Martin Audio Blackline S15+ Technical Specifications

Blackline S15
Compact, vented sub-bass system
features
Q
Compact vented sub-bass
Q
Direct radiating 15" (380mm) driver
Q
High temperature 4" (100mm) voice coil
Q Top hat fitting for pole mounting F12 + /F15 +
Q
Five year limited warranty
applications
Q
Club sound reinforcement
Q
Theatre sub-bass
Q
AV presentations
The compact Blackline S15 + sub-bass system has been
designed to be used with Blackline F12 + or F15 + full-
range systems to extend and increase the total low
frequency output power. The S15 + provides good bass
punch from a new, long-excursion, 15" (380mm)/4"
(100mm) voice coil driver with a water resistant cone
and triple roll surround.
The S15 + is provided with a top hat fitting that can be
used to pole mount an F10 + or F12 + above the
enclosure.

overall dimensions

+

technical specifications

TYPE
FREQUENCY RESPONSE (1) 45Hz-120Hz ± 3dB
DRIVERS
RATED POWER (2)
RECOMMENDED AMPLIFIER 600W-1500W into 4 ohms
SENSITIVITY (3)
MAXIMUM SPL (4)
NOMINAL IMPEDANCE
DISPERSION (-6dB)
CROSSOVER
ENCLOSURE
FINISH
PROTECTIVE GRILLE
CONNECTORS
PIN CONNECTIONS
FITTINGS
DIMENSIONS
WEIGHT
Century Point, Halifax Road, Cressex Business Park,
High Wycombe, Buckinghamshire HP12 3SL, England.
Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669
E-mail: info@martin-audio.com
All information is Copyright © 2007 Martin Audio Ltd.
www.martin-audio.com
Compact, vented sub-bass system
-10dB @ 40Hz
15" (380mm)/4" (100mm) voice coil LF driver
750W AES, 3000W peak
101dB (half space)
129.5dB continuous, 135.5dB peak (half space)
8 ohms
120Hz active/passive low pass filter
100 litre, multi-laminate birch ply
Textured black paint
Black perforated steel
2 x Neutrik NL4
LF+,- : 1+,1- , Link thro': 2+,2-
1 x mounting pole socket
2 x pocket handles
(W) 470mm x (H) 690mm x (D) 496mm
(W) 18.5ins x (H) 27.2ins x (D) 19.5ins
38.5kg (84.5lbs)
