Specifications

8
Specifications
Dimensions: 23 in x 8 in x 3 in (WHD) (58.42 cm x 20.32 cm x 7.62 cm)
Weight: 9.5 lbs (4.3 kg)
Construction: All metal chassis, switches and expression pedal
External control inputs: 1 1/4" TRS jack supports up to 3 on/off switches
1 1/4" TRS jack for external expression pedal
Internal relays: 1 1/4" TRS jack connected to two internal programmable relays
MIDI: MIDI OUT/REMOTE: 7-pin DIN connector (compatible with standard 5-pin MIDI)
provides phantom power and two-way MIDI communication with the MPX 1 or
MPX G2
MIDI IN: standard MIDI IN can also be used to merge a second MIDI input stream
when MIDI OUT/REMOTE is connected
MIDI THRU: can be set to pass MIDI from either MIDI IN or REMOTE ports
Power: 9VAC, 1A wall transformer provided
25-foot 7-pin DIN cable for phantom power via MPX 1 or MPX G2
Expression pedal: vintage mechanical design, all steel construction, progammable toe switch
Display: 3-digit LED indicates program number and tempo rate
MIDI functions: MIDI bank and program select for up to 300 programs
Switches and pedal(s) can be individually set to transmit any controller. The status
of each MIDI switch is indicated with a green LED.
Tap tempo can be transmitted as MIDI Clock
Relay mapping: Different relay states can be memorized for each of 990 MIDI program numbers
Relays can operate as on/off 1–4 or as two independent on/off switches
MPX 1/MPX G2 functions*: When connected to an MPX 1 or MPX G2 via 7-pin cable, R1 LEDs automatically
display the following each time a new program is loaded:
Program number
Master Bypass state
A/B state
Tempo rate
State of each effect block (Pitch, Chorus, EQ, Mod, Delay, Reverb); effect
on=green, effect bypassed=red, effect not active=off)
The state of any active effect can be instantly changed by pressing its associated
switch
Dedicated switches for control of A/B and Tap.
* MPX 1 requires V1.1 ROM upgrade
8-1
