Tyger RISER TG-RS2T40148 Manual

Running boards compatible with 2005-2023 toyota tacoma

Download this manual

Part: TG-RS2T40148

Parts List

Driver/Left Side Bar

Passenger/Right Side Bar

Driver/Left Front Mounting Bracket

Passenger/Right Front Mounting Bracket

Driver/Left Rear Mounting Bracket

Passenger/Right Rear Mounting Bracket

Passenger/Right

Rear Bracket

Passenger/Right Front

Mounting Bracket

Front

8-1.25mm x 30mm Hex Bolts

8mm x 24mm OD x 2mm Flat Washers

8mm Lock Washers

8-1.25mm x 25mm Combination Bolts

Plastic Clips

Plastic Covers

(4) Bracket Covers

(8) Plastic Clips for

Covers

Driver/left Side Step illustrated

1/4

Customer Support: www.TygerAuto.com/Contact

Customer Support 1-866-340-3038

RISER

Driver/Left Rear

Bracket

Driver/Left Front

Mounting Bracket

Need help?

Do you have a question about the RISER TG-RS2T40148 and is the answer not in the manual?

Page 1 Customer Support 1-866-340-3038 RISER ® Part: TG-RS2T40148 Parts List Driver/Left Side Bar 8-1.25mm x 30mm Hex Bolts Passenger/Right Side Bar 8mm x 24mm OD x 2mm Flat Washers Driver/Left Front Mounting Bracket 8mm Lock Washers Passenger/Right Front Mounting Bracket 8-1.25mm x 25mm Combination Bolts Driver/Left Rear Mounting Bracket Plastic Clips Passenger/Right Rear Mounting Bracket...
Page 2 Before Installation (2) 8mm x 30mm Hex Bolts (2) 8mm Flat Washers (2) 8mm Lock Washers REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS CAREFULLY. USE ILLUSTRATION TO PROPERLY IDENTIFY BRACKETS AND SIDEBARS. STEP 1 Front Starting on the passenger side front of the vehicle, remove the plastic plugs or bolts covering the threaded holes in the body panel, (Figure 1).
Page 3 (2) 8mm x 30mm Hex Bolts STEP 3 (2) 8mm Flat Washers (2) 8mm Lock Washers Repeat Steps 1 & 2 for rear Mounting Bracket installation, (Figures 5 & 7). STEP 4 Front Select the passenger/right Side Step. Carefully position the Side Step onto the Mounting Brackets.
Page 4 STEP 7 Do periodic inspections to the installation to make sure that all hardware is secure and tight. Torque Value Fastener Class 8.8 Tightening Class10.9 Tightening Size Torque (ft-lbs) Torque (ft-lbs) 15-16 22-23 31-32 44-45 10mm 54-55 12mm 78-79 87-88 14mm 125-126 Complete Installation...
