CV-100/P1201 Series
User Manual
Power Efficient Industrial Panel PC
8.4"~24" TFT LCD Panel PC with Intel® Elkhart Lake Atom® x6000E Series
Processor
Version: V1.13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CV-108/P1201 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Cincoze CV-108/P1201 Series

Summary of Contents for Cincoze CV-108/P1201 Series

  • Page 1 CV-100/P1201 Series User Manual Power Efficient Industrial Panel PC 8.4”~24” TFT LCD Panel PC with Intel® Elkhart Lake Atom® x6000E Series Processor Version: V1.13...

  • Page 2: Table Of Contents

    Chapter 1 Product Introductions ......................14 1.1 Overview ..........................15 1.2 Highlights..........................15 1.3 Key Features ........................... 16 1.4 Hardware Specification ......................17 1.4.1 CV-108/P1201 Series....................17 1.4.2 CV-110/P1201 Series....................21 1.4.3 CV-110H/P1201 Series ....................25 1.4.4 CV-112H/P1201 Series ....................29 1.4.5 CV-115/P1201 Series....................33 1.4.6 CV-W115/P1201 Series ....................
  • Page 3 2.3 Definition of Switches ......................68 2.4 Definition of Connectors ......................70 Chapter 3 System Setup ........................74 3.1 Removing Top Cover....................... 75 3.2 Installing SO-DIMM Memory ....................76 3.3 Installing Mini-PCIe Card ......................77 3.4 Installing M.2 E Key Card ......................78 3.5 Installing Antenna ........................
  • Page 4 6.1 Pin Definition & Settings ...................... 119 6.1.1 CFM-IGN101 ......................119 6.2 Installing CFM Modules ......................120 6.2.1 CFM-IGN101 ......................120 6.2.2 CFM-PoE02 ........................ 121 6.3 Installing Accessories ......................123 6.3.1 VESA Mounting ......................123 6.3.2 URM01 ........................124 CV-100/P1201 Series | User Manual...

  • Page 5: Preface

    2025/03/28 Copyright Notice © 2023 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.

  • Page 6: Declaration Of Conformity

    (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain an RMA number from us. Our staff is available at any time to provide you with the most friendly and immediate service.

  • Page 7: Technical Support And Assistance

    Limitation of Liability Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.

  • Page 8: Conventions Used In This Manual

    Conventions Used in this Manual This indication alerts operators to an operation that, if not strictly observed, may result in severe injury. (Cette indication avertit les opérateurs d'une opération qui, si elle n'est pas strictement observée, peut entraîner des blessures graves.) This indication alerts operators to an operation that, if not strictly observed, may result in safety hazards to personnel or damage to equipment.
  • Page 9 13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel. If one of the following situations arises, get the equipment checked by service personnel: ⚫ The power cord or plug is damaged. ⚫...

  • Page 10: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty CV-100/P1201 Series Panel PC Thermal Pad (for CPU Thermal Block) DIO Terminal Block Connector (Female) Panel Mounting Kit (The quantity varies with the size of the display module, please refer to the datasheet for the actual quantity) Power Terminal Block Connector (Female) Screw Pack...
  • Page 11 10.4" TFT-LCD XGA 4:3 Panel PC with Intel Atom x6425E CV-110HR/P1201-X6425E Quad Core Processor and Resistive 5-wire Touch 10.4" TFT-LCD XGA 4:3 Panel PC with Intel Atom x6425E CV-110HC/P1201-X6425E Quad Core Processor and P-Cap. Touch 10.4" TFT-LCD XGA 4:3 Panel PC with Intel Atom x6211E CV-110HR/P1201-X6211E Dual Core Processor and Resistive 5-wire Touch 10.4"...
  • Page 12 17" TFT-LCD SXGA 5:4 Panel PC with Intel Atom x6425E CV-117C/P1201-X6425E Quad Core Processor and P-Cap. Touch 17" TFT-LCD SXGA 5:4 Panel PC with Intel Atom x6425E CV-117G/P1201-X6425E Quad Core Processor and without Touch 17" TFT-LCD SXGA 5:4 Panel PC with Intel Atom x6211E CV-117R/P1201-X6211E Dual Core Processor and Resistive 5-wire Touch 17"...
  • Page 13 15.6" TFT-LCD Full HD 16:9 Panel P C with Intel Atom CV-W115FHC/P1201-X6425E x6425E Quad Core Processor and P-Cap. Touch 15.6" TFT-LCD Full HD 16:9 Panel P C with Intel Atom CV-W115FHR/P1201-X6211E x6211E Dual Core Processor and Resistive 5-wire Touch 15.6" TFT-LCD Full HD 16:9 Panel P C with Intel Atom CV-W115FHC/P1201-X6211E x6211E Dual Core Processor and P-Cap.

