- Page 1 Moxa EtherDevice™ Switch EDS-510A Series Hardware Installation Guide Sixth Edition, May 2010 © 2010 Moxa Inc. All rights reserved. Reproduction without permission is prohibited. Fl.4, No.135, Lane 235, Pao-Chiao Rd. Shing Tien City, Taipei, Taiwan, R.O.C. TEL: +886-2-8919-1230 P/N: 1802005100013...
-
Page 2: Package Checklist
Package Checklist The EDS-510A is shipped with the following items. If any of these items are missing or damaged, please contact your customer service representative for assistance. 1 EDS-510A EtherDevice Switch Hardware Installation Guide (this guide) CD-ROM with user’s manual and Windows utility Moxa product warranty statement RJ45 to DB9 console port cable Protective caps for unused ports... - Page 3 Panel Views of EDS-510A EDS-510A-3GT 1 to 7: 10/100BaseT(X) port Front Panel View EDS-510A-3GT 10/100/1000BaseT(X) port EDS-510A-1GT2SFP 10/100/1000BaseT(X) port MSTR/HEAD EDS-510A-3SFP CPLR/TAILD 1000BaseSX/LX/LHX/ZX port EDS-510A-3GT 10/100/1000BaseT(X) port EDS-510A-1GT2SFP 1000BaseSX/LX/LHX/ZX port EDS-510A-3SFP 1000BaseSX/LX/LHX/ZX port EDS-510A-1GT2SFP Front Panel View EDS-510A-3GT 10/100/1000BaseT(X) port EDS-510A-1GT2SFP 1000BaseSX/LX/LHX/ZX port EDS-510A-3SFP...
-
Page 4: Mounting Dimensions (Unit = Mm)
Top Panel: Top Panel View Ground screw RS-232 console port RS-232 CONSOLE PWR2 Heat dissipation orifices DIP switches for Ring Master, Ring Coupler, and Turbo Ring RELAY1 RELAY2 6-pin terminal block for DI 1, DI 2, ------ MASTER COUPLER TURBO PWR1 RING and PWR 2... -
Page 5: Din-Rail Mounting
DIN-Rail Mounting The aluminum DIN-Rail attachment plate should already be fixed to the back panel of the EDS-510A when you take it out of the box. If you need to reattach the DIN-Rail attachment plate to the EDS-510A, make sure the stiff metal spring is situated towards the top, as shown by the following figures. -
Page 6: Atex Information
Do not screw the screws in all the way—leave about 2 mm to allow room for sliding the wall mount panel between the wall and the screws. STEP 3—Once the screws are fixed to the wall, insert the four screw heads through the wide parts of the keyhole-shaped apertures, and then slide the EDS-510A downwards, as indicated... -
Page 7: Wiring The Relay Contact
ATTENTION Safety First! Be sure to disconnect the power cord before installing and/or wiring your Moxa EtherDevice Switch. Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes dictating the maximum current allowable for each wire size. If the current goes above the maximum ratings, the wiring could overheat, causing serious damage to your equipment. -
Page 8: Wiring The Redundant Power Inputs
Wiring the Redundant Power Inputs The EDS-510A has two sets of power inputs—power input 1 and power input 2. The top two contacts and the bottom two contacts of the 6-pin terminal block connector on the EDS-510A’s top panel are used for the two digital inputs. - Page 9 In this section, we present two types of diagrams—Pinout Diagrams and Cable Wiring Diagrams—that convey information about the ports and the cables used to connect the EDS-510A to other devices: Pinouts—The “Pinouts” diagrams display the type of signal passing through each of the port’s pins.
-
Page 10: 10/100Baset(X) Ethernet Port Connection
RJ45 (10-pin) to DB9 (F) Cable Wiring Moxa COM Port EtherDevice Server RJ45 Plug Pin 1 RJ45 Female DB9 Connector Cable Wiring Connector 10/100BaseT(X) Ethernet Port Connection The 10/100BaseT(X) ports located on the EDS-510A’s front panel are used to connect to Ethernet-enabled devices. Most users configure these ports for Auto MDI/MDI-X mode, in which case the port’s pinouts are adjusted automatically depending on the type of Ethernet cable used (straight-through or cross-over), and the type of device (NIC-type or HUB/Switch-type) - Page 11 1000BaseT Ethernet Port Connection 1000BaseT data is transmitted on differential TRD+/- signal pairs over copper wires. MDI/MDI-X Port Pinouts Signal TRD(0)+ TRD(0)- TRD(1)+ TRD(2)+ TRD(2)- TRD(1)- TRD(3)+ TRD(3)- 1000BaseSFP (mini-GBIC) Fiber Port The gigabit Ethernet ports on the EDS-510A-1GT2SFP and EDS-510A-3SFP are 1000BaseSFP Fiber ports, which require using the gigabit mini-GBIC fiber transceivers to work properly.
-
Page 12: Turbo Ring Dip Switch Settings
Turbo Ring DIP Switch Settings EDS-510A series are plug-and-play managed redundant Ethernet switches. The proprietary Turbo Ring protocol was developed by Moxa to provide better network reliability and faster recovery time. Moxa Turbo Ring’s recovery time is less than 300 ms (Turbo Ring) or 20 ms (Turbo Ring V2) —compared to a 3- to 5-minute recovery time for commercial switches—decreasing the possible loss caused by network failures in an industrial setting. -
Page 13: Led Indicators
NOTE You must enable the Turbo Ring function first before using the DIP switch to activate the Master and Coupler functions. NOTE If you do not enable any of the EDS-510A switches to be the Ring Master, the Turbo Ring protocol will automatically choose the EDS-510A with the smallest MAC address range to be the Ring Master. -
Page 14: Specifications
When the EDS-510A disables the coupling function. TP port’s 10 Mbps link is active. Data is being transmitted at 10 GREEN Blinking (TP) Mbps. TP port’s 10 Mbps link is inactive. TP port’s 100 Mbps link is active. 100M Data is being transmitted at 100 GREEN Blinking (TP) - Page 15 Optical Fiber—1000BaseSX/LX/LHX/ZX 850 nm 1310 nm 1310 nm 1310 nm Wavelength -4 dBm -3 dBm 1 dBm +5 dBm Max. Tx -9.5 dBm -9.5 dBm -4 dBm 0 dBm Min. Tx -18 dBm -20 dBm -24 dBm -24 dBm Rx Sensitivity 8.5 dB 10.5 dB 20 dB...
- Page 16 Mechanical Casing IP30 protection, metal case Dimensions (W × H × D) 80.5 × 135 × 105 mm (3.17 × 5.31 × 4.13 in) Weight 1.17 kg Installation DIN-Rail, Wall Mounting Kit (optional) Environment Operating Temperature 0 to 60°C (32 to 140°F), standard models -40 to 75°C (-40 to 185°F), wide temp.
