Main parts identification

322482/B
Figure 2 The PI Geometry sensor, main parts identification
A Negative charging and fastening lug.
B Positive charging and fastening lug.
Communication link to the vessel and to the responders.
C
D Geometry set identification.
E Location of water switch and sensor identification label.
