Lexicon MRC V4.0 Owner's Manual Addendum

Lexicon MRC V4.0 Owner's Manual Addendum

Midi remote controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual
Addendum
MRC V4.0
MIDI
Remote
Controller

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MRC V4.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Lexicon MRC V4.0

Summary of Contents for Lexicon MRC V4.0

  • Page 1 Owner's Manual Addendum MRC V4.0 MIDI Remote Controller...
  • Page 2 Lexicon Inc. 3 Oak Park Copyright ©1992 Bedford, MA USA All Rights Reserved. Telephone 781-280-0300 Fax 781-280-0490 Lexicon Part #070-09430...

  • Page 3: Table Of Contents

    Table of Contents Control Flow ......3-11 1. Introducing Version 4.0 LXP-15 Setups ..... 3-12 V. 4.0 Features ...... 1-1 Selecting an LXP-15 V. 4.0 Changes ...... 1-1 Setup ......3-12 Communication Problems 3-13 2. Controlling the LXP series of Viewing and Editing LXP-15 multi-effects processors Setup Parameters ..
  • Page 4 Using the and ENTER Keys ........ 4-9 Storing Setups from Machine Run Mode ..4-9 MRC/LXP-5 Presets ..4-10 5. Controlling the LXP-1 with Two-Way Communication Two-way Connections ... 5-1 Merging and Two-way Communication ....5-1 Establishing Two-way Communication ....5-3 Two-way Control of Multiple LXP-1s ....

  • Page 5: Introducing Version

    Introducing Version 4.0 1. Introducing Version 4.0 Congratulations on your purchase of the MRC V4.0 MIDI Remote Controller. Version 4.0 adds some significant new features and changes to Version 3.0 of the MRC. These changes and features are based on feedback from present MRC users.This addendum is not a replacement of the Version 3.0...
  • Page 6 Lexicon MRC V4.0/ MIDI Remote Controller The following table shows the new internal memory configuration of Version 4.0 . MRC Setup Type Internal Memories LXP-1 setups LXP-5 setups LXP-15 setups GMIDI setups Global setups...

  • Page 7: Controlling The Lxp Series Of

    Multi-Effects Processors One of the most powerful features of the MRC is its ability to be used as a dedicated controller for Lexicon’s LXP-1, LXP-5 and LXP-15 multi-effects processors. For maximum flexibility with your setup, the MRC can control LXP devices using either one-way or two-way MIDI communication. This section presents the general issues of MRC/LXP control and communica- tion.

  • Page 8: One-Way And Two-Way Communications

    Lexicon MRC V4.0/ MIDI Remote Controller The MRC has several advantages as a dedicated remote controller for Lexicon’s LXP-1, LXP-5, and LXP-15 multi-effects processors. Here are some of the possibilities: • Simultaneous editing and display of as many as four parameters •...
  • Page 9 Owner's Manual Addendum Controlling the LXP Series of Multi-Effects Processors Two-way communication is used for more sophisticated applications. For instance, in order for a sequencer to record and playback MIDI data from a single synthesizer, they must be set up for two-way communication. Two cables are required.
  • Page 10 Lexicon MRC V4.0/ MIDI Remote Controller It is important to note that two-way communication creates a closed-loop between the two MIDI devices. Unlike a one-way configuration, it is not a simple matter to connect additional devices to a two-way configuration. This is because MIDI outputs cannot be combined on a single cable without a MIDI merger .

  • Page 11: Overview Of One-Way Features

    Owner's Manual Addendum Controlling the LXP Series of Multi-Effects Processors Overview of One-way Features Additional LXPs or MIDI devices THRU LXP-15 (Tempo Control) Sequencer, Keyboards, etc. LXP-5 MIDI Clock Foot Pedal #1 Foot Pedal #2 • Simplified MIDI set up •...

  • Page 12: Overview Of Two-Way Features

    Lexicon MRC V4.0/ MIDI Remote Controller • LXPs connected for one-way communication can be controlled simulta- neously by MIDI messages received at either IN port, as well as from the MRC’s sliders, switches and external controllers. Overview of Two-way Features...

  • Page 13: Advanced Two-Way Configurations

    Owner's Manual Addendum Controlling the LXP Series of Multi-Effects Processors Advanced Two-way Configurations Computer MIDI Clock Patcher Merge THRU Keyboard Additional MIDI devices LXP-15 LXP-5 LXP-1 Merge Two-way communication requires a separate pair of MIDI IN/OUT ports for each LXP being controlled. The MRC has two sets of MIDI IN/OUT ports, so you can control two LXPs in two-way at once using two-way communication.

