Summary of Contents for FCC X-Grill II 2.0
- Page 1 X-Grill II 2.0 Compatible with Trolley* SCAN QR CODE AND SCAN QR CODE FOR OUTDOOR USE ONLY! REGISTER GRILL FOR GRILL EXTENDED WARRANTY ASSEMBLY VIDEO Read the operating instructions and warnings WARRANTY: before using the appliance. FCC-XG-25200-20 Assembly, maintenance and safety...
-
Page 3: The Story Of Fcc
THE STORY OF FCC The Flying Culinary Circus is the world’s first traveling cooking group. In 2005 Trond, Hans-Kristian, Mathias, and Tor went to New York. A journey that ended up being an adventure of a lifetime. With 65 countries and 300,000 hours of culinary experience in the Chef... -
Page 4: Table Of Contents
CONTENTS The story of FCC................3 Warnings ..................5 Technical data ................6 Read before assembly ...............7 Parts list ..................8 Exploded drawing ..............9 Assembly instructions ............10 Assemble X-Grill on Trolley .............16 Regulator and Hose - Connecting the gas ......20 Check for leaks before using the grill ........21 Lighting instructions ...............22... -
Page 5: Warnings
WARNINGS ● Accessible parts of the grill become very hot during use. Keep children and others who need supervision at a safe distance. ● The grill is intended for outdoor use only in well-ventilated areas. ● Leak tests (see page 21) must always be carried out before the grill is used and when replacing the gas cylinder. -
Page 6: Technical Data
Ø 0.90 mm I3P(30)G31(Propane) I3B/P(30) HU, IT, LT, NL, NO, RO, SE, SI, SK, HR, TR, BG, IS, LU, MT, MK, GB, GR, LV, IS 1336-24 The product is manufactured in accordance with European Gas Appliances Regulation (EU) 2016/426 X-Grill II 2.0... -
Page 7: Read Before Assembly
If the grill is damaged during transport, do not assemble the grill before contacting your dealer or support@fccproducts.no. Transport damage to parts, varnish or enamel must be reported to the dealer or FCC Products before mounting and using the grill. If damage is reported after, there is a possibility that damage may have occurred during assembly. -
Page 8: Parts List
FEET TYPE A SIDE SHELF SUPPORT BRACKET B GREASE CUP SUPPORT BRACKET FIRE BOX SUPPORT BRACKET COOKING GRILL GREASE CUP SIDE SHELF SUPPORT BRACKET A BACK PANEL GREASE CUP HEAT INSULATION PLATE SIDE TABLE REINFORCING PLATE LID INSULATION BOARD X-Grill II 2.0... -
Page 9: Exploded Drawing
EXPLODED DRAWING CODE HARDWARE IMAGE SCREW M5X12 SCREW FOR INSULATION PLATE WASHER M5 FLANGE NUT M5 SPANNER... -
Page 10: Assembly Instructions
Hinweis: Bringen Sie die beiden Fettauffangschalen-Halterungen (27) und die Attach both grease tray bracket’s part 24 and grease tray insulation plates part 30 Fettauffangschalen-Isolierplatten (29) an. with 4 pcs A screws. Note: Attach both grease tray brackets (27) and Grease tray isolation plates (29). X-Grill II 2.0... - Page 11 4 x B 4 x B ASSEMBLY Hinweis: Befestigen Sie den kompletten Deckelgriff (5, 6, 7) am Deckel (1). Hinweis: Befestigen Sie den kompletten Deckelgriff (5, 6, 7) am Deckel (1). Note: Attach the complete lid handle (5, 6, 7) to the lid (1). Note: Attach the complete lid handle (5, 6, 7) to the lid (1).
- Page 12 2. Align the lid so that both hinges on the firebox are at the same height, and insert the pin of the lid mount through the lid and the hinge on the grill. Reattach the lock as it was originally positioned. Locked Unlocked Removed X-Grill II 2.0...
- Page 13 ASSEMBLY Hinweis: Stecken Sie die Bedienknöpfe (19) auf das Bedienfeld (20). Attach the control knobs part 17 to the control panel part 18. Hinweis: Stecken Sie die Bedienknöpfe (19) auf das Bedienfeld (20). Note: Attach the control knobs (19) to the control panel (20). Note: Attach the control knobs (19) to the control panel (20).
