- Page 1 Performance II SCAN QR CODE AND SCAN QR CODE FOR REGISTER BARBECUE FOR BARBECUE OUTDOOR USE ONLY! EXTENDED WARRANTY ASSEMBLY VIDEO WARRANTY: Read the operating instructions and warnings before using the appliance. FCC-G-25255-40 / GD4843-BI Assembly, maintenance and safety...
- Page 2 Performance II...
-
Page 3: The Story Of Fcc
THE STORY OF FCC The Flying Culinary Circus is the world’s first traveling cooking group. In 2005 Trond, Hans-Kristian, Mathias, and Tor went to New York. A journey that ended up being an adventure of a lifetime. With 65 countries and 300,000 hours of culinary experience in the Chef... -
Page 4: Table Of Contents
CONTENTS The story of FCC................3 Warnings ..................5 Technical data ................6 Read before assembly ...............7 Parts list ..................8 Exploded drawing ..............9 Assembly instructions ............10 Installing a built-in gas grill ...........16 Regulator and Hose - Connecting the gas ......18 Check for leaks before using the grill ........19... -
Page 5: Warnings
WARNINGS! ● Accessible parts of the grill become very hot during use. Keep children and others who need supervision at a safe distance. ● The grill is intended for outdoor use only in well-ventilated areas. ● Leak tests (see page 19) must always be carried out before the grill is used and when replacing the gas cylinder. -
Page 6: Technical Data
TECHNICAL DATA Total Heat input: 13.5 kW (main burner 10.5kW + sear burner 3kW=13.5kW) Gas consumption: 982 gram/hour (main burner/sear: 982 g/h) Gas cylinder (not included): Use standard cylinder approved for use in the Nordic Region. Even though butane and propane gas can be used, we recommend propane for use in the Nordic Region. -
Page 7: Read Before Assembly
If the grill is damaged during transport, do not assemble the grill before contacting your dealer or support@fccproducts.no. Transport damage to parts, varnish or enamel must be reported to the dealer or FCC Products before mounting and using the grill. If damage is reported after, there is a possibility that damage may have occurred during assembly. -
Page 8: Parts List
PARTS LIST CODE DESCRIPTION MAIN BURNER ASSEMBLY FLAME TAMER WARMING RACK CAST IRON GRILL MULTIFUNCTION CAST IRON COOKING GRILL MULTIFUNCTION CAST IRON ROUND COOKING GRILL LEFT HANGING PLATFORM LEFT SIDE PANEL LEFT STATOR OF OIL TRAY GREASE TRAY OIL PAN BRACKET OIL PAN HANDLE SUPPORTING LEG RIGHT SIDE PANEL... -
Page 9: Exploded Drawing
EXPLODED DRAWING... -
Page 10: Assembly Instructions
ASSEMBLY Attach the left rail profile part 9 to the left side panel part 8 using 2 D screws. Attach the right side profile part 15 to the right side panel part 14 using 2 D screws Attach 4 support legs part 13 to the right and left side panels using 4 D screws. Performance II... - Page 11 ASSEMBLY If the grill is to hang on the sides, attach the right and left hanging platforms, part 7 and 16. If the grill is mounted this way, the support legs part 13 can be unscrewed from the side frames. IMPORTANT: The grill should NOT be mounted on flammable materials.
- Page 12 ASSEMBLY Attach the grease tray part 10 to the grease tray bracket part 11 using 2 E screws and 2 B washers. Attach the grease tray handle bracket 12 using 2 A screws. Performance II...
- Page 13 ASSEMBLY Slide the grease tray under the main burner assembly. Place the flame tamers part 2 inside the grill. There should be no flame tamer over the IR burner.
- Page 14 ASSEMBLY Place the grill grate part 4, the grill grate with MGS part 5, and the MGS round grate part 5 inside the grill. Insert the warming rack part 3 Performance II...
- Page 15 ASSEMBLY Attach the hose and regulator to the flex hose from the grill, these are not included. Remember to perform a gas leak test regularly. We recommend checking the hose and regulator every time you replace the gas bottle and at least twice a year. Regulator and hose are sold separately and are not included with this grill.