  • Page 14: Controlling The Lxp-15

    Owner's Manual Addendum Controlling the LXP-15 3. Controlling the LXP-15 The MRC can be used as a dedicated remote controller for the LXP-15. All of the LXP-15 parameters are accessible via the MRC. In addition to being a full-featured editor, the MRC also extends the programmability of the LXP- 15 by allowing you to create as many as four additional Dynamic MIDI patches for each LXP-15 sound via the MRC’s Machine Edit Mode.

  • Page 15: Merging And One-Way Communication

    Lexicon MRC V4.0/ MIDI Remote Controller Merging and One-way Communication to merge MIDI Clock and controllers to merge controllers only LXP-15 When connected for one-way communication, you can use the merging features of the MRC to route MIDI controllers from either MIDI input to the LXP-15.

  • Page 16: Establishing One-Way Communication

    Owner's Manual Addendum Controlling the LXP-15 Merging Options for One-way Communication IN1 -> OUT1 <ON/OFF> When set to “ON”, all incoming MIDI received on IN1 is merged with MRC OUT1. Use this to merge MIDI Clock with MRC output for Tempo patching on the LXP-15.
  • Page 17 Lexicon MRC V4.0/ MIDI Remote Controller 4. Confirm that the LXP-15 is set to receive on the same MIDI channel as the displayed “CH#”. 5. Press ENTER to put the MRC into Machine Run Mode. The MRC display will change to show the first page of LXP-15 Setup parameters.

  • Page 18: One-Way Control Of Multiple Lxp-15S

    Additional LXPs or MIDI devices Using one-way communication, you can control as many as sixteen Lexicon devices at once by defining a separate machine for each device. Multiple LXP-15 control is very easy to set up since the LXP-15 MIDI THRU port can be used to “daisy chain”...

  • Page 19: Two-Way Connections

    Lexicon MRC V4.0/ MIDI Remote Controller Two-way Connections Two way communication allows you to access and view parameters stored in the LXP-15’s 128 internal registers. You can connect one or two LXP-15s to the MRC for two-way communication. Two MIDI cables are required for each LXP-15.
  • Page 20 Owner's Manual Addendum Controlling the LXP-15 MIDI data from the input port which is not connected to the LXP-15 can be merged with the data at the output port used for two-way communication. This is useful when you are using an LXP-15 register that uses MIDI sources for patching.

  • Page 21: Establishing Two-Way Communication

    Lexicon MRC V4.0/ MIDI Remote Controller Establishing Two-way Communication When configured for two-way communication, the MRC requests parameter data from the LXP-15 and displays it for editing. The edited values are sent back to the LXP-15. This back and forth communication, or hand shaking , occurs automatically once communication is established between the two units.
  • Page 22 Owner's Manual Addendum Controlling the LXP-15 6. Confirm that the LXP-15 is set to receive on the same MIDI channel as the displayed “CH#”. 7. Press ENTER to put the MRC into Machine Run Mode. The MRC display will change to show the first page of LXP-15 Setup parameters. 8*.

  • Page 23: Two-Way Control Of Multiple Lxp-15S

    Lexicon MRC V4.0/ MIDI Remote Controller Two-way Control of Multiple LXP-15s Other MIDI devices THRU Other MIDI LXP-15 devices THRU can be patched to LXP-15 LXP machines controlling both LXP-15s Using two-way communication you can control two LXP-15s, one for each input/output pair.

  • Page 24: Control Flow

    Owner's Manual Addendum Controlling the LXP-15 Control Flow In this diagram, MIDI data from the sequencer and pedal moves from EXT2 (set to NORMAL) can be sent to other MIDI devices via the THRU port of the LXP-15. controlled by MRC sliders when LXP-15 Mach is displayed;...

  • Page 25: Lxp-15 Setups

    Lexicon MRC V4.0/ MIDI Remote Controller LXP-15 Setups LXP-15 machine types have a bank of sixteen user-programmable memo- ries. Each of these memories stores a complete set of LXP-15 parameters and is referred to in the MRC as an Internal Setup. When connected for two- way communication, you can also upload the parameters from any of the 128 user registers in the LXP-15.

  • Page 26: Communication Problems

    Owner's Manual Addendum Controlling the LXP-15 4. Press SETUP to enter Setup Select Mode. 5. Use the leftmost slider, the SETUP button, or the keypad to select the desired setup. Pressing on the keypad switches the display between “SETUP#” and “EXTRN#”.

