INSTALLATION

322482/B

The PI Geometry sensor is mounted at the exact centre of the

trawl or danish seine opening, either at the headrope at the top of

the opening, or at the footrope at the bottom. In both locations

it must be mounted with the communication transducers facing

forward. The two Mini-R responders are normally installed on

the trawl doors or trawl wings. From this position, they will

communicate with the PI Geometry sensor.

The PI Geometry sensor must be mounted at the exact centre of

the trawl or danish seine opening. The most common location is

at the headrope at the top of the opening. It may however also

be place at the footrope.

Note

Ensure that you mount the sensor with the transducer opening

facing forward. There must be a clear line of sight between the

transducer on the PI Geometry sensor and the transducers on the

Mini-R responders. The SIMRAD print on the sensor (C) must

point up towards the water surface!
