- Page 1 TEL：1-866-XANATOS INSTALLATION INSTRUCTIONS PART#: 17FT20MA SPARTAN GRILLE GUARD 2020 FORD TRANSIT VAN (FULL SIZE)
-
Page 2: Parts List
SPARTAN GRILLE GUARD 2020 TRANSIT VAN (FULL SIZE) PARTS LIST: Spartan Grille Guard Center 12mm Lock Washers Driver/Left Modular Wing 12mm Hex Nuts Passenger/Right Modular Wing 8-1.25mm x 40mm Hex Bolts Driver/Left Frame Mounting Bracket 8-1.25mm x 30mm Hex Bolts Passenger/Right Frame Mounting Bracket 18 8mm x 24mm OD x 2mm Flat Washers Support Bracket... - Page 3 SPARTAN GRILLE GUARD 2020 TRANSIT VAN (FULL SIZE) 8. Select the Front Support Bracket, (Figure 11). Hold the Bracket in position over the Tube Spacers. Insert (2) 8mm x 40mm Hex Bolts, (2) 8mm Lock Washers and (2) 8mm Flat Washers through the Bracket, Tube Spacers and into the bumper, (Figure 12).
- Page 4 SPARTAN GRILLE GUARD 2020 TRANSIT VAN (FULL SIZE) 12mm x 32mm Large Flat Washer Front (Fig 4) remove (2) inner bumper (Fig 5) Driver side bracket bolts (driver side pictured) Mounting Bracket 12mm x 32mm Large Flat Washer Front (Fig 6A) Insert 12mm x 32mm Large Flat Washer between Mounting Bracket and bumper bracket (Fig 6B) Use 12mm x 32mm Large Flat Washer for a spacer on lower mounting bolt only...
- Page 5 SPARTAN GRILLE GUARD 2020 TRANSIT VAN (FULL SIZE) (4) 8mm x 30mm Hex Bolts (8) 8mm Flat Washers Front (4) 8mm Nylon Lock Nuts (Fig 8) Bolt outer wing to center Grille Guard (Passenger side installation pictured) (Fig 9) Remove license plate and bracket (if equipped).
- Page 6 SPARTAN GRILLE GUARD 2020 TRANSIT VAN (FULL SIZE) (2) 8mm x 40mm Hex Bolts (2) 8mm Lock Washers (2) 8mm Flat Washers Insert Bolts through Bracket, Tube Spacers then into bumper Front Fig 12 (2) 6mm Button Head Bolts (2) 6mm Lock Washers (2) 6mm Flat Washers (Fig 13) Attach Support Bracket to bottom of Grille Guard...
