CV-100/P2002 Series
User Manual
Industrial Panel PC
Performance & Power Efficient Series
Version: V1.82

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CV-W121C-AG/P2002-i5 and is the answer not in the manual?

Questions and answers

Related Manuals for Cincoze CV-W121C-AG/P2002-i5

Summary of Contents for Cincoze CV-W121C-AG/P2002-i5

  • Page 1 CV-100/P2002 Series User Manual Industrial Panel PC Performance & Power Efficient Series Version: V1.82...

  • Page 2: Table Of Contents

    Contents Preface ..............................5 Revision ............................5 Copyright Notice ..........................5 Acknowledgement ......................... 5 Disclaimer ............................6 Declaration of Conformity ......................6 Product Warranty Statement ......................6 Technical Support and Assistance ....................7 Conventions Used in this Manual ....................8 Safety Precautions ..........................
  • Page 3 2.4 Definition of Connectors ......................81 Chapter 3 System Setup ........................87 3.1 Removing Top Cover....................... 88 3.2 Installing Half Size Mini PCIe Card ..................89 3.3 Installing Full Size Mini PCIe Card ..................91 3.4 Installing mSATA Card ......................92 3.5 Installing Antenna(s) ......................
  • Page 4 4.4.2 PCH-IO Configuration ....................134 4.5 Security Setup ........................136 4.6 Boot Setup ..........................137 4.7 Save & Exit ..........................138 Chapter 5 Product Application ......................139 5.1 Digital I/O (DIO) application ....................140 5.1.1 Digital I/O Programming Guide ................. 140 5.2 Digital I/O (DIO) Hardware Specification ................

  • Page 5: Preface

    2025/06/04 Copyright Notice © 2016 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.

  • Page 6: Disclaimer

    (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain an CV-100/P2002 Series | User Manual...

  • Page 7: Technical Support And Assistance

    Limitation of Liability Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.

  • Page 8: Conventions Used In This Manual

    ⚫ Description of your peripheral attachments ⚫ Description of your software (operating system, version, application software, etc.) ⚫ A complete description of the problem ⚫ The exact wording of any error messages Conventions Used in this Manual This indication alerts operators to an operation that, if not strictly observed, may result in severe injury.
  • Page 9 power cord. 10. All cautions and warnings on the equipment should be noted. 11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage. 12. Never pour any liquid into an opening. This may cause fire or electrical shock. 13.