-
Page 16: Installing A Built-In Gas Grill
INSTALLING A BUILT-IN GAS GRILL IF YOU WANT TO BUILD IN THE GAS GRILL IN A CUSTOMIZED OUTDOOR KITCHEN, THERE ARE SOME THINGS YOU NEED TO CONSIDER. When installing a built-in gas grill, several factors must be considered to ensure both functionality and safety. - Page 17 IF YOU’RE LOOKING TO CREATE YOUR OUTDOOR KITCHEN QUICKLY AND EFFORTLESSLY, WE RECOMMEND THE FCC OUTDOOR KITCHEN MODULES. The module FCC-A-10148 - Table for Grill is a perfect table with cabinet storage, which fit the Performance II 4.0 very well. Customize your outdoor kitchen easy with FCC outdoor kitchen modules.
-
Page 18: Connecting Gas
CONNECTING GAS FOLLOW THESE INSTRUCTIONS CAREFULLY TO AVOID SERIOUS DAMAGE TO YOUR BARBECUE AND CAUSE PERSONAL INJURY. HOSE • Connect the gas hose to the gas inlet on the barbecue. Tighten well. • Install the regulator and hose. Follow the installation instructions that came with the controller set. -
Page 19: Gas Leak Test
If detected leakage cannot be rectified, do not attempt to cure leakage but consult your dea- ler or FCC Products at support@fccbbq.com for help in solving the problem. Leak test must be done regularly and every time the gas cylinder, regulator or hose is replaced. -
Page 20: Manual Lighting
LIGHTING INSTRUCTIONS LIGHTING INSTRUCTIONS Always keep the lid open when lighting the grill. Never bend over the grill when lighting it and protect your face in the event of a flare-up. 2. Make sure that all switches are in the OFF position. Open the gas valve on the regulator. 3. -
Page 21: Final Check
FINAL CHECK PLACEMENT OF THE BARBECUE • Ensure that the barbecue is placed at least 150 cm in all directions from house walls, trees, plants and other flammable materials or liquids when in use. • Do not place the barbecue under a roof or overhang. •... -
Page 22: Maintenance
MAINTENANCE KEEP THE FIREBOX, FLAME TAMERS, COOKING GRATE AND ACCESSORIES CLEAN TO AVOID GREASE FIRES. IF A GREASE FIRE OCCUR running down on flame tamers and on the grease tray. In case of grease fire, close the gas supply on the re- Do not leave the barbecue when it is lit and close gulator/barbecue and disconnect the regulator. -
Page 23: Infrared Burner
MAINTENANCE FIRES CAUSED BY FAT, CAN DAMAGE THE METAL, PAINT AND ENAMEL. DAMAGE TO THE BARBECUE CAUSED BY FAT BURNING, IS NOT COVERED BY THE GUARANTEE AS IT IS DUE TO INCORRECT USE. CLEANING COOKING GRATE AND FLAME TAMERS All cleaning and maintenance must be performed Grill grate and flame tamers are brushed when the barbecue is cold. -
Page 24: Advice, Tips And Safety
• We recommend the use of FCC BBQ original covers for the best possible protection against rain, pollen and pollution. Remember that the barbecue must be completely dry and cold before applying the coating. The coating is equally waterproof both ways and moisture on the inside can cause major rust damage on painted and stainless steel surfaces. -
Page 25: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Empty gas cylinder Replace gas cylinder Check/replace the Damaged regulator regulator Burner is blocked Clean the burner Gas supply is blocked Clean gas ventury or hose BURNER WILL NOT LIGHT Electrode is broken or dirty Clean the electrode Place the barbecue in a less Windy conditions... -
Page 26: Accessories
ACCESSORIES SOLD SEPARATELY, AVAILABLE AT YOUR BBQ DEALER MULTI GRILL SYSTEM MULTI GRILL SYSTEM GIVES YOU NEW WAYS TO ENJOY YOUR BARBECUE TIME! Using various MGS accessories like a wok, frying pan, pizza stone, cooking plate, and searing grid on a barbecue can significantly expand your outdoor cooking options. Here are three good reasons for using MGS accessories: CULINARY VERSATILITY Each of these MGS accessories serves a specific purpose,... - Page 27 ACCESSORIES SOLD SEPARATELY, AVAILABLE AT YOUR BBQ DEALER SEARING GRID COOKING PLATE FRYING PAN PIZZA STONE/GLAZED PIZZA STONE Enamelled cast iron wok which cooks the food energy efficiently and preserves the nutritional content. Sauces and soups can now also be prepared on the grill. FRYING PAN Gives you the option between high heat stir-fry meat grilling, or lower heat for stews, omelets, seafood and vegetables.
-
Page 28: Warranty Claim
Scan code to reach Consumer contact: Always attach your receipt and product serial number when making a warranty claim. Produced in China for FCC Products. We are always looking for ways we can improve our products. Therefore, we reserve the right to change technical specifications at any time.
