Lexicon Studio Core2 User Guide
Analog Input Levels
The level of the Analog Inputs can be controlled by on-screen faders with the level displayed
numerically at the bottom. A level setting of 0dB sets unity gain from the analog input to the analog
output. A setting of 0dB corresponds to -10dBV, 18dB below digital full-scale.
The Link button between fader pairs allows them to be linked as a stereo pair for convenient identical
gain setting. The left fader value takes precedence when Link is used to make the faders operate at
the same level.
Control click on the Link button to link the fader heads while maintaining their relative levels.
Control click on a fader head to set the fader (or linked fader pair) to 0dB.
To enter gain levels numerically, double-click on a numeric field, then enter a value.
Using the LexPanel
