INSTRUCTION MANUAL
SG52 VIBRATION BRACKET INSTRUCTIONS
PLEASE NOTE
The supplied vibration brackets
MUST
be installed or warranty will be void.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SG52 and is the answer not in the manual?

Questions and answers

Related Manuals for STEELGREEN SG52

Summary of Contents for STEELGREEN SG52

  • Page 1 INSTRUCTION MANUAL SG52 VIBRATION BRACKET INSTRUCTIONS PLEASE NOTE The supplied vibration brackets MUST be installed or warranty will be void.
  • Page 2 SG52 VIBRATION BRACKET INSTRUCTIONS NOTE: Instructions are the same for both right & left sides. STEP ONE: Remove the safety shield from the tank support. STEP TWO: Loosen the four tank bolts on the front & 3 tank bolts on the rear, do not completely remove the bolts.
  • Page 3 SG52 VIBRATION BRACKET INSTRUCTIONS STEP THREE: Install the vibration brackets. LEFT SIDE NOTE: The tanks should be loose from step two and able to move for proper alignment with the brackets. RIGHT SIDE...
  • Page 4 SG52 VIBRATION BRACKET INSTRUCTIONS STEP FOUR: Tighten the four tank bolts on the front & 3 tank bolts on the rear. STEP FIVE: Reattach the safety shield to the tank support. Steel Green Mfg. 920 S State Road 39 Lebanon, IN 46052 (756)-481-2890 www.steelgreenmfg.com...