  • Page 27: Using The And Enter Keys

    Lexicon MRC V4.0/ MIDI Remote Controller Using the and ENTER Keys While in Machine Run Mode, the key transmits the current values of all parameters to the LXP-15. Use it to reset the LXP-15 to the values displayed by the MRC. (You would do this, for example, if LXP-15 parameters are inadvertently changed from its front panel.) If you are using two-way...
  • Page 28 Owner's Manual Addendum Controlling the LXP-15 Page 5 DECAY SIZE DIFFUS RMIX Decay Size Diffus Rvb Mix .6-6.1s, 8M-71M 0-100% 0-100% Infinite Page 6 INLVL WPAN DPAN OUTLVL InLevl Wet Pan Dry Pan OutLevl 0-100% 100%L-51%L, 100%R-51%R, 0-100% Center, Center, 51%R-100%R 51%R-100%R Pitch/Delay...
  • Page 29 Lexicon MRC V4.0/ MIDI Remote Controller Gate Page 1 PDELY FINE FDBK Predely PdlyFbk 0-100% 0-262ms -99% to +99%% Page 2 LFO Rat .03Hz-4.84Hz Page 3 PITCH N/A THIS ALGO Page 4 TREBLE SLOPE Treble Slope 320Hz-11.6kHz, 0-127 Full Page 5...
  • Page 30 Owner's Manual Addendum Controlling the LXP-15 Full Page 5 DECAY SIZE DIFFUS Decay Size Diffus .6-6.1s 8M-87M 0-100% Page 6 INLVL WPAN DPAN OUTLVL InLevl Wet Pan Dry Pan OutLevl 0-100% 100%L-51%L, 100%R-51%R, 0-100% Center, Center, 51%R-100%R 51%R-100%R Chorus Delay Page 1 DELY1 DELY2...

  • Page 31: Mrc/Lxp-15 Presets

    Lexicon MRC V4.0/ MIDI Remote Controller MRC/LXP-15 Presets When shipped from the factory, MRC Version 4.0 has 10 setups loaded into its internal memory. Six additional memory spaces are left blank. You may want to use these setups as is, or modify them to your own taste. Be aware that changes you make will overwrite the factory-loaded setups when you perform a store operation.
  • Page 32 Owner's Manual Addendum Controlling the LXP-15 #6 Eko Roll This multi-effects preset combines 60ms and 90ms of delay to the left and right outputs. The pitch shifter is lowered slightly to create a chorusing effect. The reverb is mixed 50/50 with the delay section. It has a small/tight character, but with a 30ms pre-delay for additional space separation from the source.

  • Page 33: Storing Setups From Machine Run Mode

    Lexicon MRC V4.0/ MIDI Remote Controller Storing Setups from Machine Run Mode You can store a setup in any one of the MRC’s sixteen internal setups, or in any one of the LXP-15’s 128 user registers. Here’s how: 1. On the MRC, press STORE to enter Setup Store Mode.
  • Page 34 Owner's Manual Addendum Controlling the LXP-15 3. Transmit the changes to the LXP-15, but don’t store them. Option 1 is available to you at any time while in etup Edit Mode. Simply press MACH to cancel any changes and return to Machine Run Mode. The other options are accessed by pressing either STORE or ENTER.
  • Page 35 Lexicon MRC V4.0/ MIDI Remote Controller Viewing and Editing Setup Edit Parameters Setup Edit parameters are accessed by repeatedly pressing PAGE to scroll through different sets of parameters. (Pressing and holding PAGE will show the number of the page about to be displayed.) The function of each display...
  • Page 36 Owner's Manual Addendum Controlling the LXP-15 Editing LXP-15 Dynamic MIDI Patches SRC1 THRS1 DEST1 SCAL1 INLVL RATE 100% • Use slider/switch 1 to select a patch source. (See LXP-15 Source Table next page.) • Use slider/switch 2 to set the threshold. •...
  • Page 37 Lexicon MRC V4.0/ MIDI Remote Controller LXP-15 Patch Sources MRC Display LXP-15 Display Description INLVL InLevl Internal controller FOOT5 Foot 5 rear-panel analog controller FOOT4 Foot 4 rear-panel analog controller FOOT3 Foot 3 rear-panel analog controller FOOT2 Foot 2 rear-panel analog controller...
  • Page 38 Owner's Manual Addendum Controlling the LXP-15 LXP-15 Patch Destinations MRC Display LXP-15 Display Dly/Rvb Pch/Dly Gate Plate Cho Dly Algthm (global patches only) DLY1-F Glidely Predely Predely Predely Delay 1 DLY1-C Gldyhi Pdlyhi PredlyHi PredlyHi FDBK1 Gldfbk PdlyFdbk PdlyFdbk PdlyFdbk Feedback 3 DLY2-F Delay 2...
  • Page 39 Lexicon MRC V4.0/ MIDI Remote Controller Editing the Setup Name LXP-15 SETUP ChorsEko ChorsEko LXP-15 SETUP Use the sliders and switches on these two display pages to change the setup name. Each slider/switch selects one of the eight characters in the name.

