Nokia NBB5005000 - IP VPN 5i Installation Manual

Installation guide.
Hide thumbs

Advertisement

Nokia 5i and 10i
Part No. N451658002 Rev A
Published July 2005

Advertisement

   Related Manuals for Nokia NBB5005000 - IP VPN 5i

   Summary of Contents for Nokia NBB5005000 - IP VPN 5i

  • Page 1: Installation Guide

    Nokia 5i and 10i Installation Guide Part No. N451658002 Rev A Published July 2005...

  • Page 2

    Rights clause at FAR 52.227-19. IMPORTANT NOTE TO USERS This software and hardware is provided by Nokia Inc. as is and any express or implied warranties, including, but not limited to, implied warranties of merchantability and fitness for a particular purpose are disclaimed. In no event shall Nokia, or its affiliates, subsidiaries or suppliers be liable for any direct, indirect, incidental, special, exemplary, or consequential damages (including, but not limited to, procurement of substitute goods or services;...

  • Page 3

    Singapore 119968 Nokia Customer Support Web Site: https://support.nokia.com/ Email: tac.support@nokia.com Americas Europe Voice: 1-888-361-5030 or Voice: +44 (0) 125-286-8900 1-613-271-6721 Fax: 1-613-271-8782 Fax: +44 (0) 125-286-5666 Asia-Pacific Voice: +65-67232999 Fax: +65-67232897 050602 Nokia 5i and 10i Installation Guide...

  • Page 4

    Nokia 5i and 10i Installation Guide...

  • Page 5: Table Of Contents

    Overview ......... . . 17 About the Nokia 5i and 10i Gateways ..... . 17 Preparing the Installation Environment .

  • Page 6: Table Of Contents

    Index ..........47 Nokia 5i and 10i Installation Guide...

  • Page 7: Table Of Contents

    Figures Figure 1 Rear View of the Nokia 5i and Nokia 10i Gateways . . . 23 Figure 2 Pin Assignments for Console and AUX Connections . . 28 Figure 3 Power Cord Receptacle on the Nokia 5i and Nokia 10i Figure 4 System Status LEDs for the Nokia 5i and Nokia 10i .

  • Page 8

    Nokia 5i and 10i Installation Guide...

  • Page 9

    Table 3 Rear Panel connection descriptions of the Nokia 5i and Nokia 10i ........24 Table 4 Pin Assignments for DB9 and DB25 Interface Cables .

  • Page 10

    Nokia 5i and 10i Installation Guide...

  • Page 11: About This Guide, In This Guide

    About This Guide This guide describes the installation and use of the Nokia 5i and 10i gateways. Installation and maintenance should be performed only by experienced technicians or Nokia-approved service providers. This preface provides the following information: In This Guide...

  • Page 12: Conventions This Guide Uses, Notices

    Warnings advise the user that bodily injury might occur because of a physical hazard. Caution Cautions indicate potential equipment damage, equipment malfunction, loss of performance, loss of data, or interruption of service. Note Notes provide information of special interest or recommendations. Nokia 5i and 10i Installation Guide...

  • Page 13: Command-line Conventions

    Conventions This Guide Uses Command-Line Conventions This section defines the elements of commands that are available in Nokia Internet Communications products. You might encounter one or more of the following elements in a command-line path. Table 1 Command-Line Conventions Convention...

  • Page 14: Text Conventions

    Keys that you press simultaneously are linked by a plus sign (+): Press Ctrl + Alt + Del. Menu commands Menu commands are separated by a greater than sign (>): Choose File > Open. Nokia 5i and 10i Installation Guide...

  • Page 15: Related Documentation

    In addition to this guide, documentation for this product includes the following: Nokia IP VPN Gateway Configuration Guide v6.3 describes how to configure and manage Nokia IP VPN Gateways by using the Nokia VPN Manager software. Nokia IP VPN Gateway Command-Line Summary v6.3 is a reference for the command-line interface (CLI) for Nokia IP VPN gateways.

  • Page 16

    Nokia 5i and 10i Installation Guide...

  • Page 17: Overview, About The Nokia 5i And 10i Gateways, Preparing The Installation Environment

    The Nokia 5i and Nokia 10i gateways enable advanced home and office networking. Business users can securely connect to the corporate network. Both the Nokia 5i and Nokia 10i are designed for placement on a desk, table, or other flat surface.

  • Page 18: Ventilation, Humidity And Temperature, Safety Precautions

    Read and follow all of these precautions before you work near any power source. Circuit breakers must be installed in the fixed wiring on all circuits to which the gateways are connected. Ensure that all of the circuit breakers are easily accessible. Nokia 5i and 10i Installation Guide...

