Summary of Contents for Cincoze CV-108R-R10/P1001

  • Page 2: Table Of Contents

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Contents Prefaces Revision …………………………………………………..……………….….…….. 04 Copyright Notice …………………………………………………………………… 04 Acknowledgement ……………………………………………………..... 04 Disclaimer ………………………………………………………….……………….. 04 Declaration of Conformity ……………………………………….………………… 04 Product Warranty Statement ……………………………………….…………….. 05 Technical Support and Assistance ………………………………….……………. 06 Conventions Used in this Manual …………………………………….………….. 06 Safety Precaution …..…………………………………….…………….…………..
  • Page 3 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4 BIOS Setup 4.1 BIOS Introduction …….……….…………….…….…..….…………... 78 4.2 Main Setup ……..……….………………….…..….………………..79 4.2.1 System Date …….……………………………………………..79 4.2.2 System Time ………..…………………………………………... 79 4.3 Advanced Setup ……………………………………………………….. 80 4.3.1 ACPI Settings ……..……………………………………………. 80 4.3.2 Super IO Configuration ………………………………………...

  • Page 4: Prefaces

    2016/12/22 Copyright Notice © 2016 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd.

  • Page 5: Product Warranty Statement

    1 Year Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain a RMA number from us. Our staff is available at any time to provide you with the most friendly and immediate service.

  • Page 6: Technical Support And Assistance

    | User’s Manual Industrial Panel PC Prefaces Technical Support and Assistance 1. Visit the Cincoze website at www.cincoze.com/support.php where you can find the latest information about the product. 2. Contact your distributor or our technical support team or sales representative for technical support if you need additional assistance.

  • Page 7: Safety Precaution

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Prefaces Safety Precaution Before installing and using this device, please note the following precautions: 1. Read these safety instructions carefully. 2. Keep this User’s Manual for future reference. 3. Disconnected this equipment from any AC outlet before cleaning. 4.

  • Page 8: Package Contents

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Prefaces Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Q’ty Item Description Panel PC Panel Mounting Kit Utility DVD Driver DIO Terminal Block Connector Power Terminal Block Connector Screw Pack Note: Notify your sales representative if any of the above items are missing or damaged.

  • Page 9: Ordering Information

    Description 8.4" TFT SVGA 4:3 Panel PC with Resistive 5-wire Touch, w/ Intel Atom E3845 Quad CV-108R-R10/P1001 Core, 4x USB, 2x COM, 1x VGA and 1x DisplayPort 8.4" TFT SVGA 4:3 Panel PC with Resistive 5-wire Touch, w/ Intel Atom E3845 Quad...
  • Page 10 CV-100/P1000 Series | User’s Manual Industrial Panel PC Prefaces Ordering Information Model No. Description 12.1" TFT XGA 4:3 Panel PC with Resistive 5-wire Touch, w/ Intel Atom E3845 Quad CV-112HR-R10/P1001 Core, 4x USB, 2x COM, 1x VGA and 1x DisplayPort 12.1"...
  • Page 11 CV-100/P1000 Series | User’s Manual Industrial Panel PC Prefaces Ordering Information Model No. Description 17" TFT SXGA 5:4 Panel PC with Projected Capacitive Touch, w/ Intel Atom E3845 CV-117C-R10/P1001 Quad Core, 4x USB, 2x COM, 1x VGA and 1x DisplayPort 17"...
  • Page 12 Chapter 1 Product Introductions...

  • Page 13: Chapter 1 Product Introductions

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.1 Overview The CV-100/P1000 Series all-in-one panel PC offers LED backlight LCD. It features flat surface and IP65 dust/waterproof front panel. In addition, designed with aluminum die-cast front frame with rugged body structure that can be able to apply in industrial applications.

