MA034 (de_en)
Montageanleitung
Klingenwechsel am Kontaktbolzen der Flach-
schienenabgriffe FSA20A-K/... FSA20A-L/...
Inhalt
Sicherheitshinweise2
Notwendiges Werkzeug ............................................................3
Demontage ................................................................................3
Montage ....................................................................................3
FSA20A-K/...
FSA20A-L/...
1)
zu bestellen als Set (Klinge und Zylinderstift)
FSA20A-KL-SET Bestell-Nr. 12.0890
Klinge
1)
Blade
1)
Ø 2.5x14
Zylinderstift
Cylinder pin
MA034 (de_en)
Assembly instructions
Changing the blade on the contact bolt of the
flat contact clamps FSA20A-K/... FSA20A-L/...
Content
Safety Instructions 2
Tools required ............................................................................3
Dismantle ..................................................................................3
Assembly ...................................................................................3
Kontaktbolzen
Contact bolt
1)
1)
1)
Suitable as set (blade and cylinder pin)
FSA20A-KL-SET Order No. 12.0890
1 / 4
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Staubli MA034
Summary of Contents for Staubli MA034
- Page 1 MA034 (de_en) MA034 (de_en) Montageanleitung Assembly instructions Klingenwechsel am Kontaktbolzen der Flach- Changing the blade on the contact bolt of the schienenabgriffe FSA20A-K/... FSA20A-L/... flat contact clamps FSA20A-K/... FSA20A-L/... Inhalt Content Sicherheitshinweise2 Safety Instructions 2 Notwendiges Werkzeug ............3 Tools required ................3 Demontage ................3...
- Page 2 Sicherheitshinweise Safety instructions Die Montage und Installation der Produkte darf ausschliess- The products may be assembled and installed exclusively by lich durch qualifiziertes und erfahrenes Fachpersonal unter suitably qualified and trained specialists duly observing all ap- Berücksichtigung aller anwendbaren gesetzlichen Sicher- plicable safety regulations.
- Page 3 Notwendiges Werkzeug Tools required (ill. 1) (ill. 1) Hammer Hammer Durchschlag Ø 2 mm Punch Ø 2 mm Demontage Dismantle Zylinderstift (2) mit dem Hammer und Using the hammer and the drift dem Durchschlag vollständig austrei- punch, knock out the straight pin (2). ben.
- Page 4 Hersteller/Producer: Stäubli Electrical Connectors AG Stockbrunnenrain 8 4123 Allschwil/Switzerland Tel. +41 61 306 55 55 +41 61 306 55 56 mail ec.ch@staubli.com www.staubli.com/electrical 4 / 4...
