RISER
®
BEFORE INSTALLATION
READ INSTRUCTIONS CAREFULLY BEFORE STARTING
INSTALLATION. REMOVE CONTENTS FROM BOX AND
VERIFY ALL PARTS ARE PRESENT. FAILURE TO IDENTIFY
DAMAGE BEFORE INSTALLATION COULD LEAD TO A
REJECTION OF ANY CLAIM. IF MISSING PARTS OR ANY
DAMAGE FOUND, PLEASE TAKE A PICTURE FOR THE
CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT:
WWW.TYGERAUTO.COM/CONTACT
Driver Side Riser
D
x1
Passenger Side Riser
x1
Brackets
x6
ATTENTION: Refer to
P
D
Customer Support: www.tygerauto.com/contact
8-1.25mm x 25mm Combo Bolts
x12
8mm Lock Washers
P
x12
8mm x 24mm x 2mm Flat Washers
x12
D
P
and
labelling on the side of the tubes to determine Driver and Passenger Riser
Front
Front
x12
x6
Brackets
Combo Bolts
TORQUE VALUES
Fastener Size
Class 8.8 Torque (ft-lbs)
6mm
8mm
15-16
10mm
31-32
12mm
54-55
14mm
87-88
8-1.25mm x 30mm Hex Bolts
x12
Top View
P
Passenger Side Riser
D
Driver Side Riser
x12
Hex Bolts
Flat Washers
1/4
1/3
TG-RS6C60238
Class 10.9 Torque (ft-lbs)
6-7
22-23
44-45
78-79
125-126
x12
x12
Lock Washers
6-7
V240318
Advertisement
Related Manuals for Tyger RISER TG-RS6C60238
Summary of Contents for Tyger RISER TG-RS6C60238
- Page 1 RISER ® TG-RS6C60238 BEFORE INSTALLATION TORQUE VALUES READ INSTRUCTIONS CAREFULLY BEFORE STARTING Fastener Size Class 8.8 Torque (ft-lbs) Class 10.9 Torque (ft-lbs) INSTALLATION. REMOVE CONTENTS FROM BOX AND VERIFY ALL PARTS ARE PRESENT. FAILURE TO IDENTIFY 15-16 22-23 DAMAGE BEFORE INSTALLATION COULD LEAD TO A REJECTION OF ANY CLAIM.
- Page 2 TYGER STAR STRIDER RISER RISER Reference the letters printed on the brackets to determine mounting locations Front Driver Side Riser Front Passenger Side Riser Bottom View Front Driver Side Riser Front Passenger Side Riser...
- Page 3 RISER TOOLS REQUIRED Ratchet 13mm Socket Remover Plugs Front Extensions Wrench (Fig 2) Remove plastic plugs to uncover threaded inserts at front mounting location (if any) STEP 1 MOUNTING BRACKETS Follow (Fig 1 – 5) to attach the Brackets to the Passenger Side. Then repeat the sames steps on the Driver Side.
- Page 4 RISER Passenger-side Rear Mounting Area Remover Plugs Front (Fig 5) Remove plastic plugs to uncover threaded inserts at the rear mounting location. Attach a Bracket to Rear Mounting Location (refer to Fig 3) MOUNTING STEP 2 RUNNING BOARDS Follow (Fig 6) to install the running boards onto each Bracket for both sides.