  • Page 14: Cv-108/P1001

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2 Hardware Specification 1.2.1 CV-108/P1000 CV-108/P1000 Display • LCD Size: 8.4" (4:3) • Max. Resolution: 800 x 600 • Brightness (cd/m2): 400 • Contrast Ratio: 600 : 1 •...
  • Page 15 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Processor System Other Features • Onboard Intel® Atom™ Processor E3845 Quad • Watchdog Timer: Software Programmable Core, 1.91 GHz with AMI 64Mbit SPI BIOS. Supports 1~255 sec. • Audio: AMP 2W + 2W (Internal Speaker) Memory •...
  • Page 16 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-108/P1001...
  • Page 17 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-108/P1001E...

  • Page 18: Cv-110/P1001

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2.2 CV-110/P1000 CV-110/P1000 CV-110H/P1000 Display Display • LCD Size: 10.4" (4:3) • LCD Size: 10.4" (4:3) • Max. Resolution: 800 x 600 • Max. Resolution: 1024 x 768 •...
  • Page 19 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Processor System Other Features • Onboard Intel® Atom™ Processor E3845 Quad • Watchdog Timer: Software Programmable Core, 1.91 GHz with AMI 64Mbit SPI BIOS. Supports 1~255 sec. • Audio: AMP 2W + 2W (Internal Speaker) Memory •...
  • Page 20 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-110/P1001 CV-110H/P1001...
  • Page 21 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-110/P1001E CV-110H/P1001E...

  • Page 22: Cv-112/P1001

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2.3 CV-112/P1000 CV-112/P1000 CV-112H/P1000 Display Display • LCD Size: 12.1" (4:3) • LCD Size: 12.1" (4:3) • Max. Resolution: 800 x 600 • Max. Resolution: 1024 x 768 •...
  • Page 23 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Processor System Other Features • Onboard Intel® Atom™ Processor E3845 Quad • Watchdog Timer: Software Programmable Core, 1.91 GHz with AMI 64Mbit SPI BIOS. Supports 1~255 sec. • Audio: AMP 2W + 2W (Internal Speaker) Memory •...
  • Page 24 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-112/P1001 CV-112H/P1001...
  • Page 25 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-112/P1001E CV-112H/P1001E...

  • Page 26: Cv-115/P1001

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2.4 CV-115/P1000 CV-115/P1000 Display • LCD Size: 15" (4:3) • Max. Resolution: 1024 x 768 • Brightness (cd/m2): 350 • Contrast Ratio: 700 : 1 • LCD Color: 16.2M •...
  • Page 27 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Processor System Other Features • Onboard Intel® Atom™ Processor E3845 Quad • Watchdog Timer: Software Programmable Core, 1.91 GHz with AMI 64Mbit SPI BIOS. Supports 1~255 sec. • Audio: AMP 2W + 2W (Internal Speaker) Memory •...
  • Page 28 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-115/P1001...
  • Page 29 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-115/P1001E...

  • Page 30: Cv-W115/P1001

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2.4 CV-W115/P1000 CV-W115/P1000 Display • LCD Size: 15.6" (16:9) • Max. Resolution: 1366 x 768 • Brightness (cd/m2): 400 • Contrast Ratio: 500 : 1 • LCD Color: 16.2M •...
  • Page 31 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Processor System Other Features • Onboard Intel® Atom™ Processor E3845 Quad • Watchdog Timer: Software Programmable Core, 1.91 GHz with AMI 64Mbit SPI BIOS. Supports 1~255 sec. • Audio: AMP 2W + 2W (Internal Speaker) Memory •...
  • Page 32 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-W115/P1001...
  • Page 33 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-W115/P1001E...

  • Page 34: Cv-117/P1001

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2.5 CV-117/P1000 CV-117/P1000 Display • LCD Size: 17" (5:4) • Max. Resolution: 1280 x 1024 • Brightness (cd/m2): 350 • Contrast Ratio: 800 : 1 • LCD Color: 16.7M •...
  • Page 35 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Processor System Other Features • Onboard Intel® Atom™ Processor E3845 Quad • Watchdog Timer: Software Programmable Core, 1.91 GHz with AMI 64Mbit SPI BIOS. Supports 1~255 sec. • Audio: AMP 2W + 2W (Internal Speaker) Memory •...
  • Page 36 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-117/P1001...
  • Page 37 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-117/P1001E...

