- Page 1 SG Series MADE IN THE USA...
-
Page 2: Table Of Contents
TABLE OF CONTENTS GENERAL INFORMATION ………………………………………………………………………………………………………………………………………………………….3 SPECIFICATIONS …………...………………………………………………………………………………………………………………………………………………………….4 SAFE OPERATION ……………………………………………………………………………………………………………………………………………………………………..5 CONTROLS AND OPERATION (DRIVING) …...………………………………………………………………………………………………………………………………6 DASH PANEL …..……………………………………….…………………………………………………………………………………………………………….6 STRIKER SET-UP ...…….……………………………………………………………………………………………………………………………………………….6 OPERATION ……………..……………………………………………………………………………………………………………………………………………...7 CONTROLS AND OPERATION (SPREADER) ……………………………………………………………………………………………………………………………….9 SPREADER CALIBRATION / RATE CHARTS ………………………………………………………………………………………………………………..10 SPREADER AND HOPPER CLEANING ………………...……………………………………………………………………………………………………..10 HOPPER DRAIN INSTRUCTIONS ………………………….…………………………………………………………………………………………………….11 CONTROLS AND OPERATION (SPRAYER) ………………………………………………………………………………………………………………………………...12 SPRAYER ON/OFF CONTROLS ………………………………………………………………………………………………………………………………..12... -
Page 3: General Information
GENERAL INFORMATION Thank you for your purchasing a Steel Green machine! Please read and understand this manual before operating this piece of equipment. This manual will assist you in areas of operation, safety, and maintenance. Any unresolved question can be directed to Steel Green Mfg. -
Page 4: Specifications
SPECIFICATIONS Dimensions: MODEL SG36 MODEL SG46 MODEL SG52 DESCRIPTION SG36 SG46 SG52 Weight Front tire 16 x 6.50-8 Rear tire 21 x 7.00-10 22 x 11.00-10 Spray Capacity 30 gal. 50 gal. 60 gal. Spray Width 2’, 4’, 6’, or 8’ 2’, 6’, 8’, or 10’... -
Page 5: Safe Operation
SAFE OPERATION CAUTION! THE FOLLOWING IMPORTANT SAFETY INSTRUCTIONS WHICH, IF NOT FOLLOWED, COULD ENDANGER THE PERSONAL SAFETY AND/OR PROPERTY OF YOURSELF AND OTHERS. READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE YOUR UNIT. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. -
Page 6: Controls And Operation (Driving)
CONTROLS AND OPERATION DASH PANEL RIGHT JOY STICK LEFT JOY STICK IGNITION KEY SPEED BAR ENGINE CHOKE SPEEDOMETER ENGINE THROTTLE... -
Page 7: Operation
CONTROLS AND OPERATION CHEST PAD MACHINE OPERATION: • To drive the machine, step up on the foot board and rest against the chest pad. FOOT BOARD • Start the machine by turning the key with a little throttle and choke if needed. -
Page 8: Driving The Machine
CONTROLS AND OPERATION LEFT TURN JOY STICKS: • The left joy stick maneuvers the left tire for- ward and reverse. • The right joy stick maneuvers the right tire for- ward and reverse. DRIVING THE MACHINE: • Move both joy sticks forward to drive forward. •... -
Page 9: Controls And Operation (Spreader)
CONTROLS AND OPERATION (SPREADER) SPREADER CALIBRATION / RATE CAUTION! • To avoid injury to hand, ensure motor is switched OFF before adjusting. • Wear appropriate clothing and safety equipment when applying and handling chemicals . • Accuway balances the spread pattern by shifting the product placement on the spinner. -
Page 10: Spreader And Hopper Cleaning
NOTE: To perform a granular calibration you will need a tape measure, bucket, and a scale. • First - you will need to weigh the empty bucket and zero your scale (or note the weight of the bucket to subtract from your later measurement). -
Page 11: Hopper Drain Instructions
HOPPER DRAIN INSTRUCTIONS STEP ONE: Squeeze and rotate the spring to discon- STEP TWO: Slide the spinner off of the rod. nect it from the rod, then pull it out of the spinner. NOTE: It may be necessary to loosen the bolt and STEP THREE: Place a bucket under the hopper trap, open the trap to drain the hopper. -
