Lexicon CORE2 User Manual page 16

Using the LexPanel
Each I/O button on the Routing tab will turn on all of the corresponding inputs or outputs. Selections
which are precluded by current selections appear in gray. A check box labeled Optical appears next
to the S/PDIF buttons. When this box is checked, the optical connectors on the Core2 card will be set
to the S/PDIF format — and the ADAT buttons will be unavailable for selection (gray).
Below is a table of possible configurations:
Option
Number
1
2
3
4
5
Press Apply or OK to save routing changes.
If you are using the Wave drivers, and make any changes to the Routing Tab in the Lexicon control
panel, you must restart Windows in order to have these changes take effect.
If the ASIO drivers are being used, it is not necessary to restart Windows. Simply quit then re-launch
the audio application to have the routing changes take effect. In Cubase, blank labels on the Input and
Output buses indicates that the application must be restarted. If you are using Cubase and have
launched the Lexicon Control Panel from the Windows taskbar, you must quit Cubase before making
changes to the Routing Tab.
NOTE: At least one Input pair and one Output pair must be enabled in order to launch Cubase. If no
streams are active, an error message will indicate that the ASIO Lexicon Studio V4.2 driver could not
be loaded. If this occurs, quit Cubase, launch the LexPanel from the Windows taskbar, turn on one
or more I/O streams, then re-launch Cubase.
12
12
Analog In Analog Out
X X
X X
X X
X X
X X
Coax Coax
S/PDIF In S/PDIF Out
- -
X X
- -
- X
X -
Lexicon
Optical In Optical Out
ADAT ADAT
- -
S/PDIF S/PDIF
ADAT -
- ADAT