  • Page 14: Chapter 1 Product Introductions

    Chapter 1 Product Introductions CV-100/P1201 Series | User Manual...

  • Page 15: Overview

    I/O interfaces (GbE LAN, USB 3.2, COM, and DIO), Mini PCIe and M.2 Key E Type 2230 expansion slots, and exclusive CFM expansion to add functions such as PoE and IGN. Cincoze’s exclusive patented Convertible Display System (CDS) technology enables further flexible future computer performance upgrades and screen replacements.

  • Page 16: Key Features

    ⚫ 1x DDR4 SO-DIMM ⚫ Designed with Rugged Aluminum Die-casting Front Bezel ⚫ Support Panel / VESA / Rack Mount ⚫ Front Panel IP65 Compliant ⚫ Wide Operating Temperature ⚫ Cincoze Patent CDS Technology Support CV-100/P1201 Series | User Manual...

  • Page 17: Hardware Specification

    1.4 Hardware Specification 1.4.1 CV-108/P1201 Series Model Name CV-108R CV-108C Display • 8.4" (4:3) LCD Size • 800 x 600 Max. Resolution • 400 Brightness (cd/m2) • 600 : 1 Contrast Ratio • 262K LCD Color • 0.213 (H) x 0.213 (V) Pixel Pitch(mm) •...
  • Page 18 • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P1201 System • Intel® Atom® x6425E Processor (1.5M Cache, up to 3.00 GHz, 12W) Processor • Intel® Atom® x6211E Processor (1.5M Cache, up to 3.00 GHz, 6W) • 1x DDR4 SO-DIMM Socket Memory •...
  • Page 19 Other Function • 1x Clear CMOS Switch Clear CMOS Switch • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button •...
  • Page 20 • UL, cUL, CB, IEC/ EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-108/P1201...

  • Page 21: Cv-110/P1201 Series

    1.4.2 CV-110/P1201 Series Model Name CV-110R CV-110C Display • 10.4" (4:3) LCD Size • 800 x 600 Max. Resolution • 400 Brightness (cd/m2) • 700 : 1 Contrast Ratio • 16.2M LCD Color • Pixel Pitch(mm) 0.264 (H) x 0.264 (V) •...
  • Page 22 Model Name P1201 System • Intel® Atom® x6425E Processor (1.5M Cache, up to 3.00 GHz, 12W) Processor • Intel® Atom® x6211E Processor (1.5M Cache, up to 3.00 GHz, 6W) • 1x DDR4 SO-DIMM Socket Memory • Supports DDR4 3200MHz Memory Up to 32GB (un-buffered and non-ECC) •...
  • Page 23 • 1x Clear CMOS Switch Clear CMOS Switch • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button •...
  • Page 24 • UL, cUL, CB, IEC/ EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-110/P1201...

  • Page 25: Cv-110H/P1201 Series

    1.4.3 CV-110H/P1201 Series Model Name CV-110HR CV-110HC Display • 10.4" (4:3) LCD Size • Max. Resolution 1024 x 768 • 470 Brightness (cd/m2) • Contrast Ratio 1000 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.2055 (H) x 0.2055 (V) •...
  • Page 26 Model Name P1201 System • Intel® Atom® x6425E Processor (1.5M Cache, up to 3.00 GHz, 12W) Processor • Intel® Atom® x6211E Processor (1.5M Cache, up to 3.00 GHz, 6W) • 1x DDR4 SO-DIMM Socket Memory • Supports DDR4 3200MHz Memory Up to 32GB (un-buffered and non-ECC) •...
  • Page 27 • 1x Clear CMOS Switch Clear CMOS Switch • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button •...
  • Page 28 • UL, cUL, CB, IEC/ EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-110H/P1201...

  • Page 29: Cv-112H/P1201 Series

    1.4.4 CV-112H/P1201 Series Model Name CV-112HR CV-112HC Display • 12.1" (4:3) LCD Size • Max. Resolution 1024 x 768 • 500 Brightness (cd/m2) • Contrast Ratio 700 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.24 (H) x 0.24 (V) •...
  • Page 30 Model Name P1201 System • Intel® Atom® x6425E Processor (1.5M Cache, up to 3.00 GHz, 12W) Processor • Intel® Atom® x6211E Processor (1.5M Cache, up to 3.00 GHz, 6W) • 1x DDR4 SO-DIMM Socket Memory • Supports DDR4 3200MHz Memory Up to 32GB (un-buffered and non-ECC) •...
  • Page 31 • 1x Clear CMOS Switch Clear CMOS Switch • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button •...
  • Page 32 • UL, cUL, CB, IEC/ EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-112H/P1201...