  • Page 38: Cv-119/P1001

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2.6 CV-119/P1000 CV-119/P1000 Display • LCD Size: 19" (5:4) • Max. Resolution: 1280 x 1024 • Brightness (cd/m2): 350 • Contrast Ratio: 1000 : 1 • LCD Color: 16.7M •...
  • Page 39 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Processor System Other Features • Onboard Intel® Atom™ Processor E3845 Quad • Watchdog Timer: Software Programmable Core, 1.91 GHz with AMI 64Mbit SPI BIOS. Supports 1~255 sec. • Audio: AMP 2W + 2W (Internal Speaker) Memory •...
  • Page 40 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-119/P1001...
  • Page 41 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-119/P1001E...

  • Page 42: Cv-W121/P1001

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2.7 CV-W121/P1000 CV-W121/P1000 Display • LCD Size: 21.5" (16:9) • Max. Resolution: 1920 x 1080 • Brightness (cd/m2): 300 • Contrast Ratio: 5000 : 1 • LCD Color: 16.7M •...
  • Page 43 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Processor System Other Features • Onboard Intel® Atom™ Processor E3845 Quad • Watchdog Timer: Software Programmable Core, 1.91 GHz with AMI 64Mbit SPI BIOS. Supports 1~255 sec. • Audio: AMP 2W + 2W (Internal Speaker) Memory •...
  • Page 44 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-W121/P1001...
  • Page 45 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions Dimension Unit: mm CV-W121/P1001E...

  • Page 46: System I/O

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2 System I/O 1.2.1 Front ATX Power on/off switch CFast and SIM card Slot Press to power-on or power-off the system Used to insert a CFast card and SIM card Antenna hole External HDD Bay Used to insert a 2.5”...

  • Page 47: Rear

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2.2 Rear DC IN USB 2.0 port Used to plug a DC power input with terminal Used to connect USB 2.0/1.1 device block LAN port Reset Button Used to connect the system to a local area Used to reset the system network Mic-in...

  • Page 48: Side (Left)

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2.3 Side (Left) USB 3.0 port Digital I/O Terminal Block Used to connect USB 3.0/2.0/1.1 device The Digital I/O terminal block supports 4 digital input and 4 digital output USB 2.0 port AT/ATX mode select switch Used to connect USB 2.0/1.1 device...

  • Page 49: Side (Right)

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2.4 Side (Right) COM port OSD Function COM 2 supports RS232/422/485 serial LCD On/Off device Press to turn-on or turn-off the display Increase Brightness DisplayPort Press to increase brightness of the screen Used to connect a Display Port devices Decrease Brightness Press to decrease brightness of the screen...

  • Page 50: Top

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 1: Product Introductions 1.2.5 Top VESA Mounting Hole These are mounting holes for VESA mount (75x75mm and 100x100mm)

  • Page 51: Chapter 2 Jumpers And Connectors

    Chapter 2 Jumpers and Connectors...

  • Page 52: Jumper Settings

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors 2.1 Jumpers Settings When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open.

  • Page 53: Bottom View

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors 2.2.2 Bottom View...

  • Page 54: Connector / Jumper / Switch Definition

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors 2.3 Connector / Jumper / Switch Definitions Connector Location Definition AT_ATX1 AT / ATX Power Mode Switch BL_PWR1 Backlight Power on / off switching BL_UP1 Backlight Increase BL_DN1 Backlight Decrease CFAST1...

  • Page 55: Switches Definition

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors 2.4 Switch Definitions AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Left) ATX Power Mode（Default） 2-3 (Right) AT Power Mode CLR_CMOS1: Clear CMOS Switch Switch Definition Normal Status (Default) Clear CMOS...

