Installing a Nokia 5i and 10i Gateway

Connecting the Console Port

Use the built-in console port to supply the information that makes the gateway
available on the network. Use the built-in serial port (AUX) for
RS232-compliant equipment you are using with your gateway; for example,
as a modem connection for managing the gateway.
provides pin assignment information for console and serial connections.
Caution
Nokia recommends that you use the console cable that was
delivered with your gateway for your console connection. Otherwise,
ensure that the pin assignments for your cable match those provided
in this section.
Note
Although pin assignments are the same for console and serial
connections, they are used differently by the gateway. Therefore, do not
use these two connectors interchangeably.
Use an ASCII terminal or a computer with terminal emulation software for
console communication.
The following terminal settings are required to communicate with the
gateway by using the console port:
Baud rate
Data bits
Parity
Stop bit
Flow control
26
9600
8
none
1
none
Table 4
on page 29
Nokia 5i and 10i Installation Guide