  • Page 40: Controlling The Lxp-5 With

    Controlling the LXP-5 with Two-Way Communication Owner's Manual Addendum 4. Controlling the LXP-5 with Two-Way Communication Two-way Connections Two way communication allows you to access and view parameters stored in the LXP-5’s 128 internal registers. You can connect one or two LXP-5s to the MRC for two-way communication.
  • Page 41 Lexicon MRC V4.0/ MIDI Remote Controller MIDI data from the input port which is not connected to the LXP-5 can be merged with the data at the output port used for two-way communication. This is useful when you are using an LXP-5 register that uses MIDI sources for patching.

  • Page 42: Establishing Two-Way Communication

    Controlling the LXP-5 with Two-Way Communication Owner's Manual Addendum Establishing Two-way communication When configured for two-way communication, the MRC requests parameter data from the LXP-5 and displays it for editing. The edited values are sent back to the LXP-5. This back and forth communication, or hand shaking , occurs automatically once communication is established between the two units.
  • Page 43 Lexicon MRC V4.0/ MIDI Remote Controller 7. Confirm that the LXP-5 and MRC are set to the same MIDI channel by pressing the LEARN button on the LXP-5 while moving any of the sliders on the MRC. The LED on the LXP-5 will flicker.

  • Page 44: Two-Way Control Of Multiple Lxp-5S

    Controlling the LXP-5 with Two-Way Communication Owner's Manual Addendum Two-way Control of Multiple LXP-5s Other MIDI devices LXP-5 can be patched to LXP-5 LXP machines controlling both LXP-5s Using two-way communication you can control two LXP-5s at once, one for each input/output pair.

  • Page 45: Control Flow

    Lexicon MRC V4.0/ MIDI Remote Controller Control Flow In this diagram, MIDI data from the sequencer and pedal moves from EXT2 (set to NORMAL) can be sent to other MIDI devices via the THRU port of the LXP-15. controlled by MRC sliders when LXP-5 Mach is displayed;...

  • Page 46: Setups

    Controlling the LXP-5 with Two-Way Communication Owner's Manual Addendum LXP-5 Setups LXP-5 machine types have a bank of sixteen user-programmable memo- ries. Each of these memories stores a complete set of LXP-5 parameters and is referred to in the MRC as an Internal Setup. When connected for two- way communication, you can also upload the parameters from any of the 128 user registers in the LXP-5.

  • Page 47: Communication Problems

    Lexicon MRC V4.0/ MIDI Remote Controller 3. Press ENTER to put the MRC into Machine Run Mode. 4. Press SETUP to enter Setup Select Mode. 5. Use the leftmost slider, the SETUP button, or the keypad to select the desired setup.

  • Page 48: Using The And Enter Keys

    Controlling the LXP-5 with Two-Way Communication Owner's Manual Addendum flicker when sliders are moved on the MRC.) Refer to the MRC V3.0 Owner’s Manual for a complete description of how to use the MRC to edit LXP-5 setup parameters. Using the and ENTER Keys While in Machine Run Mode, the key transmits the current values of all...

  • Page 49: Mrc/Lxp-5 Presets

    Lexicon MRC V4.0/ MIDI Remote Controller MRC/LXP-5 Presets When shipped from the factory, MRC Version 4.0 has 10 setups loaded into its internal memory. Six additional memory spaces are left blank. You may want to use these setups as is, or modify them to your own taste. Be aware that changes you make will overwrite the factory-loaded setups when you perform a store operation.
  • Page 50 Controlling the LXP-5 with Two-Way Communication Owner's Manual Addendum #7 On Stage This preset combines an early reflection of 24.5ms with a moderately large space incorporating a 40ms pre-delay. Great for voice or instruments. #8 Chamber This preset is a straight ahead reverb with a slight early reflection set to 24ms.

