setting required for that Omniline® module. All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 32 If you are inexperienced, or in any doubt at all, get an independent safety check. ALLWAYS double check that all Orange safety clips are in place as this is essential to ensure that the array will stay safely locked together All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 33 Omniline bracket which are normally used to attach the linking plates. It uses the same nuts and bolts as the linking plates, you will All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 34 Remove the covers and the orange safety clips from the bottom two modules as this will make it much easier to fit the Allen key into the bolts to tighten them up All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 35 Fit the spare linking plate nuts and bolts starting with the lowest two and tighten with a 4mm Allen Key and a 10mm open ended spanner Tighten the fixing nuts and bolts All material © 2009. Martin Audio Ltd. Subject to change without notice.
  • Page 36 If you are inexperienced, or in any doubt at all, get an independent safety check. ALLWAYS double check that all Orange safety clips are in place as this is essential to ensure that the array will stay safely locked together All material © 2009. Martin Audio Ltd. Subject to change without notice.