- Page 14 Do not change the position of the grids when they are hot. There is a risk of suffering burns. Use the lifting arm to change grid Lifting arm position. NOTE! Do not change the position of the grids when they are hot. There is a risk of suffering burns. X-Grill II 2.0...
- Page 15 ASSEMBLY Attach the side tables, part 9. Hinweis: Hängen Sie die Seitenablagen (10) ein. Note: Attach the side tables (10). NOTE! Assembly is now complete. All joints and connections must now be leak tested before using the grill. Perform a leak test annually, and whenever the gas bottle is removed or replaced.
-
Page 16: Assemble X-Grill On Trolley
Platzierung vom Grillgerät auf dem Grillwagen Placing the barbecue on the cart X-Grill II is compatible with FCC Trolley (sold separately). Hinweis: Lösen Sie die Flügelschrauben und nehmen Sie die Fußkappen A & B vom Gerät ab. Diese Teile werden mit dem Grillgerät geliefert. - Page 17 ASSEMBLE X-GRILL II ON TROLLEY* Hinweis: Stecken Sie die Bedienknöpfe (19) a The side tables can be fastened in the slots under the main attachment for the side table. Note: Attach the control knobs (19) to the co...
- Page 18 Lesen Sie unbedingt gründlich die Bedienungs- und Montageanleitung vom Grillgerät durch, bevor Sie dieses auf dem Grillwagen in Betrieb nehmen. It is essential that you read the operating and assembly instructions for the barbecue thoroughly, before putting it into operation on the barbecue cart. X-Grill II 2.0...
- Page 19 ASSEMBLE X-GRILL II ON TROLLEY*...
-
Page 20: Connecting Gas
If the hose is too tight to thread onto the gas nipple, use soap at the tip of the hose. Never use flammable liquids. Alternatively, dip the tip of the hose in boiling water, and the hose will expand. X-Grill II 2.0... -
Page 21: Gas Leak Test
If detected leakage cannot be rectified, do not attempt to cure leakage but consult your dealer or FCC Products at support@fccproducts.no for help in solving the problem. Leak test must be done regularly and every time the gas cylinder, regulator or hose is replaced. -
Page 22: Manual Lighting
IF THE BURNER DOES NOT IGNITE, TURN THE SWITCHES TO THE OFF POSITION (CLOSE THE GAS SUPPLY) AND WAIT 5 MINUTES BEFORE TRYING TO IGNITE AGAIN. IF THE GRILL STILL DOES NOT LIGHT WITH NORMAL OR MANUAL METHOD, READ THE TROUBLESHOOTING TABLE OR CONTACT YOUR DEALER. X-Grill II 2.0... -
Page 23: Placement Of The Grill
FINAL CHECK PLACEMENT OF THE GRILL • Ensure that the grill is placed at least 150 cm in all directions from house walls, trees, plants and other flammable materials or liquids when in use. • Do not place the grill under a roof or overhang. •... -
Page 24: Maintenance
Make sure that all burners are positioned exactly over the locks before you press the burners down to secure them. X-Grill II 2.0... - Page 25 MAINTENANCE FIRES CAUSED BY FAT, CAN DAMAGE THE METAL, PAINT AND ENAMEL. DA- MAGE TO THE GRILL CAUSED BY FAT BURNING, IS NOT COVERED BY THE GUARANTEE AS IT IS DUE TO INCORRECT USE. CLEANING COOKING GRATE OG FLAME TAMERS All cleaning and maintenance must be performed Grill grate and flame tamers are brushed regularly when the grill is cold.
-
Page 26: Advice, Tips And Safety
• We recommend the use of FCC original covers for the best possible protection against rain, pollen and pollution. Remember that the grill must be completely dry and cold before applying the coating. -
Page 27: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Empty gas cylinder Replace gas cylinder D amaged regulator Check/replace the regulator Burner is blocked Clean the burner Gas supply is blocked Clean gas ventury or hose BURNER WILL NOT LIGHT Electrode is broken or dirty Clean the electrode Place the grill in a less expo- Windy conditions... -
Page 28: Warranty Claim
Scan code to reach Consumer contact: Always attach your receipt and product serial number when making a warranty claim. Produced in China for FCC Products. We are always looking for ways we can improve our products. Therefore, we reserve the right to change technical specifications at any time.