  • Page 10: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty Panel PC Screw Pack Power Terminal Block Connector Fan Terminal Block Connector DIO Terminal Block Connector Power On/Off Terminal Block Connector Screw Pack Panel Mounting Kit (The quantity varies with the size of the display module, please refer to the datasheet for the actual quantity)
  • Page 11 12.1" TFT XGA 4:3 Panel PC with Projected Capacitive CV-112HC/P2002E-i5 Touch and Intel 6th Gen. Core i5-6300U Expandable Fanless Computer, CFM Interface, CDS Interface 12.1" TFT XGA 4:3 Panel PC with Projected Capacitive Touch and Intel 6th Gen. Core i5-6300U Expandable CV-112HC/P2002E-i5-E4 Fanless Computer, CFM Interface, CDS Interface, 1x PCIex4 Expansion...
  • Page 12 Expansion 15" TFT XGA 4:3 Panel PC with Resistive 5-wire Touch CV-115R/P2002-i5 and Intel 6th Gen. Core i5-6300U Fanless Computer, CFM Interface, CDS Interface 15" TFT XGA 4:3 Panel PC with Resistive 5-wire Touch CV-115R/P2002E-i5 and Intel 6th Gen. Core i5-6300U Expandable Fanless Computer, CFM Interface, CDS Interface 15"...
  • Page 13 15" TFT XGA 4:3 Panel PC with Projected Capacitive Touch, Anti-Glare Coating, and 6th Gen Intel® Core CV-115C-AG/P2002E-i5-E4 i5-6300U Processor. Fanless and expandable design with CFM interface, CDS interface, and 1x PCIe x4 expansion slot. 15“ TFT XGA 4:3 Panel PC with Projected Capacitive Touch, Anti-Glare Coating, and 6th Gen Intel®...
  • Page 14 15" XGA 4:3 Fanless Panel PC with 6th Gen Intel® Core CV-115C-AG/P2002-i3 i3-6100U Processor, Projected Capacitive Touch, Anti-Glare Coating, CFM Interface, and CDS Interface. 15" TFT XGA 4:3 Panel PC with Projected Capacitive Touch, Anti-Glare Coating, and 6th Gen Intel® Core CV-115C-AG/P2002E-i3 i3-6100U Processor.
  • Page 15 PCIex4 Expansion 15.6" TFT WXGA 16:9 Panel PC with Projected Capacitive Touch and Intel 6th Gen. Core i5-6300U Expandable CV-W115C/P2002E-i5-PI Fanless Computer, CFM Interface, CDS Interface, 1x PCI Expansion 15.6" TFT WXGA 16:9 Panel PC with Resistive 5-wire CV-W115R/P2002-i3 Touch and Intel 6th Gen. Core i3-6100U Fanless Computer, CFM Interface, CDS Interface 15.6"...
  • Page 16 15.6" TFT-LCD Full HD 16:9 Panel P C with Resistive 5-wire Touch and Intel 6th Gen. Core i5-6300U CV-W115FHR/P2002E-i5 Expandable Fanless Computer, CFM Interface, C D S Interface 15.6" TFT-LCD Full HD 16:9 Panel P C with Resistive 5-wire Touch and Intel 6th Gen. Core i5-6300U CV-W115FHR/P2002E-i5-E4 Expandable Fanless Computer, CFM Interface, C D S Interface, 1x PCIex4 Expansion...
  • Page 17 15.6" TFT-LCD Full HD 16:9 Panel P C with Resistive 5-wire Touch and Intel 6th Gen. Core i3-6100U CV-W115FHR/P2002E-i3-PI Expandable Fanless Computer, CFM Interface, 1x PCI Expansion 15.6" TFT-LCD Full HD 16:9 Panel P C with Projected CV-W115FHC/P2002-i3 Capacitive Touch and Intel 6th Gen. Core i3-6100U Fanless Computer, CFM Interface, C D S Interface 15.6"...
  • Page 18 Fanless Computer, CFM Interface, CDS Interface 17" TFT SXGA 5:4 Panel PC with Projected Capacitive Touch and Intel 6th Gen. Core i5-6300U Expandable CV-117C/P2002E-i5-E4 Fanless Computer, CFM Interface, CDS Interface1x PCIex4 Expansion 17" TFT SXGA 5:4 Panel PC with Projected Capacitive Touch and Intel 6th Gen.
  • Page 19 17" TFT SXGA 5:4 Panel PC with Projected Capacitive CV-117C/P2002-i3 Touch and Intel 6th Gen. Core i3-6100U Fanless Computer, CFM Interface, CDS Interface 17" TFT SXGA 5:4 Panel PC with Projected Capacitive CV-117C/P2002E-i3 Touch and Intel 6th Gen. Core i3-6100U Expandable Fanless Computer, CFM Interface, CDS Interface 17"...
  • Page 20 Computer, CFM Interface, CDS Interface 1x PCI Expansion 19" TFT SXGA 5:4 Panel PC with Projected Capacitive CV-119C/P2002-i5 Touch and Intel 6th Gen. Core i5-6300U Fanless Computer, CFM Interface, CDS Interface 19" TFT SXGA 5:4 Panel PC with Projected Capacitive CV-119C/P2002E-i5 Touch and Intel 6th Gen.
  • Page 21 19" TFT SXGA 5:4 Panel PC with Resistive 5-wire Touch and Intel 6th Gen. Core i3-6100U Expandable Fanless CV-119R/P2002E-i3-PI Computer, CFM Interface, CDS Interface 1x PCI Expansion 19" TFT SXGA 5:4 Panel PC with Projected Capacitive CV-119C/P2002-i3 Touch and Intel 6th Gen. Core i3-6100U Fanless Computer, CFM Interface, CDS Interface 19"...
  • Page 22 Expandable Fanless Computer, CFM Interface, CDS Interface 1x PCI Expansion 21.5" TFT Full HD 16:9 Panel PC with Projected Capacitive Touch, Anti-Glare Coating, and Intel 6th Gen. CV-W121C-AG/P2002-i5 Core i5-6300U Processor. Supports CFM and CDS interfaces 21.5" TFT Full HD 16:9 Panel PC with Projected Capacitive Touch, Anti-Glare Coating, and Intel 6th Gen.
  • Page 23 slot 21.5" TFT Full HD 16:9 Panel PC without Touch, w/ Intel CV-W121G/P2002-i5 6th Gen. Core i5-6300U Fanless Computer, CFM Interface, CDS Interface 21.5" TFT Full HD 16:9 Panel PC without Touch, w/ Intel CV-W121G/P2002E-i5 6th Gen. Core i5-6300U Expandable Fanless Computer, CFM Interface, CDS Interface 21.5"...
  • Page 24 Interface 1x PCIex4 Expansion 21.5" TFT Full HD 16:9 Panel PC with Projected Capacitive Touch and Intel 6th Gen. Core i3-6100U CV-W121C/P2002E-i3-PI Expandable Fanless Computer, CFM Interface, CDS Interface 1x PCI Expansion 21.5" TFT Full HD 16:9 Panel PC with Projected Capacitive Touch, Anti-Glare Coating and Intel 6th Gen.
  • Page 25 24" TFT Full HD 16:9 Panel PC with Resistive 5-wire CV-W124R/P2002-i5 Touch and Intel 6th Gen. Core i5-6300U Fanless Computer,CFM Interface,CDS Interface 24" TFT Full HD 16:9 Panel PC with Resistive 5-wire CV-W124R/P2002E-i5 Touch and Intel 6th Gen. Core i5-6300U Expandable Fanless Computer, CFM Interface, CDS Interface 24"...
  • Page 26 24" TFT Full HD 16:9 Panel PC with Resistive 5-wire CV-W124R/P2002E-i3-PI Touch and Intel 6th Gen. Core i3-6100U Expandable Fanless Computer, CFM Interface, 1x PCI Expansion 24" TFT Full HD 16:9 Panel PC with Projected Capacitive CV-W124C/P2002-i3 Touch and Intel 6th Gen. Core i3-6100U Fanless Computer, CFM Interface, CDS Interface 24"...
  • Page 27 24" TFT Full HD 16:9 Panel PC without Touch, w/ Intel CV-W124G/P2002E-i3-PI 6th Gen. Core i3-6100U Expandable Fanless Computer, CFM Interface, CDS Interface, 1x PCI Expansion CV-100/P2002 Series | User Manual...

  • Page 28: Chapter 1 Product Introductions

    Chapter 1 Product Introductions CV-100/P2002 Series | User Manual...

  • Page 29: Overview

    PoE and ignition sensing functions with additional CFM boards. In addition, Cincoze offers a full series of Mini-PCIe Expansion I/O Card (MEC) for adding extra I/O through the universal bracket. The CV-100/P2002 Series comes with the slim version, and the expandable version...

