Summary of Contents for Black Horse Off Road 17FOTRMA
- Page 1 INSTALLATION INSTRUCTIONS BLACK FRONT RUNNER GRILLE GUARD FOR 15-19 FORD TRANSIT VAN (FULL SIZE) PART #17FOTRMA...
-
Page 2: Parts List
BLACK FRONT RUNNER GRILLE GUARD FOR 15-17 FORD TRANSIT VAN (FULL SIZE) PARTS LIST: Front Runner Grille Guard Center 12mm Lock Washers Driver/Left Modular Wing 12mm Hex Nuts Passenger/Right Modular Wing 8-1.25mm x 40mm Hex Bolts Driver/Left Frame Mounting Bracket 8-1.25mm x 30mm Hex Bolts Passenger/Right Frame Mounting Bracket 18 8mm x 24mm OD x 2mm Flat Washers... - Page 3 BLACK FRONT RUNNER GRILLE GUARD FOR 15-17 FORD TRANSIT VAN (FULL SIZE) 7. Remove the (2) plastic plugs and hex bolts from the center of the bumper, (Figure 9). Select the (2) Tube Spacers, (Figure 10A). Insert the Spacers into the recess in the bumper, (Figure 10B). 8.
- Page 4 BLACK FRONT RUNNER GRILLE GUARD FOR 15-17 FORD TRANSIT VAN (FULL SIZE) 12mm x 32mm Large Flat Washer Front (Fig 4) remove (2) inner bumper (Fig 5) Driver side bracket bolts (driver side pictured) Mounting Bracket 12mm x 32mm Large Flat Washer Front (Fig 6A) Insert 12mm x 32mm Large Flat Washer...
- Page 5 BLACK FRONT RUNNER GRILLE GUARD FOR 15-17 FORD TRANSIT VAN (FULL SIZE) (4) 8mm x 30mm Hex Bolts (8) 8mm Flat Washers Front (4) 8mm Nylon Lock Nuts (Fig 8) Bolt outer wing to center Grille Guard (Passenger side installation pictured) (Fig 9) Remove license plate and bracket (if equipped).
- Page 6 BLACK FRONT RUNNER GRILLE GUARD FOR 15-17 FORD TRANSIT VAN (FULL SIZE) (2) 8mm x 40mm Hex Bolts (2) 8mm Lock Washers (2) 8mm Flat Washers Insert Bolts through Bracket, Tube Spacers then into bumper Front Fig 12 (2) 6mm Button Head Bolts (2) 6mm Lock Washers (2) 6mm Flat Washers (Fig 13) Attach Support Bracket...
