RISER
®
BEFORE INSTALLATION
READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. REMOVE
CONTENTS FROM BOX AND VERIFY ALL PARTS ARE PRESENT. FAILURE TO
IDENTIFY DAMAGE BEFORE INSTALLATION COULD LEAD TO A REJECTION OF
ANY CLAIM. IF MISSING PARTS OR ANY DAMAGE FOUND, PLEASE TAKE A
PICTURE FOR THE CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT:
WWW.TYGERAUTO.COM/CONTACT
TORQUE VALUES
Fastener Size
Class 8.8 Torque (ft-lbs)
6mm
8mm
10mm
12mm
14mm
Driver/Left 6inch TYGER Sidebar
Front
Class 10.9 Torque (ft-lbs)
6-7
15-16
31-32
54-55
87-88
(3) Mounting Brackets
Customer Support: www.TygerAuto.com/Contact
TG-RS6C60048
Parts List
6-7
22-23
44-45
78-79
125-126
Passenger Side Front
Upper & Lower Bracket
1/6
x1
Driver/Left 6inch TYGER Sidebar
x1
Passenger/Right 6inch TYGER Sidebar
Mounting Brackets
x7
x1
Passenger/Right Front Upper Mounting Bracket
Passenger/Right Front Lower Mounting Bracket
x1
8mm Bolt Plate
x1
8mm x 25mm Combo Bolts
x16
8mm x 25mm Hex Bolts
x17
x17
8mm x 24mm OD x 2mm Flat Washers
x17
8mm Lock Washers
8mm Nylon Lock Nut
x1
x15
8mm Clip Nuts
(4) Mounting Brackets
V210916
Advertisement
Related Manuals for Tyger RISER TG-RS6C60048
Summary of Contents for Tyger RISER TG-RS6C60048
- Page 1 RISER ® TG-RS6C60048 Parts List Driver/Left 6inch TYGER Sidebar BEFORE INSTALLATION Passenger/Right 6inch TYGER Sidebar READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. REMOVE CONTENTS FROM BOX AND VERIFY ALL PARTS ARE PRESENT. FAILURE TO Mounting Brackets IDENTIFY DAMAGE BEFORE INSTALLATION COULD LEAD TO A REJECTION OF ANY CLAIM.
- Page 2 PROCEDURE: REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. Factory 8mm threaded ON MODELS WITH DEF TANK, SELECT A FLAT, LEVEL AREA FOR insert in body panel INSTALLATION. MAY REQUIRE CUTTING. STEP 1 Start the installation under the Driver/Left side of the vehicle.
- Page 3 STEP 4 (2) 8mm Clip Repeat STEPs 1-3 to attach (2) Mounting Brackets to the Driver/Left side. STEP 5 Rear Select the Driver/Left 6inch Running Board. Attach the Running Board to the Mounting Brackets with (8) 8mm Combo Bolts (Fig (Fig 4) Driver/Left Rear mounting location 6).
- Page 4 a. On models with plastic lower tray under the tank, remove the (3) hex bolts attaching the tray to the frame (Fig 7), and remove the tray. b. Release the tank filler hose. Release the plug for the sending unit on the top of the tank. c.
- Page 5 (1) 8mm Hex Bolt (1) 8mm Lock Washer STEP 7 (1) 8mm Flat Washer (1) 8mm Nylon Lock Nut Locate the first tab on the edge of the pinch weld. Select the Upper Bracket (Fig 10). Repeat STEPs 2 & 3 to attach the Passenger/Right Front Upper Mounting Bracket to the side of the rocker panel (Fig 11).
- Page 6 DEF cut for example only (Fig 15) Secure the side of the Lower Bracket to the Upper Bracket STEP 12 Repeat STEP 5 to attach the Passenger/Right TYGER 6inch Running Board. STEP 10 Repeat STEPs 1-3 to attach the remaining (3) Mounting Brackets to the Passenger/Right rocker panel.
