Using Cool Edit Pro
Assigning Core2 I/O in Cool Edit Pro
Core2 inputs and outputs are assigned to tracks in two different ways, depending on the view (stereo
waveform or multitrack) in which you are working.
In the stereo waveform view, select Options/Settings/Devices. In the window that appears, you can
define Waveform Playback and Waveform Record devices. Simply highlight the Core2 inputs and
outputs you want to use in the appropriate fields. These settings will apply for all files that you play
or record when in the stereo waveform view.
In the multitrack view, inputs and outputs are assigned for each individual track. Before making
assignments, you must set up Preferred Multitrack Devices. To do this,
1. Click on either of the small numeral 1's at the far left of the track display to open the Playback
Device window.
2. Click on the Device List button to access a list of Preferred Multitrack Devices.
3. In each Playback field, assign a stereo Core2 output stream.
4. In each Record field, assign a stereo Core2 input stream.
5. Click OK on each window to back out to the Multitrack screen.
As these device settings are saved as Preferences in Cool Edit Pro, they will be used for all
subsequent sessions until you change them.
To make the playback and record device assignments for a specific track,
1. Click anywhere in the gray area at the far left of the track display to open the Track Info window.
2. Click on the arrows in the Playback Device and Record Device fields to select the desired inputs
and outputs.