  • Page 33: Cv-115/P1201 Series

    1.4.5 CV-115/P1201 Series Model Name CV-115R CV-115C CV-115C-AG Display • 15" (4:3) LCD Size • Max. Resolution 1024 x 768 • 350 Brightness (cd/m2) • Contrast Ratio 800 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.297 (H) x 0.297 (V) •...
  • Page 34 Model Name P1201 System • Intel® Atom® x6425E Processor (1.5M Cache, up to 3.00 GHz, 12W) Processor • Intel® Atom® x6211E Processor (1.5M Cache, up to 3.00 GHz, 6W) • 1x DDR4 SO-DIMM Socket Memory • Supports DDR4 3200MHz Memory Up to 32GB (un-buffered and non-ECC) •...
  • Page 35 • 1x Clear CMOS Switch Clear CMOS Switch • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button •...
  • Page 36 • UL, cUL, CB, IEC/ EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-115/P1201...

  • Page 37: Cv-W115/P1201 Series

    1.4.6 CV-W115/P1201 Series Model Name CV-W115R CV-W115C Display • 15.6" (16:9) LCD Size • Max. Resolution 1366 x 768(WXGA) • 400 Brightness (cd/m2) • Contrast Ratio 500 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.252 (H) x 0.252 (V) •...
  • Page 38 Model Name P1201 System • Intel® Atom® x6425E Processor (1.5M Cache, up to 3.00 GHz, 12W) Processor • Intel® Atom® x6211E Processor (1.5M Cache, up to 3.00 GHz, 6W) • 1x DDR4 SO-DIMM Socket Memory • Supports DDR4 3200MHz Memory Up to 32GB (un-buffered and non-ECC) •...
  • Page 39 • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button • AMP 2W + 2W Internal Speaker •...
  • Page 40 • UL, cUL, CB, IEC/ EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-W115/P1201...

  • Page 41: Cv-W115Fh/P1201 Series

    1.4.7 CV-W115FH/P1201 Series Model Name CV-W115FHR CV-W115FHC Display • 15.6" (16:9) LCD Size • Max. Resolution 1920 x 1080 (Full HD) • 350 Brightness (cd/m2) • Contrast Ratio 800 : 1 • 16.7M LCD Color • Pixel Pitch(mm) 0.17925 (H) x 0.17925 (V) •...
  • Page 42 Model Name P1201 System • Intel® Atom® x6425E Processor (1.5M Cache, up to 3.00 GHz, 12W) Processor • Intel® Atom® x6211E Processor (1.5M Cache, up to 3.00 GHz, 6W) • 1x DDR4 SO-DIMM Socket Memory • Supports DDR4 3200MHz Memory Up to 32GB (un-buffered and non-ECC) •...
  • Page 43 • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button • AMP 2W + 2W Internal Speaker •...
  • Page 44 • UL, cUL, CB, IEC/ EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-W115FH/P1201...

  • Page 45: Cv-117/P1201 Series

    1.4.8 CV-117/P1201 Series Model Name CV-117R CV-117C CV-117G Display • 17" (5:4) LCD Size • Max. Resolution 1280 x 1024 • 350 Brightness (cd/m2) • Contrast Ratio 800 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.264 (H) x 0.264 (V) •...
  • Page 46 • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P1201 System • Intel® Atom® x6425E Processor (1.5M Cache, up to 3.00 GHz, 12W) Processor • Intel® Atom® x6211E Processor (1.5M Cache, up to 3.00 GHz, 6W) • 1x DDR4 SO-DIMM Socket Memory •...
  • Page 47 Other Function • 1x Clear CMOS Switch Clear CMOS Switch • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button •...
  • Page 48 • UL, cUL, CB, IEC/ EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-117/P1201...

  • Page 49: Cv-119/P1201 Series

    1.4.9 CV-119/P1201 Series Model Name CV-119R CV-119C CV-119G Display • 19" (5:4) LCD Size • Max. Resolution 1280 x 1024 • 350 Brightness (cd/m2) • Contrast Ratio 1000 : 1 • 16.7M LCD Color • Pixel Pitch(mm) 0.294 (H) x 0.294 (V) •...
  • Page 50 Model Name P1201 System • Intel® Atom® x6425E Processor (1.5M Cache, up to 3.00 GHz, 12W) Processor • Intel® Atom® x6211E Processor (1.5M Cache, up to 3.00 GHz, 6W) • 1x DDR4 SO-DIMM Socket Memory • Supports DDR4 3200MHz Memory Up to 32GB (un-buffered and non-ECC) •...
  • Page 51 • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button • AMP 2W + 2W Internal Speaker •...
  • Page 52 * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-119/P1201 Unit: mm CV-100/P1201 Series | User Manual...