  • Page 30: Product Pictures

    1.3 Product Pictures 1.4 Key Features ⚫ 12.1” ~ 24” TFT LCD with Resistive / P-CAP / P-CAP (AG) ⚫ Onboard Intel® 6th Generation Core™ Processor U Series (15W) ⚫ 2x DDR4 SO-DIMM Socket, Support Up to 32 GB ⚫ Integrated Intel®...

  • Page 31: Hardware Specification

    1.5 Hardware Specification 1.5.1 CV-112H/P2002 Series Model Name CV-112HR CV-112HC Display • 12.1" (4:3) LCD Size • Max. Resolution 1024 x 768 • 500 Brightness (cd/m2) • Contrast Ratio 700 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.24 (H) x 0.24 (V) •...
  • Page 32 • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV • EN/IEC 61000-4-6 CS: 3V • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P2002...
  • Page 33 • 1x External FAN Connector, 4-Pin Terminal Block External Fan Storage • 2x 2.5” SATA HDD/SSD Bay, Support RAID 0/1 (Gen3) SSD/HDD • 2x mSATA (One Shared by Mini-PCIe Socket) (Gen2) mSATA • 1x CFast Socket (Gen3) CFast Expansion • 1x PCI or 1x PCIex4 Expansion slot •...
  • Page 34 (with SSD, according to IEC60068-2-64) * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P2002 Series | User Manual...
  • Page 35 Dimensions CV-112H/P2002 unit :mm CV-112H/P2002E unit :mm CV-100/P2002 Series | User Manual...

  • Page 36: Cv-115/P2002 Series

    1.5.2 CV-115/P2002 Series Model Name CV-115R CV-115C CV-115C-AG Display • 15" (4:3) LCD Size • Max. Resolution 1024 x 768 • 350 Brightness (cd/m2) • Contrast Ratio 800 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.297 (H) x 0.297 (V) •...
  • Page 37 • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P2002 P2002E System • Onboard 6th Intel® Core™ U processors (Skylake) Processor - Intel® Core™ i5-6300U processor (3M Cache, up to 3.00 GHz) - Intel®...
  • Page 38 • 2x mSATA (One Shared by Mini-PCIe Socket) (Gen2) mSATA • 1x CFast Socket (Gen3) CFast Expansion • 1x PCI or 1x PCIex4 Expansion slot • Optional Riser Card: 1x PCI, 1x PCIex4 PCI Express • Support maximum dimension of add-on card (H x L): 111mm x 202mm •...
  • Page 39 (with SSD, according to IEC60068-2-64) * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P2002 Series | User Manual...
  • Page 40 Dimensions CV-115/P2002 unit :mm CV-115/P2002E unit :mm CV-100/P2002 Series | User Manual...

  • Page 41: Cv-W115/P2002 Series

    1.5.3 CV-W115/P2002 Series Model Name CV-W115R CV-W115C Display • 15.6" (16:9) LCD Size • Max. Resolution 1366 x 768(WXGA) • 400 Brightness (cd/m2) • Contrast Ratio 500 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.252 (H) x 0.252 (V) •...
  • Page 42 • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P2002 P2002E System • Onboard 6th Intel® Core™ U processors (Skylake) Processor - Intel® Core™ i5-6300U processor (3M Cache, up to 3.00 GHz) - Intel®...
  • Page 43 • 2x mSATA (One Shared by Mini-PCIe Socket) (Gen2) mSATA • 1x CFast Socket (Gen3) CFast Expansion • 1x PCI or 1x PCIex4 Expansion slot • Optional Riser Card: 1x PCI, 1x PCIex4 PCI Express • Support maximum dimension of add-on card (H x L): 111mm x 202mm •...
  • Page 44 • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P2002 Series | User Manual...
  • Page 45 Dimensions CV-W115/P2002 unit :mm CV-W115/P2002E unit :mm CV-100/P2002 Series | User Manual...

  • Page 46: Cv-W115Fh/P2002 Series

    1.5.4 CV-W115FH/P2002 Series Model Name CV-W115FHR CV-W115FHC Display • 15.6" (16:9) LCD Size • Max. Resolution 1920 x 1080 (Full HD) • 350 Brightness (cd/m2) • Contrast Ratio 800 : 1 • 16.7M LCD Color • Pixel Pitch(mm) 0.17925 (H) x 0.17925 (V) •...
  • Page 47 • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P2002 P2002E System • Onboard 6th Intel® Core™ U processors (Skylake) Processor - Intel® Core™ i5-6300U processor (3M Cache, up to 3.00 GHz) - Intel®...
  • Page 48 • 2x mSATA (One Shared by Mini-PCIe Socket) (Gen2) mSATA • 1x CFast Socket (Gen3) CFast Expansion • 1x PCI or 1x PCIex4 Expansion slot • Optional Riser Card: 1x PCI, 1x PCIex4 PCI Express • Support maximum dimension of add-on card (H x L): 111mm x 202mm •...
  • Page 49 • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P2002 Series | User Manual...
  • Page 50 Dimensions CV-W115FH/P2002 unit :mm CV-W115FH/P2002E unit :mm CV-100/P2002 Series | User Manual...

  • Page 51: Cv-117/P2002 Series

    1.5.5 CV-117/P2002 Series Model Name CV-117R CV-117C CV-117G Display • 17" (5:4) LCD Size • Max. Resolution 1280 x 1024 • 350 Brightness (cd/m2) • Contrast Ratio 800 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.264 (H) x 0.264 (V) •...
  • Page 52 • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV • EN/IEC 61000-4-6 CS: 3V • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P2002...
  • Page 53 • 1x External FAN Connector, 4-Pin Terminal Block External Fan Storage • 2x 2.5” SATA HDD/SSD Bay, Support RAID 0/1 (Gen3) SSD/HDD • 2x mSATA (One Shared by Mini-PCIe Socket) (Gen2) mSATA • 1x CFast Socket (Gen3) CFast Expansion • 1x PCI or 1x PCIex4 Expansion slot •...
  • Page 54 (with SSD, according to IEC60068-2-64) * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P2002 Series | User Manual...
  • Page 55 Dimensions CV-117/P2002 unit :mm CV-117/P2002E unit :mm CV-100/P2002 Series | User Manual...

