Summary of Contents for Wali GMF004
- Page 1 Quad Monitor Mount 27” GMF004 75x75/100x100 (1.5~10kg)x4 (3.3~22lbs)x4 RATED support@walielectric.com...
- Page 3 Supplied Parts List Lower Pole Pole Base Upper a1 (x1) a2 (x1) b (x1) d (x2) VESA Plate M5X14 Bolt M5X8 Bolt M6 Nut e (x4) f (x4) g (x4) h (x4) M4x12 Bolt M4x30 Bolt Spacer Tool Holder i (x16) j (x16) k (x16) l (x2)
- Page 4 Step 2 Install the Lower Pole to the Weighted Base using M5x14 Bolts and corresponding M5x8 Bolts , and tighten using the Allen Key Step 3 Loosen the screw on the Lower Pole with Allen key 2mm o . Connect Lower Pole to Upper Pole and tighten the screw with Allen key 2mm o to fix the two poles.
- Page 5 Step 5 Step 5.1 Step 5.2 Select TV Screws Select Spacers ( if needed ) M4x12 M4x30 Step 5.3a Step 5.3b For Monitor with Curved or For Monitor with Flat Back Recessed Back...
- Page 6 Step 6 Place the assembled TV/Monitor onto Arm , tighten the VESA Plate with M6 Nut for stability. Adjust the VESA Plate using Allen Key to move it laterally along the Arm Step 7 Swivel: Manually adjust swivel angle. (Swivel 0°/+90°, no Rotate: Manually adjust rotation angle.
- Page 7 Step 8 Guide the cable through the clip holder and store the Allen Key in the holder. Notice: Please make sure the M6 nut is installed before you rotate the monitor.
