- Page 1 EDS-510E Series Quick Installation Guide Moxa EtherDevice™ Switch Version 1.5, December 2023 Technical Support Contact Information www.moxa.com/support 2023 Moxa Inc. All rights reserved. P/N: 1802005100045 *1802005100045*...
- Page 2 Package Checklist The EDS-510E is shipped with the following items. If any of these items are missing or damaged, please contact your customer service representative for assistance. • 1 EDS-510E Ethernet switch • USB cable • Protective caps for unused ports •...
- Page 3 Panel Views of EDS-510E Front Panel Front Panel 1. 1 to 7 port status LED 2. 1 to 7: 10/100BaseT(X) port 3. System status LED: • STATE LED indicator • PWR1 LED indicator • PWR2 LED indicator • FAULT LED indicator •...
- Page 4 Mounting Dimensions Unit = mm (inch) - 4 -...
- Page 5 DIN-Rail Mounting The metal DIN-rail kit is fixed to the back panel of the EDS-510E when you take it out of the box. Mount the EDS-510E on corrosion-free mounting rails that meet the EN 60715 standard. Installation STEP 1—Insert the upper lip of the DIN rail into the DIN-rail mounting kit.
- Page 6 Wall Mounting (Optional) For some applications, you will find it convenient to mount Moxa EDS- 510E on the wall, as shown in the following illustrations: STEP 1—Remove the aluminum DIN rail attachment plate from the rear panel of the EDS-510E, and then attach the wall mount plates with M3 screws, as shown in the figure at the...
- Page 7 ATTENTION This unit is a built-in type. When the unit is installed in another piece of equipment, the equipment enclosing the unit must comply with fire enclosure regulation IEC 60950/EN60950 (or similar regulation). ATTENTION Safety First! Be sure to disconnect the power cord before installing and/or wiring your Moxa EtherDevice Switch.
- Page 8 the next section for detailed instructions on how to connect the wires to the terminal block connector, and how to attach the terminal block connector to the terminal block receptor. In this section, we illustrate the use of two contacts used to connect the relay. FAULT: The two contacts of the 6-pin terminal block connector are used to detect user-configured events.
- Page 9 STEP 3: Insert the plastic terminal block connector prongs into the terminal block receptor, which is located on the EDS-510E’s top panel. Communication Connections Each EDS-510E switch has 4 types of communication ports: • 1 USB console port (type B connector) •...
- Page 10 USB Storage Port (Type A Connector) Pinouts Description VCC (+5V) D– (Data -) D+ (Data+) GND (Ground) 10/100BaseT(X) Ethernet Port Connection The 10/100BaseT(X) ports located on the EDS-510E’s front panel are used to connect to Ethernet-enabled devices. Most users configure these ports for Auto MDI/MDI-X mode, in which case the port’s pinouts are adjusted automatically depending on the type of Ethernet cable used (straight-through or cross-over), and the type of device (NIC-type...
- Page 11 RJ45 (8-pin) to RJ45 (8-pin) Cross-over Cable Wiring 1000BaseT Ethernet Port Connection 1000BaseT data is transmitted on differential TRD+/- signal pairs over copper wires. MDI/MDI-X Port Pinouts Signal TRD(0)+ TRD(0)- TRD(1)+ TRD(2)+ TRD(2)- TRD(1)- TRD(3)+ TRD(3)- 100/1000BaseSFP (mini-GBIC) Fiber Port The gigabit Ethernet ports on the EDS-510E are 100/1000BaseSFP Fiber ports, which require using the 100M or 1G mini-GBIC fiber transceivers to work properly.
- Page 12 ATTENTION This is a Class 1 Laser/LED product. To avoid causing serious damage to your eyes, do not stare directly into the Laser Beam. Reset Button There are two functions available on the reset button. One is to reset the Ethernet switch to factory default settings by pressing and holding the reset button for 5 seconds.
- Page 13 The default setting for each DIP Switch is OFF. The following table explains the effect of setting the DIP Switch to the ON position. “Turbo Ring” DIP Switch Settings DIP 1 DIP 2 DIP 3 DIP 4 Reserved for ON: Enables this ON: Enables the ON: Activates future use.
- Page 14 Color Status Description 1. The switch is under reset progress (1 time/s). Blinking 2. Detect ABC-02-USB connect to the switch (1 time/2s). The system failed self-diagnosis on boot-up. • RAM Test Fail / System Info. Read Fail / Switch Initial Fail / PTP PHY Error.
- Page 15 Color Status Description 2. The switch is set as Turbo Chain’s Member and the corresponding chain port is down. 1. This switch has disabled the coupling function. 2. This switch is set as a Member of the Turbo Chain. FAULT + Rotate ABC-02-USB is importing/exporting MSTR/HEAD +...
- Page 16 RJ45 Ports 7-port 10/100BaseT(X), 3-port 10/100/1000BaseT(X) auto negotiation speed Fiber Ports 3-port 100/1000BaseSFP slot USB Ports USB console port (type B connector) USB storage port (type A connector) Button Reset button LED Indicators PWR1, PWR2, FAULT, STATE, 10/100M (TP port), 100/1000M (Gigabit port), MSTR/HEAD, CPLR/TAIL Alarm Contact...
- Page 17 Warranty Warranty 5 years NOTE Devices should be deployed a minimum of 600 mm from a compass. Supported SFP Modules Module Description SFP-1FELLC-T SFP module with 1 100Base single-mode with LC connector for 80 km transmission, -40 to 85°C operating temperature SFP-1FEMLC-T SFP module with 1 100Base multi-mode, LC connector for 2/4 km transmission, -40 to 85°C...
- Page 18 SFP-1G40ALC-T WDM-type (BiDi) SFP module with 1 1000BaseSFP port with LC connector for 40 km transmission; TX 1310 nm, RX 1550 nm, -40 to 85°C operating temperature SFP-1G40BLC WDM-type (BiDi) SFP module with 1 1000BaseSFP port with LC connector for 40 km transmission; TX 1550 nm, RX 1310 nm, 0 to 60°C operating temperature SFP-1G40BLC-T...
- Page 19 Hazardous Location Trademark Model/Rating Model name: EDS-510E-3GTXSFP EDS-510E-3GTXSFP-T Rating: 12 to 48 VDC, 1.3 A, Class 2 Relay output: 24 VDC, 1 A, Resistance ATEX information II 3G DEMKO 13 ATEX 1218X Ex ec nC IIC T4 Gc Ambient Range: -40°C ≤ Tamb ≤ +75°C WARNING –...
- Page 20 WARNING 1. These devices are open-type devices that are to be installed in an enclosure with tool-removable cover or door suitable for the environment at that location. 2. This equipment is suitable in Class I, Division 2, Groups A, B, C, and D, or non-hazardous locations only. AVIS IMPORTANT 1.