  • Page 56: Cv-119/P2002 Series

    1.5.6 CV-119/P2002 Series Model Name CV-119R CV-119C CV-119G Display • 19" (5:4) LCD Size • Max. Resolution 1280 x 1024 • 350 Brightness (cd/m2) • Contrast Ratio 1000 : 1 • 16.7M LCD Color • Pixel Pitch(mm) 0.294 (H) x 0.294 (V) •...
  • Page 57 EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P2002 P2002E System • Onboard 6th Intel® Core™ U processors (Skylake) Processor - Intel® Core™ i5-6300U processor (3M Cache, up to 3.00 GHz) - Intel®...
  • Page 58 • 2x mSATA (One Shared by Mini-PCIe Socket) (Gen2) mSATA • 1x CFast Socket (Gen3) CFast Expansion • 1x PCI or 1x PCIex4 Expansion slot • Optional Riser Card: 1x PCI, 1x PCIex4 PCI Express • Support maximum dimension of add-on card (H x L): 111mm x 202mm •...
  • Page 59 (with SSD, according to IEC60068-2-64) * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P2002 Series | User Manual...
  • Page 60 Dimensions CV-119/P2002 unit :mm CV-119/P2002E unit :mm CV-100/P2002 Series | User Manual...

  • Page 61: Cv-W121/P2002 Series

    1.5.7 CV-W121/P2002 Series Model Name CV-W121R CV-W121C CV-W121C-AG CV-W121G Display • 21.5" (16:9) LCD Size • 1920 x 1080 Max. Resolution • 350 Brightness (cd/m2) • 5000 : 1 Contrast Ratio • 16.7M LCD Color • 0.24825 (H) x 0.24825 (V) Pixel Pitch(mm) •...
  • Page 62 • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P2002 P2002E System • Onboard 6th Intel® Core™ U processors (Skylake) Processor - Intel® Core™ i5-6300U processor (3M Cache, up to 3.00 GHz) - Intel®...
  • Page 63 • 1x CFast Socket (Gen3) CFast Expansion • 1x PCI or 1x PCIex4 Expansion slot • Optional Riser Card: 1x PCI, 1x PCIex4 PCI Express • Support maximum dimension of add-on card (H x L): 111mm x 202mm • 2x Full-size Mini-PCIe Socket Mini PCI Express •...
  • Page 64 (with SSD, according to IEC60068-2-64) * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P2002 Series | User Manual...
  • Page 65 Dimensions CV-W121/P2002 unit :mm CV-W121/P2002E unit :mm CV-100/P2002 Series | User Manual...

  • Page 66: Cv-W124/P2002 Series

    1.5.8 CV-W124/P2002 Series Model Name CV-W124R CV-W124C CV-W124G Display • 24" (16:9) LCD Size • Max. Resolution 1920 x 1080 • 350 Brightness (cd/m2) • Contrast Ratio 5000 : 1 • 16.7M LCD Color • Pixel Pitch(mm) 0.27675 (H) x 0.27675 (V) •...
  • Page 67 • EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV • EN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 3 V/m • EN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kV • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV •...
  • Page 68 • 1x Power On/Off Switch Power Switch • 1x Reset Button Reset Button • 1x Remote Power On/Off Connector, 2-pin Terminal Block Remote Power On/Off • 1x External FAN Connector, 4-Pin Terminal Block External Fan Storage • 2x 2.5” SATA HDD/SSD Bay, Support RAID 0/1 (Gen3) SSD/HDD •...
  • Page 69 (with SSD, according to IEC60068-2-64) * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P2002 Series | User Manual...
  • Page 70 Dimensions CV-W124/P2002 unit :mm CV-W124/P2002E unit :mm CV-100/P2002 Series | User Manual...

  • Page 71: System I/O

    1.6 System I/O 1.6.1 Front DC IN USB 3.0 Used to plug a DC power input with terminal block Used to connect to USB 3.0/2.0/1.1 compatible DVI-D devices Used to connect to a monitor with digital signal USB 2.0 interface Used to connect to USB 2.0/1.1 compatible devices Digital I/O Terminal Block Used to connect to a monitor with analog signal...

  • Page 72: Rear

    1.6.2 Rear CFast and SIM Card Power On/Off Switch CFast card and SIM card slot Power-on or power-off the system HDD/SSD 2.5” SATA HDD/SSD Bay, Support RAID 0/1 1.6.3 Left Antenna Hole Power LED Used to connect an antenna for optional Mini-PCIe Indicates the power status of the system WiFi module HDD LED...

  • Page 73: Right

    1.6.4 Right Antenna Hole Used to connect an antenna for optional Mini-PCIe Used to connect to RS-232/422/485 serial devices WiFi module CV-100/P2002 Series | User Manual...

  • Page 74: Chapter 2 Switches & Connectors

    Chapter 2 Switches & Connectors CV-100/P2002 Series | User Manual...

  • Page 75: Location Of The Switches/Connectors

    2.1 Location of the Switches/Connectors 2.1.1 Top View CV-100/P2002 Series | User Manual...

  • Page 76: Bottom View

    2.1.2 Bottom View CV-100/P2002 Series | User Manual...

  • Page 77: Definition Of Switches/Connectors

    2.2 Definition of Switches/Connectors List of Jumpers/Switches/Connectors Location Definition AT_ATX1 AT / ATX Power Mode Switch BL_PWR1 Backlight Power on / off switching BL_UP1 Backlight Increase BL_DN1 Backlight Decrease CFAST1 CFast Connector COM3~6 with Power Select COM1_1, COM2_1, COM3_1 RS232 / RS422 / RS485 Connector COM4_1, COM5_1, COM6_1 Function setting DC_IN1...

