Unpacking and Inspection
After unpacking the system modules, save all packing materials in case you ever need to ship the units. Thoroughly inspect the modules and packing
materials for signs of damage. Report any damage to the carrier at once; report equipment malfunction to your dealer.
Communications Notice
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may
cause interference to radio and television reception. It has been type tested and found to comply with the limits for a Class B computing device in accordance with the
specifications in Subpart B of Part 15 of FCC Rules, which are designated to provide reasonable protection against such interference in a residential installation. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television reception, which can be
determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient the receiving antenna
Relocate the computer with respect to the receiver
Move the computer away from the receiver
Plug the computer into a different outlet so that the computer and receiver are on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet prepared
by the Federal Communications Commission helpful: "How to identify and Resolve Radio/TV Interference Problems." This booklet is available from the U.S. Government
Printing Office, Washington, DC 20402, Stock No. 004-000-00345-4.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class B prescrites dans le
Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada.
Ground
Clamp
Electric
Service
Equipment
Ground Clamps
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
NEC — National Electrical Code
"ADAT" is a trademark of the Alesis Corporation.
"Cool Edit Pro" is a trademark of Syntrillium.
"Type IV is a trademark of dbx Corporation.
Copyright 1999, Lexicon Inc.
All Rights Reserved.
Lexicon Part # 070-13748
Outdoor Antenna Grounding
Antenna Lead-in
Wire
If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide
some protection against voltage surges and built-up static charges. Section 810 of the National Electrical
Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mast and
Antenna Discharge
supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding
Unit (NEC Section
810-20)
conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for
the grounding electrode. See figure below.
Grounding Conductors
(NEC Section 810-21)
Power Lines An outside antenna should be located away from power lines.
Lexicon Inc.
3 Oak Park
Bedford MA 01730-1441
Telephone 781-280-0300
Fax 781-280-0490
www.lexicon.com
