- Page 1 BLACK MODULAR GRILL GUARD FOR DODGE RAM 2500/3500 2009-2018(Excl. Rebel Trim) INSTALLATION INSTRUCTIONS BLACK MODULAR GRILL GUARD FOR DODGE RAM 2500/3500 2009-2018(Excl. Rebel Trim) PART # 17DR01MA Page 1 of 5...
-
Page 2: Before Installation
BLACK MODULAR GRILL GUARD FOR DODGE RAM 2500/3500 2009-2018(Excl. Rebel Trim) Before Installation Please read the instruction completely for easy installation, which will also help you to avoid scratches or other potential damages to your appealing car. The figures here are for reference only and may have differences with the actual product you received, however they share the same assembly way. -
Page 3: Installation Steps
BLACK MODULAR GRILL GUARD FOR DODGE RAM 2500/3500 2009-2018(Excl. Rebel Trim) Bracket R Installation Steps Description Description Hex bolt M12_35 Flat washer D12(12x24x2.5mm) ⑦ ⑧ ⑪ ⑫ Hex lock nut M12 Hex bolt M10_45 ⑨ ⑩ ⑬ ⑭ Spring washer D10 Flat washer D10(10x30x2.5mm) ⑯... - Page 4 BLACK MODULAR GRILL GUARD FOR DODGE RAM 2500/3500 2009-2018(Excl. Rebel Trim) PROCEDURE: Step 1: Use standard parts ⑭⑮⑯ to connect left and right brush guards with grille guard. ⑭⑮⑯ ⑪⑪⑫⑬ to install bracket L/R on the original ⑩ Step 2: Remove tow hook. Use standard parts mounting points of tow hook.
- Page 5 BLACK MODULAR GRILL GUARD FOR DODGE RAM 2500/3500 2009-2018(Excl. Rebel Trim) ⑦⑧⑨ Step3: Use standard parts to install step 1 grille guard on step 2 brackets. Adjust the grille guard, and then tighten all hardware. ⑦⑧⑨ Step4: Installation is finished, pick up all tools. NOTE Any damages and losses caused by improper installation and application, goes beyond our quality warranty.