  • Page 19

    Do not work on the gateway during an electrical storm. Do not connect or disconnect any wires, including network or power connections. Whenever the threat of lightning danger exists, avoid touching the gateway. This precaution is sensible for any electrical device during periods of lightning activity. Nokia 5i and 10i Installation Guide...

  • Page 20: Product Disposal

    The device contains components (such as its lithium battery) that must be disposed of properly to prevent damage to the environment. Contact your local waste management agencies for specific guidelines. Nokia 5i and 10i Installation Guide...

  • Page 21: Site Requirements

    Site Requirements Site Requirements Before you install a Nokia 5i or 10i gateway, ensure that your computer room or wiring closet conforms to the environmental specifications listed in Appendix A, “Technical Specifications,” Warning Hazardous radiation exposure can occur if you use controls, make performance adjustments, or follow procedures that are not described in this document.

  • Page 22

    Overview Nokia 5i and 10i Installation Guide...

  • Page 23: Installing A Nokia 5i And 10i Gateway

    Installing a Nokia 5i and 10i Gateway Both the Nokia 5i and Nokia 10i are designed for placement on a desk, table, or other flat surface. They are not designed for rack-mount or wall-mount installations. Rear Panel All physical connections to the Nokia 5i and Nokia 10i, such as network and power, are made through the rear panel.

  • Page 24: Resetting The Gateway To Factory Default

    Auxiliary The auxiliary port (AUX) or dial-in port is a 9-pin male connector. This port is used to dial in to the Nokia 5i and Nokia 10i through a modem when the Nokia 5i or Nokia 10i is unreachable through other ports.

  • Page 25: Performing The Initial Hardware Configuration

    31. Performing the Initial Hardware Configuration The first time you turn on power to a Nokia 5i or Nokia 10i gateway, the initial hardware configuration process begins. This section describes how to perform the initial configuration manually by using a console connection.

  • Page 26: Connecting The Console Port

    Caution Nokia recommends that you use the console cable that was delivered with your gateway for your console connection. Otherwise, ensure that the pin assignments for your cable match those provided in this section.

  • Page 27

    Use the built-in serial port (AUX) for RS232- compliant equipment you are using with your gateway; for example, as a modem connection for managing the gateway. Figure 2 provides pin assignment information for console and serial connections. Nokia 5i and 10i Installation Guide...

  • Page 28: Figure 2 Pin Assignments For Console And Aux Connections

    Installing a Nokia 5i and 10i Gateway Figure 2 Pin Assignments for Console and AUX Connections Input or Pin # Assignment output Input (AUX port only; not used 00460 by the console port) Input Output Output Input Output Input not used...

  • Page 29: Connecting Power And Turning The Power On

    The gateway power supplies automatically detects the input voltage (120 VAC [100 to 130] or 240 VAC [200 to 264]) and configures itself appropriately. Note The Nokia 5i and Nokia 10i automatically powers on when the power cable is connected. Nokia 5i and 10i Installation Guide...

  • Page 30: Figure 3 Power Cord Receptacle On The Nokia 5i And Nokia 10i

    2. Plug the other end of the cord into a three-wire grounded power strip or wall outlet. If the gateway does not power up, contact your Nokia service provider as listed in “Nokia Contact Information” on page 3 for technical support.

  • Page 31: Figure 4 System Status Leds For The Nokia 5i And Nokia 10i

    You can monitor the basic operation of the gateway and network interfaces by checking their status LEDs. The system status LEDs are located on the front panel of the gateway. Figure 4 System Status LEDs for the Nokia 5i and Nokia 10i 00418 Table 5 describes the LEDs on the Nokia 5i and Nokia 10i front panel.

  • Page 32: Connecting Network Interfaces, Connecting To Ethernet Ports

    Mbps ports. Connecting to Ethernet Ports You can connect one network interface to the network to use as the Nokia IP VPN Gateway interface. You configure this interface during the system startup procedure, which is described in the Performing the Initial Gateway Configuration section of the Nokia IP VPN Installation Guide.

  • Page 33: Ethernet Cables

    Connecting Network Interfaces Ethernet Cables The Nokia 5i and Nokia 10i use IEEE 802.3 10 BASE-T, 100 Base-TX shielded twisted-pair, CAT-5 ethernet cables. To connect Ethernet devices: Use a straight-through RJ-45 cable to connect to a 10-Mbps or 100-Mbps hub or switch.

