6 Shake It Up
SPD SPD MAX
204 192 5
PDL PDL IND
98.24ms 107.2ms 5.62ms
FBK FBK CFB
0 0 20
7 Wowza
SPD SPD MAX
182 260 4
PDL PDL IND
0.0ms 0.00 18.30ms
FBK FBK CFB
-36 40 40
8 Wowza 2
SPD SPD MAX
115 115 4
PDL PDL IND
10.6ms 9.44ms 5.62ms
FBK FBK CFB
-38 21 38
9 Vocalz
SPD SPD MAX
39 49 3
PDL PDL IND
4.44ms 4.44ms 48.57ms
FBK FBK CFB
-21 21 25
0 X Flange
SPD SPD MAX
50 25 1
PDL PDL IND
0.0ms 0.0ms 24.21ms
FBK FBK CFB
-30 -30 -45
Program Descriptions
1 Prime Chorus
This is a basic preset which independently wobbles the
left and right audio sources. Each channel runs asyn-
chronously (different speeds and windows). However,
there is a small amount of cross feedback which runs
the output of each channel back into the opposite input.
MAX WIN WIN
7 23smp 31smp
IND TRB MIX
5.62ms 5.53kHz All Fx
CFB PAN PAN
20 Right Left
MAX WIN WIN
5 78smp 39smp
IND TRB MIX
5.62ms 5.5kHz All Fx
CFB PAN PAN
-29 Left Right
MAX WIN WIN
5 59smp 122smp
IND TRB MIX
5.62ms 7.8kHz All Fx
CFB PAN PAN
-21 70 30
MAX WIN WIN
4 771smp 850smp
IND TRB MIX
48.57ms 4.18kHz 80 Fx
CFB PAN PAN
-25 Left Right
MAX WIN WIN
1 200smp 500smp
IND TRB MIX
24.21ms 19.4kHz All Fx
CFB PAN PAN
-45 Right Left
Bank 15: the Prime Time III Programs
2 Slap Chorus
Similar to Prime Chorus except a longer predelay is
utilized. Great for chunky electric guitar rhythm pads.
Reduce feedbacks and cross feedbacks for less de-
cay.
3 Bounce Glide
This preset bounces back and forth. The outputs are
panned reversed, so don't drive yourself crazy if you
feed in a discrete stereo source. The delay returns are
slowly modulated. Pushing MAX to a greater value will
result in a heavy, heavy unearthly effect.
4 Swirls
This preset is a fast moving modulating effect. Each
predelay is set to 0ms and all feedbacks and cross
feedbacks are used with one of each phase inverted.
Any use of this effect which winds up passing through
a surround decoder will swirl all around you.
5 Heavy Detune
Use with caution. Strong effect for an aggressive "Idol"
type lead vocal.
6 Shake It Up
Strong slap-fast vibrato effect. For more intensity,
increse the values of FBL and FBR to 50. If you slow
it down with the speed controls you may want to lessen
MAX shift as well. The outputs are panned reversed.
7 Wowza
Kinda like a fast Leslie on acid....
8 Wowza 2
Four hours later.....
9 Vocalz
This preset is somewhat filtered down, but the dry
delay set to 48ms with the mix control set to 80% helps
create a doubling effect. Definitely for smooth sound
sources.
0 X Flange
Use this pre-fader. This an "over the top" flange effect
which chases its own tail. Mix the returns to mono for
an even stronger effect. In stereo it drives a surround
decoder crazy.
12-4