  • Page 53: Cv-W121/P1201 Series

    1.4.10 CV-W121/P1201 Series Model Name CV-W121R CV-W121C CV-W121G Display • 21.5" (16:9) LCD Size • Max. Resolution 1920 x 1080 • 350 Brightness (cd/m2) • Contrast Ratio 5000 : 1 • 16.7M LCD Color • Pixel Pitch(mm) 0.24825 (H) x 0.24825 (V) •...
  • Page 54 Model Name P1201 System • Intel® Atom® x6425E Processor (1.5M Cache, up to 3.00 GHz, 12W) Processor • Intel® Atom® x6211E Processor (1.5M Cache, up to 3.00 GHz, 6W) • 1x DDR4 SO-DIMM Socket Memory • Supports DDR4 3200MHz Memory Up to 32GB (un-buffered and non-ECC) •...
  • Page 55 • 1x Reset Button Reset Button • Support 0.2sec Instant Reboot Technology Instant Reboot • Software Programmable Supports 256 Levels System Reset Watchdog Timer • LCD On/Off, Brightness Up, Brightness Down OSD Button • AMP 2W + 2W Internal Speaker •...
  • Page 56 * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-W121/P1201 Unit: mm CV-100/P1201 Series | User Manual...

  • Page 57: Cv-W124/P1201 Series

    1.4.11 CV-W124/P1201 Series Model Name CV-W124R CV-W124C CV-W124G Display • 24" (16:9) LCD Size • Max. Resolution 1920 x 1080 • 350 Brightness (cd/m2) • Contrast Ratio 5000 : 1 • 16.7M LCD Color • Pixel Pitch(mm) 0.27675 (H) x 0.27675 (V) •...
  • Page 58 • EN/IEC 61000-4-6 CS: 3V • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz • Safety UL, cUL, CB, IEC, EN 62368-1 Model Name P1201 System • Intel® Atom® x6425E Processor (1.5M Cache, up to 3.00 GHz, 12W) Processor •...
  • Page 59 • 1x CFM PoE Interface for optional CFM-PoE Module Expansion Interface CDS (Convertible Display • 1x CDS Interface for Convertible Display Module System) Interface Other Function • 1x Clear CMOS Switch Clear CMOS Switch • 1x Reset Button Reset Button •...
  • Page 60 • UL, cUL, CB, IEC/ EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-W124/P1201...

  • Page 61: System I/O

    1.5 System I/O 1.5.1 Front Antenna Clear CMOS Used to clear CMOS to reset BIOS Used to install an antenna jack Front Accessible 2.5” HDD Tray SIM Card Slot Used to inserts a 2.5” HDD/SSD Used to inserts a SIM card Power LED Reset Switch Indicates the power status of the system...

  • Page 62: Right

    1.5.3 Right COM3 Mic-In COM port supports RS232/422/485 serial device Used to connect a microphone Line-Out The Digital I/O terminal block supports 4 digital input Used to connect a speaker and 4 digital output Antenna USB 2.0 Used to install an antenna jack Used to connect USB 2.0/1.1 device 1.5.4 Left Temperature LED...

  • Page 63: Top

    1.5.5 Top VESA Mounting Hole These are mounting holes for VESA mount (75x75mm and 100x100mm) CV-100/P1201 Series | User Manual...

  • Page 64: Chapter 2 Switches & Connectors

    Chapter 2 Switches & Connectors CV-100/P1201 Series | User Manual...

  • Page 65: Location Of Switches And Connectors

    2.1 Location of Switches and Connectors 2.1.1 Top View CV-100/P1201 Series | User Manual...

  • Page 66: Bottom View

    2.1.2 Bottom View CV-100/P1201 Series | User Manual...

  • Page 67: Switches And Connectors Definition

    2.2 Switches and Connectors Definition Location Definition AT_ATX1 AT / ATX Power Mode Switch CLR_CMOS1 Clear CMOS Switch RESET1 Reset Button BL_UP1 Backlight Brightness Increase Button BL_DN1 Backlight Brightness Decrease Button BL_PWR1 Backlight Power On / Off Button PWR_SW1 Power Switch Super CAP SW PWR_SSD_LED1 Power LED/ HDD LED...