  • Page 34: Figure 5 Output Connector For The Ethernet Cable

    Installing a Nokia 5i and 10i Gateway Figure 5 Output Connector for the Ethernet Cable Gigabit 10/100 Mbps Ethernet Pin # assignment assignment BI_DA+ 00270a BI_DA- BI_DB+ BI_DC+ BI_DC- RX - BI_DB- BI_DD+ BI_DD- Figure 6 on page 35 shows the pin assignments for the RJ-45 crossover cable.

  • Page 35: Figure 6 Ethernet Crossover-cable Pin Connections

    Connecting Network Interfaces Figure 6 Ethernet Crossover-Cable Pin Connections 00017.1 You can order appropriate adapter cables separately. To order additional cables, contact your cable vendor. Nokia 5i and 10i Installation Guide...

  • Page 36

    Installing a Nokia 5i and 10i Gateway Nokia 5i and 10i Installation Guide...

  • Page 37: Troubleshooting

    Problem No console connection to the gateway. Solution For information about how to create a console connection, see “Connecting the Console Port” on page 26. Nokia 5i and 10i Installation Guide...

  • Page 38

    Problem Wrong terminal settings. Solution Verify terminal settings: 9600 bps, 8 data bits, 1 stop bit, no parity. Problem Defective gateway or file system. Solution Contact the Nokia customer support site listed in “Nokia Contact Information” on page 3. Do Not Get a Login Prompt—Error Messages Appear Problem The gateway is defective, or the file system on the gateway is defective.

  • Page 39

    Ethernet connection (10 Mbps, 100 Mbps, or 1000 Mbps). Problem Port not enabled. Solution Verify from the Interface page in Nokia VPN Manager that the interface port is configured as active. Problem High collision rate on the hub.

  • Page 40

    Troubleshooting Nokia 5i and 10i Installation Guide...

  • Page 41: A Technical Specifications, Physical Dimensions

    Depth: 4.8 in. (12.19 cm) Weight 1.8 lbs (0.81 kg) Model Nokia 10i Dimensions Height: 1.2 in. (3.04 cm) Width: 8.0 in. (20.32 cm) Depth: 4.8 in. (12.19 cm) Weight 1.8 lbs (0.81 kg) Nokia 5i and 10i Installation Guide...

  • Page 42: Space Requirements, Random Access Memory, Data Storage

    Technical Specifications Space Requirements The Nokia 5i and Nokia 10i are not rack mounted. Both the Nokia 5i and Nokia 10i are designed for placement on a desk, table, or other flat surface. Random Access Memory The random access memory for the gateways is:...

  • Page 43: B Compliance Information, Declaration Of Conformity

    According to ISO/IEC Guide 22 and EN 45014: Manufacturer’s Name: Nokia Inc. 313 Fairchild Drive Mountain View, CA 94043-2215 Manufacturer’s Address: declares that the product: Product Name: 10i, 5i Model Number: EM3100 Product Options: Nokia 5i and 10i Installation Guide...

  • Page 44

    Directive 89/336/EEC with Amendment 93/68/EEC. Christopher Saleem Compliance & Reliability Engineering Manager Security & Mobile Connectivity, Enterprise Solutions Mountain View, California Elie Habib Senior Vice President Security & Mobile Connectivity, Enterprise Solutions Mountain View, CA Nokia 5i and 10i Installation Guide...

  • Page 45: Compliance Statements

    European Community (CE) Immunity Standards EN55024 European Community (CE) EN61000-4-2 EN61000-4-3 EN61000-4-4 EN61000-4-5 EN61000-4-6 EN61000-4-11 Harmonics and Voltage Fluctuation EN61000-3-2 European Community (CE) EN61000-3-3 European Community (CE) Safety Standards UL60950/EN60950 US/European Community(CE) CAN/CSA-C22.2 No.60950 Canada Nokia 5i and 10i Installation Guide...

  • Page 46: Fcc Notice (us)

    Consult the dealer or an experienced radio/TV technician for help. Caution Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. 050324 Nokia 5i and 10i Installation Guide...

  • Page 47: Index

    17 console temperature 18 cable connection 27 ventilation 18 terminal settings 26 LEDs 31 data communications equipment device 27 data storage 42 dimensions, physical 41 modem connection, pin assignments 28 Nokia 5i and 10i Installation Guide Index - 47...

  • Page 48

    29 power source, safety 20 random access memory 42 RJ-45 connector 33, 34 safety, power source 20 specifications space requirements 42 technical specifications See specifications terminal settings 26 troubleshooting 37 Index - 48 Nokia 5i and 10i Installation Guide...

This manual also for:

5i, 10i