  • Page 78: Definition Of Switches

    2.3 Definition of Switches Super CAP Function Setting: Pin Define SW2 Switch Switch mode Function Super CAP Enable (Default) Disable Clear CMOS Function Setting : Pin Define SW2 Switch Switch mode Function CMOS Clear CMOS Normal (Default) COM1/2 Voltage Function Setting : Pin Define SW2 Switch Switch mode Function ON/ON (Default)
  • Page 79 COM3/4/5/6 Voltage Function Setting : Pin Define SW1 Switch Switch mode Function ON/ON (Default) COM3 ON/OFF OFF/OFF ON/ON (Default) COM4 ON/OFF OFF/OFF ON/ON (Default) COM5 ON/OFF OFF/OFF ON/ON (Default) COM6 ON/OFF OFF/OFF AT_ATX1: AT / ATX Power Mode Switch Definition 1-2 (Left) AT Power Mode 2-3 (Right)
  • Page 80 BL_PWR1: Backlight Power on / off Switch Definition Push Backlight Power on / off switching BL_UP1: Backlight Increase Switch Definition Push Backlight Increase BL_DN1: Backlight Decrease Switch Definition Push Backlight Decrease RESET1: Reset Switch Switch Definition Push Reset System CV-100/P2002 Series | User Manual...

  • Page 81: Definition Of Connectors

    2.4 Definition of Connectors COM1_1/COM2_1/(COM3_1/COM4_1/COM5_1/COM6_1 on the BTB Board): RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 RS485 RS232 Definition Full Duplex Half Duplex Definition Definition DATA - DATA + DC_IN1: DC Power Input Connector (+9~48V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition +9~48VIN...
  • Page 82 LED1: Power / HDD Access LED Status LED Status LED Color Yellow POWER Green POWER3: Power Connector Connector Type: 1X4-pin Wafer, 2.0mm pitch Definition +12V POWER4: Power Connector Connector Type: 1X4-pin Wafer, 2.0mm pitch Definition +12V FAN1: External PWM Fan Connector Connector Type: Terminal Block 1X3 3-pin, 3.5mm pitch Definition +12V...
  • Page 83 CN1: Mini PCI-Express Socket (SIM Card to Link) Pin Definition Pin Definition Pin Definition WAKE# RESERVED +3.3V +3.3V USB_D+ RESERVED PERST# PERN0 +3.3V +1.5V +3.3V CLKREQ# PERN0 RESERVED SIM_DATA +1.5V REFCLK+ SIM_CLK SMB_CLK +1.5V REFCLK+ PETN0 SIM_RESET SMB_DATA PETP0 SIM_VPP +3.3V USB_D- CV-100/P2002 Series | User Manual...
  • Page 84 CN2: Mini PCI-Express Socket / mSATA Socket Pin Definition Pin Definition Pin Definition WAKE# +3.3V +3.3V USB_D+ +3.3V PERST# PERN0/SATAPR0 +3.3V +1.5V +3.3VAUX CLKREQ# PERN0/SATARN0 +1.5V REFCLK+ SMB_CLK +1.5V REFCLK+ PETN0 SMB_DATA PETP0 +3.3V USB_D- CV-100/P2002 Series | User Manual...
  • Page 85 CN3: mSATA Socket Pin Definition Pin Definition Pin Definition WAKE# +3.3V +3.3V USB_D+ +3.3V PERST# SATARXP +3.3V +1.5V +3.3V SATARXN +1.5V SMB_CLK +1.5V SATATXN SMB_DATA SATATXP +3.3V USB_D- CV-100/P2002 Series | User Manual...
  • Page 86 Power Ignition Setting (CFM-IGN100 Only) Connector Location Definition Ignition Function Setting 24V_12V_1 24V/ 12V Power Switching for Ignition Board IGN Board Pin define (CFM-IGN100 Only) SW2: Set shutdown delay timer when ACC is turned off Pin 1 Pin 2 Pin 3 Pin 4 Definition 0 second...

  • Page 87: Chapter 3 System Setup

    Chapter 3 System Setup CV-100/P2002 Series | User Manual...

  • Page 88: Removing Top Cover

    This chapter takes P2002E as an example to demonstrate the installation of hardware components. 3.1 Removing Top Cover In order to prevent electric shock or system damage, must turn off power and disconnect the unit from power source before removing the chassis cover. (Afin d'éviter tout risque d'électrocution ou d'endommagement du système, vous devez couper l'alimentation et débrancher l'appareil de la source d'alimentation avant de retirer le couvercle du châssis.)

  • Page 89: Installing Half Size Mini Pcie Card

    Place the top cover aside gently. 3.2 Installing Half Size Mini PCIe Card Locate the Mini PCIe slot. Use provided two screws on bracket to fasten the module and bracket together. CV-100/P2002 Series | User Manual...
  • Page 90 Tilt the Mini PCIe card at a 45-degree angle and insert it into the socket until the golden finger connector of the card seated firmly. ° Press down the module and use the two screws to fix the module. CV-100/P2002 Series | User Manual...

  • Page 91: Installing Full Size Mini Pcie Card

    3.3 Installing Full Size Mini PCIe Card 1. Locate the Mini PCIe slot. 2. Tilt the Mini PCIe card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly. 45° 3.