  • Page 56: Jumpers Definition

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors 2.5 Jumper Definitions COM12_SEL1: COM1 / COM2 with Power Select Connector Type: 2X5 10-pin Header, 2.0mm pitch COM1 COM2 Definition Definition 1-3 On 2-4 On 3-5 On +12V 4-6 On +12V...
  • Page 57 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors COM1_1: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 RS485 RS232 Full Duplex Half Duplex Definition Definition Definition DCD1 TX1- DATA1- Power over Serial PIN Definitions RxD1 TX1+ DATA1+...
  • Page 58 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors DC_IN1: DC Power Input Connector (+9~48V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition +9~48VIN Chassis GND DIO1: Digital Input / Output Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition DC INPUT...
  • Page 59 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors DP1: DisplayPort Connector Definition Definition DP_LANE0_P DP_LANE3_N DP_LANE0_N DP_LANE1_P DP_AUX_P DP_LANE1_N DP_LANE2_P DP_AUX_N DP_HPD DP_LANE2_N DP_LANE3_P DP_PWR...
  • Page 60 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors LAN1: RJ45 with LEDs Port Definition Definition LAN1_MDI0P LAN1_MDI2N LAN1_MDI0N LAN1_MDI1N LAN1_MDI1P LAN1_MDI3P LAN1_MDI2P LAN1_MDI3N Act LED Status Definition Link LED Status Definition Blinking Yellow Data Activity Steady Green 1Gbps Network Link No Activity...
  • Page 61 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors LINE_OUT1: Line-out Jack (Green) MIC1: Microphone Jack (Pink) Connector Type: 5-pin Phone Jack Connector Type: 5-pin Phone Jack Definition Definition OUT_R MIC_R OUT_L MIC_L MINIPCIE1: Mini PCI-Express Socket Definition Definition Definition...
  • Page 62 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors POWER1: Power Connector PWR_SW1：Power Switch Connector Connector Type: 1X4-pin Wafer, 2.0mm pitch Definition Definition Power switch +12V SATA1: SATA with Power Connector Definition Definition SATA_TX1+ SATA_TX1- SATA_RX1- SATA_RX1+ +3.3V +3.3V...
  • Page 63 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors SPK_L1: Left Internal Speaker Connector SPK_R1: Right Internal Speaker Connector Definition Definition OUT_L OUT_R USB1_2_1：USB2.0 Connector, Type A Definition Definition USB_DATA0- USB_DATA_1- USB_DATA0+ USB_DATA_1+ USB2_1: USB2.0 Connector, Type A Definition USB2_DATA1- USB2_DATA1+...

  • Page 64: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 65: Removing The Top Cover

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 3: System Setup 3.1 Removing the Top Cover In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.

  • Page 66: Installing A Half Size Mini Pcie Card

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 3: System Setup 3.2 Installing a Half Size Mini PCIe Card 1. Locate the Mini PCIe socket. 2. Use two screws provided on bracket to fasten the module and bracket together. 3.

  • Page 67: Installing A Full Size Mini Pcie Card

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 3: System Setup 4. Press the module down and use the two screws to fix the module. 3.3 Installing a Full Size Mini PCIe Card 1. Locate the Mini PCIe socket. 2.

  • Page 68: Installing Antennas

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 3: System Setup 3. Press the module down and use the two screws to fix the module. 3.4 Installing Antennas 1. Remove the antenna hole covers at front panel. 2. Have antenna jack penetrate through the hole.
  • Page 69 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 3: System Setup 3. Put on the washer and fasten the nut with antenna jack. 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at the another end of the cable onto the module.

  • Page 70: Installing A So-Dimm

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 3: System Setup 3.5 Installing a SO-DIMM 1. Locate SO-DIMM socket. 2. Tilt the SODIMM module at a 45 degree angle and insert it to SODIMM socket until the gold-pated connector of module contacted firmly with the socket. 45°...

  • Page 71: Installing The Top Cover

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 3: System Setup 3.6 Installing the Top Cover 1. Put on the cover. 2. Fasten the 8 screws to fix the cover.

  • Page 72: Installing A Sata Hard Drive

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 3: System Setup 3.7 Installing a SATA Hard Drive 1. Locate the removable HDD bay and loosen the 2 screws. 2. Pull out the HDD bracket. 3. Make the PCB side of the HDD face up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to assemble HDD and HDD bracket together.

