- Page 1 S/S MODULAR GRILL GUARD FOR CHEVY TAHOE/SUBURBAN 07-14/AVALANCHE 07-13 INSTALLATION INSTRUCTIONS S/S MODULAR GRILL GUARD FOR CHEVY TAHOE/SUBURBAN 07- 14/AVALANCHE 07-13 PART # 17A037400MSS Page 1 of 7 3/6/12Rev1 (DP)
-
Page 2: Parts List
S/S MODULAR GRILL GUARD FOR CHEVY TAHOE/SUBURBAN 07-14/AVALANCHE 07-13 PARTS LIST: 1 Grille Guard 12 Cap nut M12 2 Frame Mounting Brackets 8 Hexagon bolt M12_30 2 Lower Support Brackets 22 Flat washer D12(12x24x2.5mm) 1 Driver/Left Top Support Bracket 2 Hexagon bolt M6_20 1 Passenger/Right Top Support Bracket 2 Large washer D6(6x18x1.6mm) 1 Wrench S=5... - Page 3 S/S MODULAR GRILL GUARD FOR CHEVY TAHOE/SUBURBAN 07-14/AVALANCHE 07-13 a. On vehicles without tow hooks: The bumper may have plastic fill covers completely blocking the openings in the bumper or an indented area only and no opening. Cut slots to clear the flat Mounting Brackets. Reinstall the fill covers if removed. b.
- Page 4 S/S MODULAR GRILL GUARD FOR CHEVY TAHOE/SUBURBAN 07-14/AVALANCHE 07-13 Front Remove trim ring around opening for tow hook (Fig 1) Remove plastic bumper reinforcements (back of driver side pictured) 12mm x 35mm Bolt Plate Fig 2 Front Fig 3 12mm x 35mm Bolt Plate 12mm Flat Washer 12mm Nylon Lock Nut 12mm Plastic Retainer...
- Page 5 S/S MODULAR GRILL GUARD FOR CHEVY TAHOE/SUBURBAN 07-14/AVALANCHE 07-13 12mm x 140mm Hex Bolt Lower Support Bracket (2) 12mm Flat Washers 12mm Nylon Lock Nut 12mm x 35m Hex Bolt (2) 12mm Flat Washer 12mm Nylon Lock Nut 12mm x 35mm Bolt Plate 12mm Flat Washer 12mm Nylon Lock Nut Front...
- Page 6 S/S MODULAR GRILL GUARD FOR CHEVY TAHOE/SUBURBAN 07-14/AVALANCHE 07-13 Passenger Side Installation Pictured Remove factory Front hex bolt Fig 7 6mm x 20mm Hex Bolt 6mm Flat Washer 6mm Lock Washer Factory hex bolt Front Front (Fig 8A) Passenger side Top Fig 8B Support Bracket pictured (3) 12mm x 30mm Hex Bolts...
- Page 7 S/S MODULAR GRILL GUARD FOR CHEVY TAHOE/SUBURBAN 07-14/AVALANCHE 07-13 Hexagon socket button head screws M8_20 Cap Nut M8 Large washer D8 Page 7 of 7 3/6/12Rev1 (DP)
