- Page 1 Barrel 70E Kettle grill OUTDOOR USE ONLY! Read the operating instructions and warnings before using the appliance. FCC-C-20570E Assembly, maintenance and safety...
-
Page 3: The Story Of Fcc
THE STORY OF FCC The Flying Culinary Circus is the world’s first traveling cooking group. In 2005 Trond, Hans-Kristian, Mathias, and Tor went to New York. A journey that ended up being an adventure of a lifetime. With 65 countries and 300,000 hours of culinary experience in the Chef... -
Page 4: Table Of Contents
CONTENTS The story of FCC................3 Read before assembly ..............5 Safety and warnings ..............6 Correct amount of charcoal ............8 Parts list ..................10 Exploded drawing ..............11 Assembly instructions ............12 Lighting methods ..............18 Maintenance ................19 Consumer Contact ..............20 Barrel... -
Page 5: Read Before Assembly
If the grill is damaged during transport, do not assemble the grill before contacting your dealer or support@fccproducts.no. Transport damage to parts, varnish or paint must be reported to the dealer or FCC Products before mounting and using the grill. If damage is reported after, there is a possibility that damage may have occurred during assembly. -
Page 6: Safety Information
SAFETY INFORMATION! • KEEP CHILDREN, ANIMALS AND OTHERS WHO NEEDS SUPERVISION AT A SAFE DISTANCE FROM THE BARREL . THE BARREL CAN BE EXTREMELY HOT. • NEVER MOVE THE BARREL ONCE LIT OR WHILE IT IS STILL HOT. • DO NOT TOUCH THE BARREL BODY WHEN LIT, IT CAN BE EXTREMELY HOT AND THERE IS A RISK OF BURNS. - Page 7 WARNINGS! ● For outdoor use only! Do not use under awnings, canopies, parasols or the like. ● Place the Barrel on a firm, even and stable surface at a safe distance from buildings, trees and other flammable materials. ● Never move the Barrel when in use. ●...
-
Page 8: Correct Amount Of Charcoal
RECOMMENDED AMOUNT OF CHARCOAL RECOMMENDED AMOUNT OF CHARCOAL 2,3 KG MAXIMUM AMOUNT OF CHARCOAL 2,7 KG RECOMMENDED AMOUNT OF BRIQUETTES 2,4 KG MAXIMUM AMOUNT OF BRIQUETTES 2,9 KG NOTE! NEVER OVERFILL THE BARREL WITH CHARCOAL AS IT MAY DAMAGE THE ENAMELED SURFACES. - Page 9 USING THE BARREL ● Read page 8 for correct amount of charcoal. ● Do not overfill the Barrel with charcoal. The Barrel can get too hot for cooking and the heat can represent a risk to people or animals in the vicinity. ●...
-
Page 10: Parts List
PARTS LIST P A R T S L I S T P A R T S L I S T P A R T S L I S T P A R T S L I S T P A R T S L I S T P A R T S L I S T P A R T S L I S T P A R T S L I S T... -
Page 11: Exploded View
EXPLODED VIEW E X P L O D E D D R A W I N G... -
Page 12: Assembly Instructions
ASSEMBLY Montering Montering A S S E M B L Y Place a piece of cardboard on the floor (e.g the outer carton) to A S S E M B L Y prevent scratching the unit and parts during assembly. STEP 1. - Page 13 ASSEMBLY Montering Montering A S S E M B L Y A S S E M B L Y STEP 3 Mount part 21 bent leg with part 20 wheel leg and part 15 long leg x 2. Place part 22 bottom Montering shelf into the hole in the legs.
- Page 14 Montering Montering A S S E M B L Y A S S E M B L Y ASSEMBLY STEP 5. STEP 5. STEP 5 Place part 19 wheel axel with 2 pcs H washers, 2 pcs 18 wheel with 2 pcs F nuts and thighten both sides.
- Page 15 Montering STEP 7 A S S E M B L Y ASSEMBLY STEP 7 STEP 7 Place the complete lid on the barrel and mount it with 2 pcs A screws and 2 pcs D nuts. Two persons are recommended when performing this step.
- Page 16 STEP 10. ASSEMBLY TEP 10. STEP 9 Mount part 11 side tables with 8pcs A screws, 8 pcs B washers Montering and 8 pcs D nuts. Tip! Do not tighten until all screws A S S E M B L Y are in place.
- Page 17 STEP 11 ASSEMBLY Montering A S S E M B L Y STEP 11 Place part 9 charcoal grate with part 8 charcoal grate handles. Here you can adjust the height of the charcoal grate. Place part 2 cooking grill into the barrel. STEP 11 The grill is now fully assembled.
-
Page 18: Lighting Methods
LIGHTING METHODS We recommend using lighting briquettes, charcoal starter or electric grill starter for lighting charcoal/ briquettes. Lighter fluid is not recommended. DURING LIGHTING Grills with lids: Always have the lid off or open during lighting. Never close the lid before the flames from the charcoal have died down, to avoid damaging the lid surface. -
Page 19: Maintenance
IMPORTANT THIS BARREL IS MADE OF ENAMELLED STEEL AND THE CHASSIS OF LACQUERED STEEL, WHICH CAN RUST ON SURFACE AND JOINTS. THIS DOES NOT AFFECT THE FUNCTIONALITY OF THE BARREL. TO MINIMIZE RUST FORMATIONS MAKE SURE: ● Not to exceed recommended quantities of charcoal stated in the user manual. ●... -
Page 20: Consumer Contact
Scan code to reach Consumer contact: Always attach your receipt and product serial number when making a warranty claim. PRODUCED IN CHINA FOR FCC PRODUCTS. We are always looking for ways we can improve our products. Therefore, we reserve the right to change technical specifications at any time.