Page 12: Controls And Operation (Sprayer)
CONTROLS AND OPERATION (SPRAYER) The spray boom consists of 3-sections: Left Wing, Center Section, & Right Wing (see below). RIGHT WING CENTER SECTION LEFT WING NOTE: • Orientation is from the riders view, standing on the machine. • Layout is the same for all SG units standard spray boom. SPRAYER ON/OFF CONTROLS Each section of the boom is controlled by a dedicated Lever Valve located on the spray manifold. -
Page 13: Sprayer Pump Controls
CONTROLS AND OPERATION (PUMP) • Spray pressure is controlled by the pressure regulator located to the right of the boom control valves. • Pressure is increased by turning the pressure regu- lator clockwise (right) and decreased by turning counter-clockwise (left) •... -
Page 14: Liquid Tank Controls / Hose Reel Operation
CONTROLS AND OPERATION (LIQUID) LIQUID TANK CONTROLS • Each SG model is equipped with 2 Liquid Tanks. The RIGHT TANK LEFT TANK tanks can be operated in Tandem or separately. • The Left tank is controlled by 2 Valves located on the left side of the Upright. -
Page 15: Standard Volume Spray Chart
SPRAY CHART STANDARD VOLUME SPRAY CHART 20” CAPACITY ONE CAPACITY ONE DROP NOZZLE NOZZLE IN NOZZLE IN GALLONS PER 1000 SQ FT SIZE OZ/MIN 4 MPH 5 MPH 3 MPH 4 MPH 5 MPH 0.13 0.29 0.22 0.18 AVI-11015 0.15 11.1 0.34 0.26... -
Page 16: Care & Maintenance
CARE & MAINTENANCE WINTERIZATION WARNING! • Proper winterization of the spray system helps to prevent damage to the system due to wintertime • Do not operate the engine in a confined space freezing. Follow these easy steps: where carbon monoxide and other fumes can ... - Page 17 CARE & MAINTENANCE SUGGESTED SERVICE ACTION DAILY WEEKLY BI-WEEKLY MONTHLY YEARLY HOURS Front Caster Wheels Grease Front Caster Yoke Grease bucket Front Tire Pressure 22PSI Front Tire Bearing Preload Rear Tire Pressure 18PSI Rear Lug Nut Torque 75Lbs Rear Hub Castle Nut Check the cotter pin Frame Hardware Check all bolts &...
-
Page 18: Grease Points
CARE & MAINTENANCE GREASE POINTS There are 5 grease points on a SG machine: • 1 on each front tire. • 1 on each of the castor tubes. • 1 on the idler arm. Idler Arm grease point Castor Tube Grease Point (BOTH SIDES) Tire Grease point (BOTH FRONT TIRES) -
Page 19: Drawings & Diagrams
DRAWINGS & DIAGRAMS KAWASAKI WIRE HARNESS... - Page 20 DRAWINGS & DIAGRAMS BRIGGS WIRE HARNESS...
- Page 21 DRAWINGS & DIAGRAMS PUMP WIRE HARNESS...
- Page 22 DRAWINGS & DIAGRAMS...
- Page 23 DRAWINGS & DIAGRAMS HI-FLOW PUMP WIRE HARNESS...
-
Page 24: Drive Belts
DRAWINGS & DIAGRAMS NOTE: Please visit us at steelgreenmfg.com for drive belt replacement instructions, more part diagrams and instruction manuals. DRIVE BELTS: A48R SG 36/42 A50R SG 46/52... - Page 25 DRAWINGS & DIAGRAMS UPRIGHT SG36/42 ITEM QTY PART NUMBER DESCRIPTION ITEM QTY PART NUMBER DESCRIPTION R21-092 UPRIGHT, CROSSMEMBER, SG46/52 R21-159 MOUNTING PLATE, TEE JET MANIFOLD HFSSC-3875 HEX BOLT, 3/8 X 3/4 S51301-STD TEE JET SPRAY MANIFOLD ASSEMBLY HFNCS-38S HEX FLANGE NUT - 3/8-16 R21-151 MOUNTING BRACKET, SPRAY MANIFOLD HFSSC-145...
- Page 26 DRAWINGS & DIAGRAMS UPRIGHT SG46/52 ITEM QTY PART NUMBER DESCRIPTION ITEM QTY PART NUMBER DESCRIPTION R21-030 UPRIGHT, CROSSMEMBER, SG46/52 R21-159 MOUNTING PLATE, TEE JET MANIFOLD HFSSC-3875 HEX BOLT, 3/8 X 3/4 S51301-STD TEE JET SPRAY MANIFOLD ASSEMBLY HFNCS-38S HEX FLANGE NUT - 3/8-16 R21-034 MOUNTING BRACKET, SPRAY MANIFOLD HFSSC-145...
