- Page 1 BULL BAR 2009-15 HONDA PILOT INSTALLATION INSTRUCTIONS BLACK BULL BAR WITH SKID PLATE FOR HONDA PILOT 09-15 PART # BBH1409A-SP Page 1 of 6 2/7/13 (DP...
-
Page 2: Parts List
BULL BAR 2009-15 HONDA PILOT PARTS LIST: Bull Bar 12mm Lock Washers Driver/Left Mounting Bracket 12mm Hex Nuts Passenger/Right Mounting Bracket 10-1.5mm x 30mm Hex Bolts Driver/Left Support Bracket 10mm x 30mm OD x 2.5mm Flat Washers Passenger/Right Support Bracket 10mm Lock Washers 8mm x 25mm Bolt Plates 10mm Hex Nuts... - Page 3 BULL BAR 2009-15 HONDA PILOT a. Info for 2012-13 models only: Hold the lower air dam up in approximate position against the bottom of the (2) Mounting Brackets. Mark the location of the Brackets onto the underside of the air dam. b.
- Page 4 BULL BAR 2009-15 HONDA PILOT Insert Mounting Bracket between frame support and cross member 2012-13 installation pictured with air dam (2012-13 passenger side pictured) in place for instruction purposes only Front 2012-13 driver side pictured Front Fig 2 Loosen but do not remove this factory bolt if needed Fig 3 Front...
- Page 5 BULL BAR 2009-15 HONDA PILOT Mark the Bracket location onto the bottom of the crossmember. Temporarily remove the Bull Bar and Driver/Left Support Brackets. Check backside of crossmember for Support Bracket clearance before drilling. (driver side pictured from below) Passenger/Right Support Bracket Front Fig 7...
- Page 6 BULL BAR 2009-15 HONDA PILOT Front (2) 12-1.75mm x 30mm Coarse Thread Hex Bolts (4) 12mm Flat Washers (2) 12mm Lock Washers (2) 12mm Hex Nuts Install and align the Bull Bar as per instructions, tighten all hardware before marking the area on the splash guard to (Fig 12) 2009-11 pictured cut for clearance.
