MPX R1 Version 2 User Guide
Installation Notes
Power Requirements
Connecting the MPX R1
to an MPX 1 or an
MPX G2
Stand-alone
Configuration
1-4
Use Lexicon MSA power adapter, or 9 VAC 1 amp equivalent.
to AC Power
Source
to Lexicon
MSA Adapter
Connect a 7-pin DIN cable between the MPX (1 or G2) and the MPX R1.
Connect the MPX (1 or G2) to the MSA adapter provided with the MPX R1.
to Lexicon
MSA Adapter
5-pin DIN Cable
MIDI Device 1
MIDI Device 2
Relay
(Amp Channel Select)
7-pin DIN
Foot
Cable
Switch
Relay
(Amp Channel Select)
OUT
IN
THRU
5-pin DIN Cable
IN
Lexicon
Foot Pedal
Foot Pedal
Foot
Switch
