Installation
The Core2 card must be installed in a PCI slot which is a bus master slot to take advantage of its bus
master capabilities. Refer to your computer owner's manual to determine which slots are available
as bus masters. (On some older motherboards, the PCI slot next to the ISA bus connector [the PCI/
ISA/ shared slot] is not a PCI bus master slot).
Setup
1. Put on the anti-static wrist strap.
2. Place the foam from your Lexicon Studio package on top of a work surface next to your computer.
3. Make sure that your computer is properly shut down and unplugged.
4. Remove the computer top cover and PCI slot cover(s) for the slots you've chosen for the Core2
card. If you do not know how to open your computer, consult the manufacturer's owner's manual.
5. Touch the computer power supply case to discharge any personal static electricity.
6. Remove the Core2 from its anti-static bag, holding the card only by its edges. Be careful to avoid
touching the pins on the bottom edge of the card.
Install the Card
1. Align the Core2 card over the slot you've chosen and insert it.
2. Place one hand along the top edge of the card and push down firmly until the card is fully seated
in the slot. Do not use excessive force.
3. Once the card is fully seated, attach the bracket to the computer chassis with the screws provided
with your computer. If the computer is a tower or mini-tower design, check to see that boards are
not bending under their own weight and shorting against each other.
4. Replace the cover on the computer. Do not operate the system without the cover.