  • Page 51: Controlling The Lxp-1 With

    Owner's Manual Addendum Controlling the LXP-1 with Two-Way Communication 5. Controlling the LXP-1 with Two-Way Communication Two-way Connections Two way communication allows you to access and view parameters stored in the LXP-1’s 128 internal registers. You can connect one or two LXP-1s to the MRC for two-way communication.
  • Page 52 Lexicon MRC V4.0/ MIDI Remote Controller MIDI data from the input port which is not connected to the LXP-1 can be merged with the data on the output port used for two-way communication. This is useful when you are using an LXP-1 register that uses MIDI sources for patching.

  • Page 53: Establishing Two-Way Communication

    Owner's Manual Addendum Controlling the LXP-1 with Two-Way Communication Establishing Two-way communication When configured for two-way communication, the MRC requests parameter data from the LXP-1 and displays it for editing. The edited values are sent back to the LXP-1. This back and forth communication, or hand shaking , occurs automatically once communication is established between the two units.
  • Page 54 Lexicon MRC V4.0/ MIDI Remote Controller 7. Confirm that the LXP-1 and MRC are set to the same MIDI channel by pressing the MIDI button on the LXP-1 while moving any of the sliders on the MRC. The MIDI LED on the LXP-1 will flicker.

  • Page 55: Two-Way Control Of Multiple Lxp-1S

    Owner's Manual Addendum Controlling the LXP-1 with Two-Way Communication Two-way Control of Multiple LXP-1s Other MIDI devices LXP-1 can be patched to LXP-1 LXP machines controlling both LXP-1s Using two-way communication you can control two LXP-1s at once, one for each input/output pair.

  • Page 56: Control Flow

    Lexicon MRC V4.0/ MIDI Remote Controller Control Flow In this diagram, MIDI data from the sequencer and pedal moves from EXT2 (set to NORMAL) can be sent to other MIDI devices via the THRU port of the LXP-1. controlled by MRC sliders when LXP-1 Mach is displayed;...

  • Page 57: Selecting An Lxp-1 Setup

    Owner's Manual Addendum Controlling the LXP-1 with Two-Way Communication LXP-1 Setups LXP-1 machine types have a bank of sixteen user-programmable memo- ries. Each of these memories stores a complete set of LXP-1 parameters and is referred to in the MRC as an Internal Setup. When connected for two- way communication, you can also upload the parameters from any of the 128 user registers in the LXP-1.

  • Page 58: Communication Problems

    Lexicon MRC V4.0/ MIDI Remote Controller 3. Press ENTER to put the MRC into Machine Run Mode. 4. Press SETUP to enter Setup Select Mode. 5. Use the leftmost slider, the SETUP button, or the keypad to select the desired setup.

  • Page 59: Viewing And Editing Lxp-1 Setup Parameters

    Owner's Manual Addendum Controlling the LXP-1 with Two-Way Communication Viewing and Editing LXP-1 Setup Parameters LXP-1 setup parameters are viewed and edited on two MRC display pages. Pages can be selected by pressing PAGE repeatedly, or by pressing the desired page number on the keypad. To edit LXP-1 parameters from the MRC, simply select the desired page and move the slider of the parameter you want to edit.

  • Page 60: Mrc/Lxp-1 Presets

    Lexicon MRC V4.0/ MIDI Remote Controller MRC/LXP-1 Presets When shipped from the factory, MRC Version 4.0 has 10 setups loaded into its internal memory. Six additional memory spaces are left blank. You may want to use these setups as is, or modify them to your own taste. Be aware that changes you make will overwrite the factory-loaded setups when you perform a store operation.

  • Page 61: Changing Lxp-1 Midi Thru To Midi Out

    Owner's Manual Addendum Controlling the LXP-1 with Two-Way Communication #9 LongChrs Delayed effect with feedback (32%) at HICUT filter (4.88kHz). #10 MultiTap Offbeat stereo bouncing delays with diffusion (100%) on each recirculating pass. Changing LXP-1 MIDI THRU to MIDI OUT Using a Phillips-head screwdriver, remove the 2 screws from either side of the LXP-1 front panel.
  • Page 62 Lexicon Inc. 3 Oak Park Bedford, MA 01730 USA 781-280-0300 Fax 781-280-0490 Lexicon Part No. 070-09430 Printed in USA...