  • Page 92: Installing Msata Card

    3.4 Installing mSATA Card Locate the mSATA slot on the system board. Tilt the mSATA card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly. 45° Fasten the card with two screws. CV-100/P2002 Series | User Manual...

  • Page 93: Installing Antenna(S)

    3.5 Installing Antenna(s) Remove the antenna rubber covers on left and right panel. Penetrate the antenna jack through the hole. Put on the washer and fasten the nut with antenna jack. CV-100/P2002 Series | User Manual...
  • Page 94 Assemble the antenna and antenna jack together. Attach the RF connector at another end of the cable onto the card. CV-100/P2002 Series | User Manual...

  • Page 95: Installing So-Dimm Memory

    3.6 Installing SO-DIMM Memory 1. Locate SO-DIMM socket. 2. Tilt the SODIMM module at a 45-degree angle and insert it to SODIMM socket until the gold-pated connector of module contacted firmly with the socket. 3. Press the module down until its fixed firmly by the two locking latches on each side. CV-100/P2002 Series | User Manual...

  • Page 96: Installing Pci(E) Card

    3.7 Installing PCI(e) Card 1. Locate the retention module of PCI(e) expansion card. 2. Loosen one screw halfway as indicated to have the clamp arm slidable. clamp arm 3. Loosen one screw to remove the PCI bracket. CV-100/P2002 Series | User Manual...
  • Page 97 4. Align the notch of golden fingers of PCI(e) card with the expansion slot. Insert the card horizontally, and press the card straight down into the slot until it’s seated firmly. 5. Fasten one screw to secure the PCI(e) expansion card. 6.

  • Page 98: Installing Thermal Pad Of Thermal Block

    7. Finally, fasten the screw that were previously loosen halfway to fix the retention module. 3.8 Installing Thermal Pad of Thermal Block Place thermal pad on the top of CPU thermal block in order to provide a seamless contact with the body of chassis to create an efficient heat dissipation.

  • Page 99: Installing Cfm-Ign Module (Optional)

    3.9 Installing CFM-IGN Module (Optional) Locate the power Ignition connector on system motherboard as indicated. Insert the female connector of power ignition board to the male connector on system motherboard. Fasten two screws to secure the power ignition board. CV-100/P2002 Series | User Manual...

  • Page 100: Installing Cfm-Poe Module (Optional)

    3.10 Installing CFM-PoE Module (Optional) This chapter takes CFM-PoE101 for example. 1. Locate the PoE connector on system motherboard as indicated. 2. Insert the female connector of PoE daughter board to the male connector on system motherboard. 3. Fasten two screws to secure the PoE board. CV-100/P2002 Series | User Manual...

  • Page 101: Installing Top Cover

    3.11 Installing Top Cover 1. Put on the left edge of top cover onto system, and the other side subsequently. 2. Fasten the six screws at front and rear panel to secure the top cover. CV-100/P2002 Series | User Manual...

  • Page 102: Installing Sata Hard Drive At Front Panel

    3.12 Installing SATA Hard Drive at Front Panel 1. Turn over the system to bottom side, and remove one screw. 2. Loosen the two screws to remove the HDD bay cover bracket. 3. Pull the rotating arm of HDD bracket outward as indicated. CV-100/P2002 Series | User Manual...
  • Page 103 4. Hold the rotating arm to pull out the HDD bracket. 5. Place the HDD bracket on screw-hole side of HDD. Use four screws provided to assemble HDD on the bracket. 6. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket and push it until the edge connector of HDD fully inserted into SATA slot.

  • Page 104: Installing Sata Hard Drive On Bottom Side

    7. Put back HDD bay cover at front panel, and fasten it with two screws. 8. Fasten one screw to secure the HDD bracket on the system chassis. 3.13 Installing SATA Hard Drive on Bottom Side Turn over the system to bottom side. Locate the cover of HDD compartment. CV-100/P2002 Series | User Manual...
  • Page 105 Loosen the two screws, then pull the cover to remove it. Loosen three screws and take the HDD bracket out of HDD compartment. Place the HDD bracket on screw-hole side of HDD. Use four screws provided to assemble HDD on the bracket. CV-100/P2002 Series | User Manual...
  • Page 106 Seat the HDD bracket into HDD compartment, and line up the connector of HDD with SATA slot, then push it until HDD is fully connected into slot. Secure the HDD bracket with three screws. Put back the cover and fasten the two screws. CV-100/P2002 Series | User Manual...

  • Page 107: Installing Sim Card

    3.14 Installing SIM Card 1. Locate the SIM card slot at front panel. 2. Loosen two screws to remove the cover plate. 3. Insert the SIM card. CV-100/P2002 Series | User Manual...

  • Page 108: Installing Cfast Card

    3.15 Installing CFast Card 1. Locate the CFast card slot at front panel. 2. Loosen the two screws to remove the cover plate. 3. Insert a CFast card until it clicks. 4. Fasten two screws to secure the cover plate. CV-100/P2002 Series | User Manual...

  • Page 109: Connecting With Cv Display Module

    3.16 Connecting with CV Display Module 1. Prepare the mounting kit that accompanied with P2002 as shown. (including two mounting brackets and one screw pack) 2. Remove six screws at left and right panel of PC2000. 3. Assemble two mounting brackets to left and right panel of PC2000 by fastening three screws at each side.
  • Page 110 4. Turn over the system to bottom side. Locate the connector cover of display module. 5. Loosen two screws to remove the cover. The following photos indicates the male connector (on display module) and female connector (on P2002). CV-100/P2002 Series | User Manual...
  • Page 111 6. Place the P2002 on the display module through its display connector hole as indicated. 7. Align the mounting holes of P2002 with the screw holes of display module underneath. Then slide the PC2000 carefully as indicated to have P2002 and display module connected together. 8.

