JUMP STAND W/JIG
6' 68-209-586
ALL MINIMUM WATER ENVELOPE DIMENSIONS FOR RESIDENTIAL INGROUND SWIMMING
POOLS MUST MEET THE ANSI/NSPI-5 2003 AMERICAN NATIONAL STANDARD FOR
RESIDENTIAL INGROUND SWIMMING POOLS (REFERENCED THROUGHOUT THESE
ASSEMBLY AND INSTALLATION INSTRUCTIONS AS "ANSI/NSP-5 2003"). COMPLY WITH
LOCAL GOVERNMENT REGULATIONS IF THEY EXCEED ANSI/NSPI STANDARDS.
All diving boards and related equipment are manufactured for inground swimming pools ONLY. The
S.R. Smith Frontier II Jump Stands are designed to be easily transported and installed. Follow all
instructions carefully and inspect closely to assure proper and safe installation.
PROPER INSTALLATION CANNOT BE OVERSTATED. IMPROPER INSTALLATION VOIDS S.R.
SMITH'S WARRANTY AND MAY AFFECT THE SAFETY OF THE USER.
ASSEMBLY AND INSTALLATION INSTRUCTIONS
WESTERN SALES AND MANUFACTURING PLANT
THESE INSTRUCTIONS MUST REMAIN WITH STAND OWNER
06-305
1/2 METER
FRONTIER II
STEEL STAND COMPLETE
CAUTION
– PLEASE READ CAREFULLY –
CORPORATE HEADQUARTERS
P.O. Box 400 • 1017 S.W. Berg Parkway
Canby, Oregon 97013
Phone (503) 266-2231 • Fax (503) 266-4334
EASTERN MANUFACTURING PLANT
105 Challenger Drive
Portland, Tennessee 37148
Phone (615) 325-0770 • Fax (615) 325-0775
www.srsmith.com
ATTENTION!
8' 68-209-588
AUG06
