Simrad PI GEOMETRY - REV B Instruction Manual page 21

322482/B
Figure 9 PI Geometry configuration example
This example shows how the PI44 (or PI54) is set up to receive
information from a PI Geometry sensor. Note that two channels
are used. Standard communication channels and update rates
are also shown.
How to access the Setup menu
Press the
1
MENU
2 On the menu, select
Setup
3 Press the button to allow for changes, and then the
ENT
same button one more time to accept the warning.
How to set up the geometry readings
1 To reset the unit, set all six sensors to default sensor type
None.
2 Choose the sensor input you wish to use for the PI Geometry
sensor; 1 to 6.
Define the sensor type (by default None) to Dual.
3
4 Set to the correct update rate.
Update
to the chosen sensor type Geometry (0 to 300
5 Set
Measure 1
m) or Geometry XT (0 to 600 m).
6 Set the communication
Set to the chosen sensor type Geometry or
7
Measure 2
Geometry XT.
Note
and
Measure 1 Measure 2
8 Set the communication
9 Press the button to save the changes and exit.
ENT
button to open the main menu.
Sensor setup
to its correct value.
Channel
must be set to the same sensor type!
to its correct value.
Channel
Configuration
.
19
