Protecting Your Registers
Against Another Kind of Loss
After creating a collection of registers, some users may
not wish to let others access their "trademark" sounds.
If this concerns you, copy any internal registers that
you create to a nonvolatile memory cartridge at the end
of each session (using the register transporter in the
control mode). Then use the register clear function
(also found in the control mode) to remove the registers
from internal memory. Take the cartridge with you
when you leave the facility.
Use of the register transporter and register clear func-
tions are described below.
Moving Registers Around
with the Register Transporter
The register transporter has four functions:
• Copy single registers from one location to
another
• Move single registers from one location to
another
• Copy all internal registers to a cartridge
• Copy all cartridge registers to internal memory
When registers are copied, the original register source
remains intact. When registers are moved, the original
register source is cleared.
IMPORTANT
The register protect function found on page
two of the control mode must be set to OFF if
any moves or copies are to overwrite existing
registers.
To copy entire register contents between internal and
cartridge memory:
1. Press CTRL to enter the control mode.
2. Press PAGE, 2 to go to page 2.
3. Use slider one to select CPY CART TO INTER-
NAL or CPY INTERNAL TO CART.
4. Hold down STO and press REG to complete the
copy.
Note: When either of these two modes are
selected, the SRC and DST sliders are inactive.
2-16
To move or copy single registers:
1. Press CTRL to enter the control mode.
2. Press PAGE, 2 to go to page 2.
3. Use slider one to select MOVE or COPY.
4. Use slider two to select the source.
5. Use slider three to select the destination.
6. Hold down STO and press REG to complete the
copy or move.

Clearing Register Contents

Page two of the control mode has a CLEAR control that
allows complete removal of register contents. CLEAR
has three functions:
• Clear a single register
• Clear all internal registers
• Clear all cartridge registers
To clear a single register:
1. Press CTRL to enter the control mode.
2. Press PAGE, 2 to go to page two.
3. Use slider one to select CLR SETUP.
4. Use slider two to select the register that you wish
to clear.
5. Hold down STO and press REG to clear the
selected register.
To clear all cartridge or internal registers:
1. Press CTRL to enter the control mode.
2. Press PAGE, 2 to go to page two.
3. Use slider two to select CLR ALL INT or CLR ALL
CART.
4. Hold down STO and press REG to clear the
selected registers.
Note: When either CLR ALL INT or CLR ALL
CART are selected, the BANK and REG sliders
are inactive.