- Page 27 DRAWINGS & DIAGRAMS LEFT RIGHT...
- Page 28 DRAWINGS & DIAGRAMS SG36/42 SG52/46...
- Page 29 DRAWINGS & DIAGRAMS LEFT RIGHT...
- Page 30 DRAWINGS & DIAGRAMS...
- Page 31 DRAWINGS & DIAGRAMS...
- Page 32 DRAWINGS & DIAGRAMS...
- Page 33 DRAWINGS & DIAGRAMS...
- Page 34 DRAWINGS & DIAGRAMS CHASSIS SG36/42 2022 ITEM QTY PART NUMBER DESCRIPTION ITEM QTY PART NUMBER DESCRIPTION HHCSC5-3410 AXLE BOLT - 3/4-10 x 10 FWSS-38 FLAT WASHER, SS - 3/8 H80406 WHEEL MOTOR RIGHT SG36/42 SSNNC-38 NYLOCK, SS - 3/8-16 H80407 WHEEL MOTOR LEFT SG36/42 HFSSC-38114 HEX FLANGE BOLT 3/8 X 1-1/4...
- Page 35 DRAWINGS & DIAGRAMS CHASSIS SG46/52 2022 ITEM QTY PART NUMBER DESCRIPTION ITEM QTY PART NUMBER DESCRIPTION HHCSC5-3410 AXLE BOLT - 3/4-10 x 10 SSNNC-38 NYLOCK, SS - 3/8-16 H80415 WHEEL MOTOR RIGHT SG46/52 HFSSC-38114 HEX FLANGE BOLT 3/8 X 1-1/4 H80414 WHEEL MOTOR LEFT SG46/52 HFNCS-38S...
- Page 36 DRAWINGS & DIAGRAMS...
- Page 37 DRAWINGS & DIAGRAMS...
- Page 38 DRAWINGS & DIAGRAMS...
- Page 39 DRAWINGS & DIAGRAMS...
- Page 40 DRAWINGS & DIAGRAMS...
- Page 41 DRAWINGS & DIAGRAMS SG52 SG36/42/46...
- Page 42 DRAWINGS & DIAGRAMS...
- Page 43 DRAWINGS & DIAGRAMS SG36/42 SG46/52...
- Page 44 DRAWINGS & DIAGRAMS...
-
Page 45: Drawings & Diagrams
DRAWINGS & DIAGRAMS ENGINE \ HYDRAULICS SG36/42 2022 ITEM QTY PART NUMBER DESCRIPTION X30004 MUFFLER, KAWASAKI R21-202 HEAT SHEILD, MUFFLER, SG36/42 HFNCS-516S HEX NUT, 5/16 R21-225 BRACKET,PARKING BRAKE,WHEEL MOTOR HM-0812510 HEX BOLT, METRIC 8 X 1.25 X 10 FX730V-AR10-R ENGINE, KAWASAKI, 26HP 2447K110 CLEVIS, PARKING BRAKE CABLE CB-381SS... - Page 46 DRAWINGS & DIAGRAMS ENGINE \ HYDRAULICS SG46/52 2022 ITEM QTY PART NUMBER DESCRIPTION X30004 MUFFLER, KAWASAKI R21-200 HEAT SHEILD, MUFFLER, SG46/52 HFNCS-516S HEX NUT, 5/16 R21-225 BRACKET,PARKING BRAKE,WHEEL MOTOR HM-0812510 HEX BOLT, METRIC 8 X 1.25 X 10 FX730V-AR10-R ENGINE, KAWASAKI, 26HP 2447K110 CLEVIS, PARKING BRAKE CABLE CB-381SS...
- Page 47 DRAWINGS & DIAGRAMS...
- Page 48 DRAWINGS & DIAGRAMS...
- Page 49 DRAWINGS & DIAGRAMS...
- Page 50 DRAWINGS & DIAGRAMS...
- Page 51 DRAWINGS & DIAGRAMS...
- Page 52 DRAWINGS & DIAGRAMS HOPPER HOSE, (STRAIGHT FITTING) HOPPER HOSE, (ELBOW FITTING)
- Page 53 DRAWINGS & DIAGRAMS...
- Page 54 DRAWINGS & DIAGRAMS...
