  • Page 1 REGISTER GRILL FOR GRILL OUTDOOR USE ONLY EXTENDED WARRANTY ASSEMBLY VIDEO WARRANTY: Read the manual, follow the assembly instructions step by step. Get to know your barbeque and the safety instructions before using the appliance. FCC-G-22620-41 / K114BDF3 Assembly, maintenance and safety...
  • Page 2 Mansion 4.1s...

  • Page 3: The Story Of Fcc

    The Flying Culinary Circus is the world’s first traveling cooking group. In 2005 Trond, Hans-Kristian, Mathias, and Tor went to New York. A journey that ended up being an adventure of a lifetime. With 65 countries and 300,000 hours of culinary experience in the Chef whites, we have developed, designed, and produced a wide range of grills and accessories that add something new and unique to the grill range in Scandinavia.

  • Page 4: Table Of Contents

    CONTENTS The story of FCC................3 Warnings ..................5 Technical Data ................6 Read before assembly ...............7 Parts List ..................8 Exploded Drawing ..............9 Assembly Instructions ............10 Regulator and Hose - Connecting the gas ......22 Check for leaks .................23 Lighting Instructions..............24 Last Check...................25 Maintenance ................26...

  • Page 5: Warnings

    WARNINGS! ● Accessible parts of the grill become very hot during use. Keep children and others who need supervision at a safe distance. ● The grill is intended for outdoor use only in well-ventilated areas. ● Leak tests (see page 23) must always be carried out before the grill is used and when replacing the gas cylinder.

  • Page 6: Technical Data

    TECHNICAL DATA Total Heat input: 17 kW Gas consumption: 1236 gram/hour Gas cylinder (not included): Use standard cylinder approved for use in the Nordic Region. Even though butane and propane gas can be used, we recommend propane for use in the Nordic Region.

  • Page 7: Read Before Assembly

    If the grill is damaged during transport, do not assemble the grill before contacting your dealer or support@fccproducts.no. Transport damage to parts, varnish or enamel must be reported to the dealer or FCC Products before mounting and using the grill. If damage is reported after, there is a possibility that damage may have occurred during assembly.

  • Page 8: Parts List

    PARTS LIST CODE DESCRIPTION THERMOMETER LID HANDLE WARMING RACK CAST IRON GRILL WITH MGS OPENING CAST IRON GRILL HEAT DISTRIBUTION PANEL / FLAME TAMERS TUBE BURNER GREASE CUP GREASE CUP HOLDER DRIP TRAY FIREBOX ASSEMBLY SIDE BURNER LID SIDE BURNER COOKING GRID SIDE BURNER ASSEMBLY CART FRONT BEAM CART LEFT SIDE PANEL...

  • Page 9: Exploded Drawing

    EXPLODED DRAWING...

  • Page 10: Assembly Instructions

    ASSEMBLY Place a piece of cardboard (e.g the grill carton) on the floor to prevent scratching the unit and parts during assembly. Turn bottom panel of cabinet (19) upside down, and attach castors (22) with a wrench. Loosen the preassembled screws on bottom panel (19) and slide on the side panels (17 &...
  • Page 11 ASSEMBLY Fix rear panel (18) to the bottom and side panels using 4xscrew B Loosen the preassembled screws in front of the cart and slide on the triangiular support brackets (21), then tighten the screws.
  • Page 12 ASSEMBLY Attach the cart front beam (16) to the side panels with 4x screw A. Fix the thermometer (2) to the lid using the washer and wing- nut. Push the knobs for main burners (25) and side burner (24) onto the control panel. Put the firebox assembly (16) on top of the trolley.
  • Page 13 ASSEMBLY Secure the firebox assembly with 4x screw B. Screw in all the screws before tightening!
  • Page 14 ASSEMBLY 1 Loosen the pre-assembled screws on the left side of the firebox. 2 Align the side table to the screws and slide it on. 3 Then thighten the screws. Mansion 4.1s...
  • Page 15 ASSEMBLY Secure side tables by fixing 2x screw B wit 2x washer D from the insixe of the firebox.
  • Page 16 ASSEMBLY 1 Loosen the pre-assembled screws on the right side. 2 Align the side table to the screws and slide it on. 3 Then thighten the screws. Secure right side table with 2x screw B and 2x washer D from the inside of the firebox. Mansion 4.1s...
  • Page 17 ASSEMBLY 1 Loosen the screws on side burner. 2 Slide the burner unit on the bracket and 3 thighten the screws. 4 Then attach it to the side burner table. Remember to attach the side burner lighting wire.
  • Page 18 ASSEMBLY 1 The gas connection bracket and hose is attached behind the control panel with a cable tie. Cut the cable tie carefully with a scissor. 2 Fix the bracket with gas intake to the side panel using 1x screw A. 1 xA Mansion 4.1s...
  • Page 19 ASSEMBLY Enter 2x hinge pins C into the bottom plate. To install the doors, align the hole under the door to the hinge on bottom panel. The hinge on top is spring-loaded. Press it up and align the hole on top of the door so the hinge snap into the hole.
  • Page 20 ASSEMBLY Fix the grease cup holder to the drip tray with 2x screw A. Then slide the grease onto the cup holder. Insert the assembled drip tray into the grill body on the rear side of the bbq. Mansion 4.1s...
  • Page 21 ASSEMBLY 1 Align the flame tamers on the grooves inside the firebox. 2 Insert the cast iron grills. 3 Place the warming rack. Add a regulator and hose (sold separately). Do not use the bbq while the gas cylinder is inside the cabinet. Read more about regulator and hose on the next page.

