SPECIFICATIONS
CONSTRUCTION
Case: High Impact Polycarbonate
Ventilation: 110 cu ft/min air volume
Acoustic rating: 50dB(A)
Weight: 13 lbs.
ELECTRICAL
Voltage required: 120VAC 60Hz
Power consumption: 250 Watts max
Current usage: 2.0 amps
LAMP
Type: Quartz-halogen, proprietary design
Lamp life: 400-700 hrs average
WARRANTY
One year limited warranty, excluding lamp
Listing
UL file number E220601
79-15017-00 REV C0
2004-AS
OWNER'S MANUAL
www.srsmith.com
CONTROL SEQUENCE
1. From off to on the first time.
Light on, color wheel
stationary with the color
wheel at position it was on
when turned off. (#2 to #1)
2. Toggle from on to off to on.
Light on, color wheel moves
to white, pauses, then
continues rotating. (#1 to
#2 to #1)
3. Toggle from on to off to on.
Light on, color wheel stops
on the desired color.
(Another toggle will start the
color wheel rotating again.)
(#1 to #2 to #1)
4. From on to off.
Light off, color wheel off.
Sets the color that will come
on when initially turned on
again. (#1 to #2)
NOTES:
1. FOR EXTERNAL AUTO
CONTROL YOU MUST LEAVE
TOGGLE SWITCH IN THE "ON
POSITION.