  • Page 112: Installing Vesa Mount

    3.17 Installing VESA Mount The following picture indicates VESA mounting hole pattern on P2002, which is compliant with VESA mounting standard. 1. The following picture uses a panel PC (P2002+CV display module) as a demonstration. To attach the panel PC to a VESA stand, please fasten eight screws as indicated to fix it on the stand. (Please refer to section 3.16 in this manual for how to attach PC2002 to CV display module.) P2002 + CV display module...

  • Page 113: Installing Panel Mount

    3.18 Installing Panel Mount 1. Accessories provided by Cincoze are as follows. (Please note that the quantity of mounting kits varies with the size of the display module, please refer to the datasheet for the actual quantity) CV-100/P2002 Series | User Manual...
  • Page 114 2. All mounting kits displayed are to be inserted into holes. 3. Installation preparation and steps. CV-100/P2002 Series | User Manual...
  • Page 115 CV-100/P2002 Series | User Manual...
  • Page 116 4. Apply all mount kits to the rest of holes. And you have completed the panel mount installation, as shown below. CV-100/P2002 Series | User Manual...

  • Page 117: Installing Rack Mount

    3.19 Installing Rack Mount 1. Locate the screw holes on the PC or monitor module. Then fasten 8 screws (M4x6) as indicated to fix it on the rack mount base. 2. Assemble two rack mount brackets by fastening 4 screws (M5x6) at each side. For 8.4”...
  • Page 118 For 19” ~ 24” Panel PC For P2002E For P2002 / P1001E For M1101/ P1001 / P1101 / P2102 / P2102E/P2202/P2202E/P2302/P2302E Left Side Right Side Bottom Side 3. Assemble two rack mount brackets by fastening 4 screws (M5x12), flat washers and hex nuts at each side.

  • Page 119: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup CV-100/P2002 Series | User Manual...

  • Page 120: Bios Introduction

    4.1 BIOS Introduction The BIOS (Basic Input/ Output System) is a program located on a Flash Memory on the motherboard. When you start the computer, the BIOS program will gain control. The BIOS first operates an auto-diagnostic test called POST (power on self-test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization.

  • Page 121: Main Setup

    4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. 4.2.1 System Date Set the date.

  • Page 122: Advanced Setup

    4.3 Advanced Setup 4.3.1 ACPI Settings Enable or disable ACPI Auto Configuration. ■ Enable ACPI Auto Configuration [Enabled] Enables or disables BIOS ACPI Auto Configuration. CV-100/P2002 Series | User Manual...

  • Page 123: Amt Configuration

    4.3.2 AMT Configuration This screen allows users to configure related settings of Intel® Active Management Technology. ■ Intel AMT [Enabled] Allows you to enable or disable Intel® Active Management Technology BIOS execution. ■ Un-Configure ME [Disabled] Sets this item to [Disabled] to unconfigure AMT/ME without using a password or set it to [Enabled] to use a password.

  • Page 124: F81866 Super Io Configuration

    ■ Firmware Update Configuration ❑ ME FW Image Re-Flash [Disabled] Allows you to enable or disable ME firmware image re-flash function. 4.3.4 F81866 Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option.

  • Page 125: Hardware Monitor

    ❑ Change Settings [Auto] Used to change the address & IRQ settings of the specified serial port. ❑ Onboard Serial Port 1 Mode [RS232] Change the Serial interface. Select <RS232>, <RS422> or <RS485> interface. ■ Watch Dog [Disabled] You can setup the system watch-dog timer, a hardware timer that generates a reset when the software that it monitors does not respond as expected each time the watch dog polls it.

  • Page 126: S5 Rtc Wake Settings

    4.3.6 S5 RTC Wake Settings ■ Wake System from S5 [Disabled] This item allows users to change the way to wake system from S5 state. [Fixed Time]: Set the specified time (HH:MM:SS) to wake system. [Dynamic Time]: Set the increase time from current time to wake system. 4.3.7 Serial Port Console Redirection ■...

  • Page 127: Cpu Configuration

    4.3.8 CPU Configuration ■ Hyper-Threading [Enabled] Allows you to enable or disable Intel® Hyper-Threading function of processor. ■ Active Process Cores [All] Allows you to choose the number of active processor cores. Configuration options: [All] [1]. ■ Intel® Virtualization Technology [Enabled] Enables or disables Intel®...

  • Page 128: Sata Configuration

    4.3.9 SATA Configuration ■ Serial Controller(s) [Enabled] Allows you to enable or disable Serial ATA controller. ■ SATA Mode [AHCI] This item allows users to choose [AHCI] or [RAID] mode. ■ Software Feature Mask Configuration RAID option ROM (OROM) / Intel® Rapid Storage Technology (RST) driver will refer to the software feature configuration to enable or disable the storage features.

  • Page 129: Csm Configuration

    Enables or disables Intel® Storage Technology (RST) Force Form. ■ Serial ATA Port (Stationary) ❑ Port 0 [Enabled] Enables or disables SATA Port 0. ■ Serial ATA Port (Swappable) ❑ Port 1 [Enabled] Enables or disables SATA Port 1. ❑ Hot Plug [Enabled] Enables or disables Hot Plug support for port1.
  • Page 130 ■ CSM Support [Enabled] Enables or disables UEFI CSM (Compatibility Support Module) to support a legacy PC boot process. ■ Boot option filter [Legacy only] This item allows users to select which type of operating system to boot. [UEFI and Legacy]: Allows booting from operating systems that support legacy option ROM or UEFI option ROM.

  • Page 131: Asmedia Sata Controller Configuration

    4.3.11 Asmedia SATA Controller Configuration ■ SATA Controller 0 Configuration Settings Displays configuration information on SATA Controller 0. CV-100/P2002 Series | User Manual...