  • Page 73: Installing A Sim Card

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 3: System Setup 4. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket until the connector of HDD contact the SATA connector firmly. 3.8 Installing a SIM Card 1.

  • Page 74: Installing A Cfast Card

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 3: System Setup 3.9 Installing a CFast Card 1. Locate the CFast card slot. 2. Remove the mounting cover by unscrewing the two screws. 3. Insert the CFast card.

  • Page 75: Connecting With Cv Display Module

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 3: System Setup 3.10 Connecting with CV Display Module 1. Locate the module connector slot. 2. Turn over the unit to have the bottom side face up, loosen the 2 screws of the module connector bracket.
  • Page 76 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 3: System Setup 3. Connect the modules. 4. Fasten the 6 screws onto the display module through the holes of the PC module.

  • Page 77: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 78: Bios Introduction

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.1 BIOS Introduction The BIOS (Basic Input/Output System) is a program located on a Flash Memory on the motherboard. When you start the computer, the BIOS program will gain control. The BIOS first operates an auto-diagnostic test called POST (power on self test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization.

  • Page 79: Main Setup

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu.

  • Page 80: Advanced Setup

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.3 Advanced Setup 4.3.1 ACPI Settings Enable or disable ACPI Auto Configuration. 80 80...

  • Page 81: Super Io Configuration

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.3.2 Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. ■ Serial Port 1 Configuration ...
  • Page 82 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup ■ Serial Port 2 Configuration  Please see Serial Port 1 Configuration ■ Serial Port 3 Configuration  Please see Serial Port 1 Configuration  Serial port 3 configuration does not have Onboard Serial Port Mode, described in the previous two configurations.

  • Page 83: Hardware Monitor

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.3.3 Hardware Monitor These items display the current status of all monitored hardware devices/components such as voltages and temperatures. 4.3.4 Serial Port Console Redirection  Console Redirection This item allows users to enable or disable console redirection. 83 83...

  • Page 84: Cpu Configuration

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.3.5 CPU Configuration ■ Socket 0 CPU Information This section provides information on your CPU, frequency, and cache memory. ■ Active Processor Cores Change the active processor cores. Select <All> or <1> mode. ■...

  • Page 85: Thermal Configuration

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.3.6 Thermal Configuration ■ Critical Trip Point Allows user to set the CPU temperature threshold. If the CPU temperature reaches this value, the operating system will shut down the system. This item is configurable only when DTS is enabled.

  • Page 86: Sata Configuration

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.3.7 SATA Configuration ■ Serial-ATA (SATA) This item will allow users to enable or disable Serial ATA. ■ SATA Mode This item will allow users to select IDE or AHCI Mode. ■...

  • Page 87: Os Selection

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.3.8 OS Selection This allows you to configure Windows OS version to install. The purpose of this is to enable USB 3.0 controller interface. If you set Windows 7 and install the OS, you will need to install USB 3.0 driver at the OS level to fully support USB 3.0 interfaces.

  • Page 88: Compatibility Support Module Configuration

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.3.9 Compatibility Support Module Configuration ■ CSM Support Enables or disables UEFI CSM (Compatibility Support Module) to support a legacy PC boot process. ■ Boot option filter Allows user to select which type of operating system to boot. UEFI and Legacy: Allows booting from operating systems that support legacy option ROM or UEFI option ROM.

  • Page 89: Usb Configuration

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.3.10 USB Configuration ■ Legacy USB Support Allows USB keyboard/ mouse to be used in MS-DOS. ■ XHCI Hand-off Determines whether to enable XHCI (USB3.0) Hand-off feature for an operating system without XHCI (USB3.0) Hand-off support.

  • Page 90: Chipset

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.4 Chipset 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics- related configuration options.
  • Page 91 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup ■ Intel IGD Configuration This section provides onboard graphics-related configuration options.  GOP Driver This item will allow users to enable or disable GOP Driver.  Integrated Graphics Device This item will allow users to enable or disable Integrated Graphics Device.

