- Page 1 Performance II 3.1 SCAN QR-CODE SCAN QR-CODE AND REGISTER THE GRILL FOR ASSEMBLY OUTDOOR USE ONLY! FOR EXTENDED WARRANTY VIDEO WARRANTY: Read the operating instructions and warnings before using the appliance. FCC-G-24210-31 / GD4236S-B Assembly, maintenance and safety...
-
Page 3: The Story Of Fcc
THE STORY OF FCC The Flying Culinary Circus is the world’s first traveling cooking group. In 2005 Trond, Hans-Kristian, Mathias, and Tor went to New York. A journey that ended up being an adventure of a lifetime. With 65 countries and 300,000 hours of culinary experience in the Chef... -
Page 4: Table Of Contents
CONTENTS The story of FCC................3 Warnings ..................5 Technical data ................6 Read before assembly ...............7 Parts list ..................8 Exploded drawing ..............9 Assembly instructions ............10 Regulator and hose - connecting the gas ......18 Check for leaks before using the grill ........19 Last check ................20... -
Page 5: Warnings
WARNINGS! ● Accessible parts of the grill become very hot during use. Keep children and others who need supervision at a safe distance. ● The grill is intended for outdoor use only in well-ventilated areas. ● Leak tests (see page 19) must always be carried out before the grill is used and when replacing the gas cylinder. -
Page 6: Technical Data
TECHNICAL DATA Total Heat input: 13.7 kW Gas consumption: 997 gram/hour (Main Burner: 764 g/h, Side Burner: 233 g/h) Gas cylinder (not included): Use standard cylinder approved for use in the Nordic Region. Even though butane and propane gas can be used, we recommend propane for use in the Nordic Region. -
Page 7: Read Before Assembly
If the grill is damaged during transport, do not assemble the grill before contacting your dealer or support@fccproducts.no. Transport damage to parts, varnish or enamel must be reported to the dealer or FCC Products before mounting and using the grill. If damage is reported after, there is a possibility that damage may have occurred during assembly. -
Page 8: Parts List
PARTS LIST CODE DESCRIPTION LEFT BACK FOOT LEFT FRONT FOOT RIGHT BACK FOOT RIGHT FRONT FOOT DECOR SHEET OF SIDE BURNER SIDE BURNER ASSEMBLY KNOB LEFT SUPPORT OF OIL TRAY FLAME TAMER COOKING GRILL WHEEL AXLE WHEEL WARMING RACK BODY ASSEMBLY OIL TRAY GREASE CUP MIDDLE PANEL... -
Page 9: Exploded Drawing
GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- EXPLODED DRAWING Explosion view: — 2 —... -
Page 10: Assembly Instructions
GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S-B GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S-B MONTERING ASSEMBLY GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S-B GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S-B GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S-B assemble the legs and bottom panel assemble the legs and bottom panel Monter høyre ben del 4, 3 og venstre ben del 2 og 1 til bunnplate, del 18,... - Page 11 GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- ASSEMBLY, USE AND CARE MANUAL GD4236S- install the middle panel GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- install the middle panel ASSEMBLY install the middle panel install the middle panel Mount shelf (17) with 8 D bolts. Mount the right and left oil tray support (8 and 24) with 8 pcs D bolts.
- Page 12 ASSEMBLY GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S-B GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S-B Mount the grill body on the chassis. Insert 8 pcs A bolts before tightening. GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S-B install the firebox install the firebox install the firebox NOTE!
- Page 13 ASSEMBLY GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S-B GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S-B GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S-B Loosen the pre-assembled bolts and mount the finished right side table to the grill with 2 pcs D bolts and tighten all 4 bolts. install the right side table assy install the right side table assy install the right side table assy...
- Page 14 GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- MONTERING ASSEMBLY Monter gassventilen til sidebrenner med del 28 deksel for kontrollbry- Fit the gas valve to the side burner (28) cover for the control switch assemble the valve and knob of assemble the valve and knob of assemble the valve and knob of...
- Page 15 GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- place the grills /warming rack...
- Page 16 ASSEMBLY Place the matchstick holder (27) as shown on the illustration. GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- place the matchstick holder assy Performance II...