  • Page 22: Connecting Gas

    CONNECTING GAS FOLLOW THESE INSTRUCTIONS CAREFULLY TO AVOID SERIOUS DAMAGE TO YOUR GRILL AND CAUSE PERSONAL INJURY. HOSE • Connect the gas hose to the gas inlet on the grill. Tighten well. • Install the regulator and hose. Follow the installation instructions that came with the controller set.

  • Page 23: Gas Leak Test

    If detected leakage cannot be rectified, do not attempt to cure leakage but consult your dealer or FCC Products at support@fccproducts.no for help in solving the problem. Leak test must be done regularly and every time the gas cylinder, regulator or hose is replaced.

  • Page 24: Manual Lighting

    LIGHTING INSTRUCTIONS LIGHTING INSTRUCTIONS Always keep the lid open when lighting the grill. Never bend over the grill when lighting it and protect your face in the event of a flare-up. 2. Make sure that all switches are in the OFF position. Open the gas valve on the regulator. 3.

  • Page 25: Final Check

    LIGHTING INSTRUCTIONS LIGHTING THE SIDE BURNER Open the lid of the side burner. 2. Make sure all the burner knobs are in the OFF position. Open the gas valve of the gas cylinder. 3. Press and turn the knob slowly to the left to the HI position until you hear a click. This will generate a spark to the electrode prongs and ignite the burners.

  • Page 26: Maintenance

    MAINTENANCE KEEP THE FIREBOX, FLAME TAMERS, COOKING GRATE AND ACCESSORIES CLEAN TO AVOID GREASE FIRES. IF A GREASE FIRE OCCUR Do not leave the grill when it is lit and close the gas supply as soon as possible if there is a sign of In case of grease fire, close the gas supply on the a grease fire.
  • Page 27 MAINTENANCE FIRES CAUSED BY FAT, CAN DAMAGE THE METAL, PAINT AND ENAMEL. DAMAGE TO THE GRILL CAUSED BY FAT BURNING, IS NOT COVERED BY THE GUARANTEE AS IT IS DUE TO INCORRECT USE. CLEANING COOKING GRATE OG FLAME TAMERS All cleaning and maintenance must be performed Grill grate and flame tamers are brushed when the grill is cold.

  • Page 28: Advice, Tips And Safety

    • We recommend the use of FCC original covers for the best possible protection against rain, pol- len and pollution. Remember that the grill must be completely dry and cold before applying the coating.

  • Page 29: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Empty gas cylinder Replace gas cylinder D amaged regulator Check/replace the regulator Burner is blocked Clean the burner Gas supply is blocked Clean gas ventury or hose BURNER WILL NOT LIGHT Electrode is broken or dirty Clean the electrode Place the grill in a less expo- Windy conditions...

  • Page 30: Multi Grill System

    ACCESSORIES SOLD SEPARATELY, AVAILABLE AT YOUR BBQ DEALER MULTI GRILL SYSTEM MULTI GRILL SYSTEM GIVES YOU NEW WAYS TO ENJOY YOUR BARBECUE TIME! Using various MGS accessories like a wok, frying pan, pizza stone, cooking plate, and searing grid on a grill can significantly expand your outdoor cooking options. Here are three good reasons for using MGS accessories: CULINARY VERSATILITY Each of these MGS accessories serves a specific purpose,...
  • Page 31 ACCESSORIES SOLD SEPARATELY, AVAILABLE AT YOUR BBQ DEALER SEARING GRID COOKING PLATE FRYING PAN PIZZA STONE/GLAZED PIZZA STONE Enamelled cast iron wok which cooks the food energy efficiently and preserves the nutritional content. Sauces and soups can now also be prepared on the grill. FRYING PAN Gives you the option between high heat stir-fry meat grilling, or lower heat for stews, omelets, seafood and vegetables.

  • Page 32: Warranty Claim

    Scan code to reach Consumer contact: Always attach your receipt and product serial number when making a warranty claim. Produced in China for FCC Products. We are always looking for ways we can improve our products. Therefore, we reserve the right to change technical specifications at any time.