  • Page 92: South Bridge

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.4.2 South Bridge ■ Azalia HD Audio Control detection of the Azalia device.  Audio Controller Enabled: Azalia will be unconditionally enabled. Disabled: Azalia will be unconditionally disabled. ■...
  • Page 93 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup ■ PCI Express Configuration  PCI Express Port 0 This item will allow users to enable or disable PCI Express Port 0.  Speed Change the PCI Express interface speed. Select <AUTO> ,<Gen 2> or <Gen 1> ...

  • Page 94: Security

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.5 Security This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.5.1 Administrator Password Administrator Password controls access to the BIOS Setup utility.

  • Page 95: Boot

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.6 Boot This section allows you to configure the boot settings. 4.6.1 Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. 4.6.2 Bootup NumLock State Select the Power-on state for Numlock.

  • Page 96: Save & Exit

    CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 4: BIOS Setup 4.7 Save & Exit This section allows you to configure the boot settings. 4.7.1 Save Changes and Reset This item allows user to reset system setup after saving changes. 4.7.2 Discard Changes and Reset This item allows user to reset system setup without saving any changes.

  • Page 97: Chapter 5 Product Application

    Chapter 5 Product Application...

  • Page 98: Digital I/O (Dio) Application

    This section describes DIO application of the product. The content and application development are better understood and implemented by well experienced professionals or developers. 5.1.1 Digital I/O Programming Guide 5.1.1.1 Pins for Digital I/O for Cincoze P1001 series product Item Standard GPIO74 (Pin107)
  • Page 99 P1001 / P1001E | User’s Manual Convertible Computer Modules Chapter 5: Product application 5.1.1.3 Relative Registers To program the F81866A configuration registers, see the following configuration procedures.
  • Page 100 P1001 / P1001E | User’s Manual Convertible Computer Modules Chapter 5: Product application 5.1.1.4 Sample Code in C Language 5.1.1.4.1 Control of GP74 to GP77 (DI1 ~ DI4) #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device>...
  • Page 101 P1001 / P1001E | User’s Manual Convertible Computer Modules Chapter 5: Product application 5.1.1.4.2 Control of GP80 to GP83 (DO1 ~ DO4) #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device>...
  • Page 102 // Select configuration register 61h (Low Byte address) WriteByte(DataPort, ( 0x00)) <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Note: Cincoze DIO Port base address is 0x0A00h. 5.1.1.6 DATA Bit Table (DI/O) 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0...

  • Page 103: Digital I/O (Dio) Hardware Specification

    P1001 / P1001E | User’s Manual Convertible Computer Modules Chapter 5: Product application 5.1.1.7 DIO I/O Port Address Pin Definition Data Bits 0xA03 0xA02 I/O Port address 5.2 Digital I/O (DIO) Hardware Specification • 4x Digital Input (Source Type) • Input Voltage (Dry Contact) - Logic 0: Close to GND - Logic 1: Open •...
  • Page 104 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors DIO1: Digital Input / Output Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition DC INPUT...
  • Page 105 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: Jumpers and Connectors...
  • Page 106 Appendix Panel Mount Procedures...

  • Page 107: Appendix Panel Mount Procedures

    | User’s Manual Industrial Panel PC Chapter 2: System Setup A.1 Mounting Solution Guide For Panel Mount 1. Accessories provided by Cincoze are as follows. Mounting Kits Panel Mount PPC Before assembly, please prepare panel mount PPC and customer’s fixture.
  • Page 108 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: System Setup 2. All mounting kits displayed are to be inserted into holes. 3. Installation preparation and steps. LVDS connector Panel mount side view with LVDS connector Before Mounting Kits are installed of CV series...
  • Page 109 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: System Setup STEP 1 Position panel mount kits STEP 2 Insert the panel mounting kit into bottom hole STEP 3 Slide the kit toward back...
  • Page 110 CV-100/P1000 Series | User’s Manual Industrial Panel PC Chapter 2: System Setup STEP 4 Tighten the screw forward until the front screw just touches the surface 4. Apply all mount kits to the rest of holes. And you have completed the panel mount installation, as shown below.
  • Page 111 © 2014 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.
