- Page 1 Triple Monitor Mount 27” GMF003 75x75/100x100 (1.5~10kg)x3 (3.3~22lbs)x3 RATED support@walielectric.com...
- Page 3 Supplied Parts List Lower Pole Pole Base Upper a1 (x1) a2 (x1) b (x1) c (x1) Monitor Arm VESA Plate M5X14 Bolt M5X8 Bolt d (x1) e (x3) f (x4) g (x4) M6 Nut M4x12 Bolt M4x30 Bolt Spacer h (x3) i (x12) j (x12) k (x12)
- Page 4 Step 2 Install the Lower Pole to the Weighted Base using M5x14 Bolts and corresponding M5x8 Bolts , and tighten using the Allen Key Step 3 Loosen the screw on the Lower Pole with Allen key 2mm o . Connect Lower Pole to Upper Pole and tighten the screw with Allen key 2mm o to fix the two poles.
- Page 5 Step 5 Step 5.1 Step 5.2 Select TV Screws Select Spacers ( if needed ) M4x12 M4x30 Step 5.3a Step 5.3b For Monitor with Curved or For Monitor with Flat Back Recessed Back...
- Page 6 Step 6 Put the assembled TV/Monitor onto the Monitor Arms d & and tighten the VESA Plate e with M6 Nut h for stability. Step 7 If one monitor is lower, remove the Nut h and turn the bolt counter-clockwise using Allen key 3mm o to raise the monitor.
- Page 7 Step 8 Manually swivel, tilt, and rotate the monitor for the best viewing angle. Guide the cable through the clip holder and store the Allen Key in the holder. Notice: Please make sure the M6 nut is installed before you rotate the monitor. 45°...