- Page 55 DRAWINGS & DIAGRAMS TANKS \ SPRAY SYSTEM STATION 4 SG36 2022 TANKS \ SPRAY SYSTEM STATION 4 SG42/46 2022 ITEM QTY PART NUMBER DESCRIPTION ITEM QTY PART NUMBER DESCRIPTION M10015 TANK, 15 GAL. RIGHT M10015 TANK, 15 GAL. RIGHT M10015-L TANK, 15 GAL., LEFT M10015-L TANK, 15 GAL., LEFT...
- Page 56 DRAWINGS & DIAGRAMS TANKS \ SPRAY SYSTEM SG52 ITEM QTY PART NUMBER DESCRIPTION M10030-R TANK, 30 GAL. RIGHT M10030-L TANK, 30 GAL. LEFT 5059-3611-D011 PUMP, SHURFLO 34-007 HEAT SINK, SPRAY PUMP W21-100 MOUNTING BRACKET, SPRAY PUMP S51243 CAP, TANK S51242 BULKHEAD FITTING, TANK S52081 3/4"...
- Page 57 DRAWINGS & DIAGRAMS RIGHT Tank SG36 LEFT Tank SG36...
- Page 58 DRAWINGS & DIAGRAMS LEFT Tank SG46 RIGHT Tank SG46...
- Page 59 DRAWINGS & DIAGRAMS LEFT Tank SG52 RIGHT Tank SG52...
- Page 60 DRAWINGS & DIAGRAMS PRESSURE HOSE...
- Page 61 DRAWINGS & DIAGRAMS...
- Page 62 DRAWINGS & DIAGRAMS...
- Page 63 DRAWINGS & DIAGRAMS SG52 SG42/46...
- Page 64 DRAWINGS & DIAGRAMS HYDRAULIC SYSTEM...
- Page 65 DRAWINGS & DIAGRAMS SPRAY HOSE SYSTEM SUPPLY RETURN OUTPUT...
- Page 66 DRAWINGS & DIAGRAMS HOPPER \ FINAL ASSEMBLY SG36 PARTS LIST ITEM QTY PART NUMBER DESCRIPTION ITEM QTY PART NUMBER DESCRIPTION R21-095 PANNEL, SIDE, HOPPER, SG36 NFW-14B WASHER, PLASTIC R21-095-R PANNEL, SIDE, HOPPER, SG36, RIGHT TRPC-141S PHILLIPS SCREW, SS - 1/4-20 x 1 R21-044 CROSS MEMBER, FRONT, SG36 HOPPER SSNNC-14...
-
Page 67: Flat Washer
DRAWINGS & DIAGRAMS HOPPER \ FINAL ASSEMBLY SG52 PARTS LIST ITEM QTY PART NUMBER DESCRIPTION ITEM QTY PART NUMBER DESCRIPTION R21-043-L PANNEL, SIDE, HOPPER, SG52, LEFT NFW-14B WASHER, PLASTIC R21-043-R PANNEL, SIDE, HOPPER, SG52, RIGHT TRPC-141S PHILLIPS SCREW, SS - 1/4-20 x 1 R21-044 CROSS MEMBER, FRONT SSNNC-14... - Page 68 DRAWINGS & DIAGRAMS...
- Page 69 DRAWINGS & DIAGRAMS...
- Page 70 DRAWINGS & DIAGRAMS...
- Page 71 DRAWINGS & DIAGRAMS...
- Page 72 DRAWINGS & DIAGRAMS...
-
Page 77: Warranty
Steel Green Manufacturing, LLC 1-Year Limited Warranty A. WHAT IS COVERED – This Warranty applies to equipment having model numbers SG52, SG46, SG42, and SG36 (“Equipment”) manufactured by Steel Green Manufacturing, LLC, an Indiana limited liability company (“Steel Green”). This Warranty only applies to Equipment purchased directly from Steel Green or an authorized dealer or distributor of the Equipment (“Authorized Dealers”) in the United States. - Page 78 STEEL GREEN’S ONLY LIABILITY WITH RESPECT TO THIS WARRANTY AND YOUR EXCLUSIVE REMEDY SHALL BE FOR THE REPAIR OR REPLACEMENT OF PARTS AS SET FORTH HEREIN. NO CLAIM FOR BREACH OF WARRANTY SHALL ENTITLE YOU TO CANCELLATION OR RESCISSION OF THE PURCHASE OF THE EQUIPMENT.
- Page 80 OPERATORS MANUAL PART NO. REV. DESCRIPTION SGOM-001 OPERATORS MANUAL, SG SERIES PRINTED IN U.S.A.
