- Page 1 BYOS 2 SLIDE SYSTEM ™ ( BUIL D YOUR OWN SL IDE) ASSEMBLY & INSTALLATION INSTRUCTIONS S.R.Smith, LLC Canby, Oregon | 800.824.4387 Tucson, Arizona | 800.737.5386 srsmith.com Copyright© 2019 S.R.Smith. All rights reserved. SBK-BYOS2 INSTALL | 0419...
- Page 2 Failure to properly install this product could result in a dangerous condition, including but not limited to electrical and or structural hazards. S.R.Smith. disclaims all liability arising from the installation and the user assumes all risk associated with the installation.
-
Page 3: Table Of Contents
Step 8: Final Slide Position ......................13-15 Step 9: Pour Concrete Piers ......................15 Step 10: Connect Water Supply ......................15 Flume & Anchor Support Hardware....................16 Slide Care & Maintenance ........................17 Copyright ® 2019 S.R.Smith, LLC All rights reserved. | srsmith.com SBK-BYOS2 INSTALL | 0419... -
Page 4: Byos 2 Liability Disclaimer
• Minimum recommended head clearance above the slide pathway is 7 feet. • Minimum BYOS 2 water envelope is 7’ wide (centered on slide) x 13.5’ long x 4.5’ deep . • The exit section must be installed with the correct alighnmenet to the pool edge with a minimum overhang of 3”... -
Page 5: Intended Use Instructions
POSITION ONLY CAN RESULT SWIMMERS ONLY Face forward on the slide, holding the legs and arms with the palms of your hands forward and tilted up. Copyright ® 2019 S.R.Smith, LLC All rights reserved. | srsmith.com SBK-BYOS2 INSTALL | 0419... -
Page 6: Water Safety Envelope
(NOT TO SCALE) Minimum Slide Clearance Area DIAGRAM C (NOT TO SCALE) Minimum Water Safety Envelope ALL SLIDES SHOULD BE BONDED Check your local electrical code requirements. Copyright ® 2019 S.R.Smith, LLC All rights reserved. | srsmith.com SBK-BYOS2 INSTALL | 0419... -
Page 7: Sl Id E Plac E Me Nt
Refer to the Diagram F below. 3” MINIMUM OVERHANG DIAGRAM F (NOT TO SCALE) NOTE: The exit point of the flume can be no higher than 20” above the water. Copyright ® 2019 S.R.Smith, LLC All rights reserved. | srsmith.com SBK-BYOS2 INSTALL | 0419... -
Page 8: Getting Started
It is important to note however, that S.R.Smith does not approve or accept liability for BYOS 2 designs. All designs should be checked by a licensed Civil or Structural Engineer in your state, and when necessary, inspected/approved by the applicable local governing agency. -
Page 9: Tools Required
I N S TA L L AT I O N I N S T R U C T I O N S B YO S 2 S L I D E L IST OF R E Q UIR E D TO O LS Tools required for assembly and installation of BYOS 2 slide: 1. 3/8” Drive Ratchet 5. Torque Wrench 2. - Page 10 25 ft lbs is reached on each bolt. Do not over tighten. Using greater force may fracture the fiberglass. Tightening the bolts in this sequence is necessary to compress the gasket evenly. FIG. 3 Copyright ® 2019 S.R.Smith, LLC All rights reserved. | srsmith.com SBK-BYOS2 INSTALL | 0419...
-
Page 11: Step 3: Entry Section Anchor Assembly
Attach handrails first. Handrails are directional; the side with the 2 bends faces away from the pool. (Fig. 4) The BYOS 2 Frame Support consists of 1 entry frame support, 1 right support arm and 1 left support arm. The assembly is attached to the BYOS 2 Entry Section with the hardware kit BYOS2-101-SS. - Page 12 TIP: Once all the flume sections are assembled and the flange bolts are correctly tightened, do a water test with a garden hose to ensure there are no flume to flume leaks. FIG. 10 FIG. 11 FIG. 12 FIG. 13 Copyright ® 2019 S.R.Smith, LLC All rights reserved. | srsmith.com SBK-BYOS2 INSTALL | 0419...
-
Page 13: Step 4: Byos 2 20˚ Anchor Information
The following information is for the BYOS 2 20˚ anchor and should be reviewed before proceeding onto the next step. Our 20˚ anchor is designed to allow easier use with concrete tube forms. The length of our BYOS 2 flume anchors allow room for concrete chutes when using concrete tube forms in a BYOS 2 installation. This anchor design will provide more flexibility in installation options and make your BYOS 2 installations even easier. -
Page 14: Step 6: Excavate The Holes
ENTRY FRAME 24” x 24” x 12” 18” Tube at 24” Depth FLUME SUPPORTS 24” 24” x 24” x 12” 12” 18” Tube at 24” Depth Copyright ® 2019 S.R.Smith, LLC All rights reserved. | srsmith.com SBK-BYOS2 INSTALL | 0419... -
Page 15: Step 8: Final Slide Position
Utilize an angle finder along the centerline of the flume ensure the flume is at the correct angle. Check the angle along the centerline of the flume only. (Fig. 18) (Continued on next page) FIG. 18 Copyright ® 2019 S.R.Smith, LLC All rights reserved. | srsmith.com SBK-BYOS2 INSTALL | 0419... - Page 16 • At this point the entire slide should be assembled, anchor supports attached and all bolts correctly tighten. The slide should be blocked up in its approximate horizontal and vertical position. (Continued on next page) Copyright ® 2019 S.R.Smith, LLC All rights reserved. | srsmith.com SBK-BYOS2 INSTALL | 0419...
-
Page 17: Step 9: Pour Concrete Piers
STEP 10: CONNECT WATER SUPPLY SYSTEM The BYOS 2 slide can be plumbed with rigid 1” PVC pipe or with 1” Flex PVC, you may find that Flex PVC works best. Glue and slip pipe into the 1” female fittings on the underside of the Entry section. (Fig. 23 & 24) Use PVC primer and glue (not included) as required. -
Page 18: Flume & Anchor Support Hardware
B YO S 2 S L I D E BYOS 2 FLU ME & A NC H O R S UPPO RT HA RDWAR E The entry frame support anchor comes with a part specific hardware kit. Use hardware set BYOS2-101-SS. -
Page 19: Slide Care & Maintenance
B YO S 2 S L I D E BYOS 2 S L ID E C A R E & MA INTE NANC E Your BYOS slide requires periodic maintenance to keep it looking like new and protected from the elements. - Page 20 I N S TA L L AT I O N I N S T R U C T I O N S B YO S 2 S L I D E NOTES: Copyright ® 2019 S.R.Smith, LLC All rights reserved. | srsmith.com SBK-BYOS2 INSTALL | 0419...