- Page 17 ASSEMBLY The grill is fully assembled. Fit the regulator and hose (sold separately) and perform a gas leak test before you start using the grill. ASSEMBLY IS NOW COMPLETE. ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE BBQ. LEAK TEST ANNUALLY, AND WHENEVER THE GAS BOTTLE IS REMOVED OR REPLACED.
-
Page 18: Connecting Gas
CONNECTING GAS FOLLOW THESE INSTRUCTIONS CAREFULLY TO AVOID SERIOUS DAMAGE TO YOUR GRILL AND CAUSE PERSONAL INJURY. HOSE • Connect the gas hose to the gas inlet on the grill. Tighten well. • Install the regulator and hose. Follow the installation instructions that came with the controller set. -
Page 19: Gas Leak Test
If detected leakage cannot be rectified, do not attempt to cure leakage but consult your dealer or FCC Products at support@fccproducts.no for help in solving the problem. Leak test must be done regularly and every time the gas cylinder, regulator or hose is replaced. -
Page 20: Last Check
LAST CHECK PLACEMENT OF THE GRILL • Ensure that the grill is placed at least 150 cm in all directions from house walls, trees, plants and other flammable materials or liquids when in use. • Do not place the grill under a roof or overhang. •... -
Page 21: Manual Lighting
LIGHTING INSTRUCTIONS LIGHTING INSTRUCTIONS Open the lid. The lid must always be open when lighting the grill. 2. Set all control knobs to off. 3. Open the gas valve of the gas cylinder. 4. Push the knob of the desired burner in and turn it to the left. The burner will ignite automatically. -
Page 22: Maintenance
MAINTENANCE GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4236S- KEEP THE FIREBOX, FLAME TAMERS, COOKING GRATE AND ACCESSORIES CLEAN TO AVOID GREASE FIRES. place the grills /warming rack IF A GREASE FIRE OCCUR from running down on flame tamers and on the /pot support grease tray. -
Page 23: Infrared Burner
MAINTENANCE FIRES CAUSED BY FAT, CAN DAMAGE THE METAL, PAINT AND ENAMEL. DAMAGE TO THE GRILL CAUSED BY FAT BURNING, IS NOT COVERED BY THE GUARANTEE AS IT IS DUE TO INCORRECT USE. CLEANING COOKING GRATE OG FLAME TAMERS All cleaning and maintenance must be performed Grill grate and flame tamers are brushed when the grill is cold. -
Page 24: Advice, Tips And Safety
• We recommend the use of FCC original covers for the best possible protection against rain, pollen and pollution. Remember that the grill must be completely dry and cold before apply- ing the coating. The coating is equally waterproof both ways and moisture on the inside can cause major rust damage on painted and stainless steel surfaces. -
Page 25: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Empty gas cylinder Replace gas cylinder Damaged regulator Check/replace the regulator Burner is blocked Clean the burner Gas supply is blocked Clean gas ventury or hose Electrode is broken or dirty Clean the electrode BURNER WILL NOT LIGHT Ignition knob is broken Contact your dealer... -
Page 26: Multi Grill System
ACCESSORIES SOLD SEPARATELY, AVAILABLE AT YOUR BBQ DEALER MULTI GRILL SYSTEM MULTI GRILL SYSTEM GIVES YOU NEW WAYS TO ENJOY YOUR BARBECUE TIME! Using various MGS accessories like a wok, frying pan, pizza stone, cooking plate, and searing grid on a grill can significantly expand your outdoor cooking options. Here are three good reasons for using MGS accessories: CULINARY VERSATILITY Each of these MGS accessories serves a specific purpose,... - Page 27 ACCESSORIES SOLD SEPARATELY, AVAILABLE AT YOUR BBQ DEALER SEARING GRID COOKING PLATE FRYING PAN PIZZA STONE/GLAZED PIZZA STONE Enamelled cast iron wok which cooks the food energy efficiently and preserves the nutritional content. Sauces and soups can now also be prepared on the grill. FRYING PAN Gives you the option between high heat stir-fry meat grilling, or lower heat for stews, omelets, seafood and vegetables.
-
Page 28: Warranty Claim
Scan code to reach Consumer contact: Always attach your receipt and product serial number when making a warranty claim. Produced in China for FCC Products. We are always looking for ways we can improve our products. Therefore, we reserve the right to change technical specifications at any time.
