- Page 1 Superior 47 Kettle grill OUTDOOR USE ONLY! Read the operating instructions and warnings before using the appliance. FCC-C-22047 Assembly, maintenance and safety...
-
Page 3: The Story Of Fcc
THE STORY OF FCC The Flying Culinary Circus is the world’s first traveling cooking group. In 2005 Trond, Hans-Kristian, Mathias, and Tor went to New York. A journey that ended up being an adventure of a lifetime. With 65 countries and 300,000 hours of culinary experience in the Chef... -
Page 4: Table Of Contents
CONTENTS The story of FCC................3 Read before assembly ..............5 Safety and warnings ..............6 Correct amount of charcoal ............8 Parts list ..................9 Assembly instructions ............10 Lighting methods ..............16 Using the grill ................18 Maintenance ................18 Consumer Contact ..............20 Superior... -
Page 5: Read Before Assembly
If the grill is damaged during transport, do not assemble the grill before contacting your dealer or support@fccproducts.no. Transport damage to parts, varnish or paint must be reported to the dealer or FCC Products before mounting and using the grill. If damage is reported after, there is a possibility that damage may have occurred during assembly. -
Page 6: Safety Information
SAFETY INFORMATION! • KEEP CHILDREN, ANIMALS AND OTHERS WHO NEEDS SUPERVISION AT A SAFE DISTANCE FROM THE GRILL . THE GRILL CAN BE EXTREMELY HOT. • NEVER MOVE THE GRILL ONCE LIT OR WHILE IT IS STILL HOT. • DO NOT TOUCH THE GRILL BODY WHEN LIT, IT CAN BE EXTREMELY HOT AND THERE IS A RISK OF BURNS. - Page 7 WARNINGS! ● For outdoor use only! Do not use under awnings, canopies, parasols or the like. ● Place the grill on a firm, even and stable surface at a safe distance from buildings, trees and other flammable materials. ● Never move the grill when in use. ●...
-
Page 8: Correct Amount Of Charcoal
RECOMMENDED AMOUNT OF CHARCOAL 1,5 kg RECOMMENDED AMOUNT OF CHARCOAL 1,8 kg MAXIMUM AMOUNT OF CHARCOAL 1,8 kg RECOMMENDED AMOUNT OF BRIQUETTES 2,2 kg MAXIMUM AMOUNT OF BRIQUETTES NOTE! NEVER OVERFILL THE GRILL WITH CHARCOAL AS IT MAY DAMAGE THE LACQUERED SURFACES. -
Page 9: Parts List
PARTS LIST CODE IMAGE CODE IMAGE CODE IMAGE DESCRIPTION M6x12 , Washer and nut M6x30 Screw and washer for leg M8 Wheel nut and washer M5x16 Screw... -
Page 10: Assembly Instructions
ASSEMBLY Place a piece of cardboard on the floor (e.g the outer carton) to prevent scratching the unit and parts during assembly. STEP 1 Assemble the handles using 2 pcs of screw E, as shown. This step is the same for all 3 handles. M5x16 STEP 2 Mount the handle for the lid with 2 pcs of screw A, set. - Page 11 ASSEMBLY STEP 4 Mount the charcoal grate support (part 6) to part 7 and 9 using 2 pcs of screw A combo. Mount all 3 parts in the same way. Do not tighten! M6x12 M6x30 STEP 5 Insert the bottom shelf (part 11) into the front leg and into the holes in the other two legs. Mount the air vent (part 10) to the fire bowl using 1 pc of screw A set.
- Page 12 ASSEMBLY STEP 6 Mount the wheels (part 12) using 2 pcs of nute and washer D set. Place the wheel cap (part 20) after tightening the nuts. Superior...
- Page 13 ASSEMBLY STEP 7 Place part 13 into the slots in the leg mountings. STEP 8 Insert part 14 into part 15 by slightly pushing part 14 together. Align the ends of part 14 with the holes in part 15 (the ashtray), then insert the handle into the groove along the edge.
- Page 14 ASSEMBLY STEP 9 Then put the charcoal guard grid (part 17) into the bottom of the fire bowl. Place the cooking grid (part 16) on top of the fire bowl. The handles for cooking grid (part 18) kan be used to remove cooking grid to refill coal. Superior...
- Page 15 ASSEMBLY STEP 10 Final check: Ensure that all screws are tightened. The grill is now ready to use.
-
Page 16: Lighting Methods
LIGHTING METHODS DURING LIGHTING Always have the lid off or open during lighting. Never close the lid before the flames from the charcoal have died down, to avoid damaging the lid surface. NB: Only use the lid to suppress flames if the flames are getting out of control. Painted surfaces can be damaged by extreme heat. -
Page 17: Using The Grill
USING THE GRILL ● Read page 8 for correct amount of charcoal. ● Do not overfill the grill with charcoal. The grill can get too hot for cooking and the heat can represent a risk to people or animals in the vicinity. ●... -
Page 18: Maintenance
IMPORTANT THIS GRILL IS MADE OF PAINTED STEEL WHICH CAN RUST ON SURFACE AND JOINTS. THIS DOES NOT AFFECT THE FUNCTIONALITY OF THE GRILL. TO MINIMIZE RUST FORMATIONS MAKE SURE: ● Not to exceed recommended quantities of charcoal stated in the user manual. ●... - Page 19 NOTES...
-
Page 20: Consumer Contact
+ carriage and administration fee. If new parts are needed or in the event of a warranty claim, please contact your dealer or consumer contact: FCC Products AS Kjeller vest 3, 2007 Kjeller, Norway +47 924 78 600 Support opening hours: Mon–Fri 10:00–14:00...