  • Page 132: Usb Configuration

    4.3.12 USB Configuration ■ Legacy USB Support [Enabled] This item allows users to enable or disable legacy USB support. When set to [Auto], legacy USB support will be disabled automatically if no USB devices are connected. ■ XHCI Hand-off [Enabled] This item allows users to enable or disable XHCI (USB3.0) hand-off function.

  • Page 133: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 System Agent (SA) Configuration ■ VT-d [Enabled] This item allows users o enable or disable Intel® Virtualization Technology for Directed I/O (VT-d) function. ■...

  • Page 134: Pch-Io Configuration

    ❑ Primary Display [Auto] This item allows users to select which graphics device is used as primary display. [Auto]: auto-detection by BIOS. [IGFX]: Integrated graphics as primary display. [PCIE]: Graphics device on PCIe interface as primary display. ❑ Internal Graphics [Auto] This item allows users to enable or disable Internal Graphics.
  • Page 135 PCI Express Root Port (Mini PCIe) ❑ PCI Express Port 6 [Enabled] Allows you to enable or disable PCI Express Port 6. ❑ PCIe Speed [Auto] Allows you to select PCI Express interface speed. Configuration options: [Auto] [Gen1] [Gen2] [Gen3]. ■...

  • Page 136: Security Setup

    4.5 Security Setup This section allows users to configure BIOS security settings. 4.5.1 Administrator Password Administrator Password controls access to the BIOS Setup utility. 4.5.2 User Password User Password controls access to the system at boot and to the BIOS Setup utility. CV-100/P2002 Series | User Manual...

  • Page 137: Boot Setup

    4.6 Boot Setup This section allows you to configure Boot settings. ■ Setup Prompt Timeout [1] Use this item to set number of seconds (1..65535) to wait for setup activation key. ■ Bootup NumLock State [On] Allows you to select the power-on state for keyboard NumLock. ■...

  • Page 138: Save & Exit

    4.7 Save & Exit ■ Save Changes and Exit This item allows you to exit system setup after saving changes. ■ Discard Changes and Exit This item allows you to exit system setup without saving changes. ■ Save Changes and Reset This item allows you to reset the system after saving changes.

  • Page 139: Chapter 5 Product Application

    Chapter 5 Product Application CV-100/P2002 Series | User Manual...

  • Page 140: Digital I/O (Dio) Application

    This section describes DIO application of the product. The content and application development are better understood and implemented by well experienced professionals or developers. 5.1.1 Digital I/O Programming Guide 5.1.1.1 Pins for Digital I/O of Cincoze P1001 series product Item Standard...
  • Page 141 To program the Super I/O chip F81866A configuration registers, the following configuration procedures must be followed in sequence: (1) Enter the Extended Function Mode (2) Configure the configuration registers (3) Exit the Extended Function Mode The configuration register is used to control the behavior of the corresponding devices. To configure the register, use the index port to select the index and then write data port to alter the parameters.
  • Page 142 CV-100/P2002 Series | User Manual...
  • Page 143 5.1.1.4 Sample Code in C Language 5.1.1.4.1 Control of GP70 to GP77 #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) // Select logic device 06h <Input Mode Selection>...
  • Page 144 WriteByte(DataPort, (ReadByte(DataPort) ǀ 0x00)) // Set (bit 0~7) = 0 to select GP 70~77 as Input mode. <Input Value> WriteByte(AddrPort, 0x82) // Select configuration register 82h ReadByte(DataPort, Value) // Read bit 0~7 (0xFF)= GP70 ~77 as High. <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) 5.1.1.4.2 Control of GP80 to GP87 #define AddrPort 0x4E...
  • Page 145 // Select configuration register 60h WriteByte(DataPort, (ReadByte(DataPort) ǀ 0x03)) WriteByte(AddrPort, 0x61) // Select configuration register 61h WriteByte(DataPort, (ReadByte(DataPort) ǀ 0x20)) <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Note: Cincoze DIO Port base address is 0x0A00h. CV-100/P2002 Series | User Manual...
  • Page 146 5.1.1.6 DATA Bit Table (DIO) CV-100/P2002 Series | User Manual...
  • Page 147 5.1.1.7 DIO I/O Port Address DI8 DI7 DI6 DI5 DI4 DI3 DI2 DI1 DO8 DO7 DO6 DO5 DO4 DO3 DO2 DO1 Pin Definition Data Bits 0xA03 0xA02 I/O Port address CV-100/P2002 Series | User Manual...

  • Page 148: Digital I/O (Dio) Hardware Specification

    5.2 Digital I/O (DIO) Hardware Specification ⚫ XCOM+/ 2XCOM+: Isolated power in V+ ⚫ XCOM-/ 2XCOM-: Isolated power in V- ⚫ Isolated power in DC voltage: 9~30V ⚫ 8x/ 16x Digital Input (Source Type) ⚫ Input Signal Voltage Level Signal Logic 0: XCOM+ = 9V, Signal Low <...

  • Page 149: P2002 Dio Connector Definition

    5.2.1 P2002 DIO Connector Definition DIO1/DIO2 : Digital Input / Output Connector Connector Type: Terminal Block 2X10 10-pin, 3.5mm pitch Definition Definition DC INPUT DC INPUT CV-100/P2002 Series | User Manual...
  • Page 150 CV-100/P2002 Series | User Manual...
  • Page 151 © 2020 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.

This manual is also suitable for:

Cv-112hr/p2002-i5Cv-112hr/p2002e-i5Cv-112hr/p2002e-i5-e4Cv-112hr/p2002e-i5-piCv-112hc/p2002-i5Cv-112hc/p2002e-i5 ... Show all

Table of Contents
