CV-100/P1001 Series
User Manual
Version: V2.08
Industrial Panel PC
Power Efficient Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CV-100/P1001 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cincoze CV-100/P1001 Series

Summary of Contents for Cincoze CV-100/P1001 Series

  • Page 1 CV-100/P1001 Series User Manual Industrial Panel PC Power Efficient Series Version: V2.08...

  • Page 2: Table Of Contents

    Contents Preface ..............................5 Revision ............................5 Acknowledgement ......................... 5 Disclaimer ............................6 Declaration of Conformity ......................6 Product Warranty Statement ......................6 Technical Support and Assistance ....................7 Conventions Used in this Manual ....................8 Safety Precautions .......................... 8 Package Contents .........................
  • Page 3 2.4 Definition of Jumpers ......................76 2.5 Definition of Switches ......................76 2.6 Definition of Connectors ......................77 Chapter 3 System Setup ........................83 3.1 Removing the Top Cover ......................84 3.2 Installing a Half Size Mini PCIe Card ..................85 3.3 Installing a Full Size Mini PCIe Card ..................
  • Page 4 5.2 Digital I/O (DIO) Hardware Specification ................127 P1001 Series | User Manual CV-100/...

  • Page 5: Preface

    Correction made 2023/04/14 © 2018 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.

  • Page 6: Disclaimer

    This manual is intended to be used as a practical and informative guide only and is subject to change without notice. It does not represent a commitment on the part of Cincoze. This product might include unintentional technical or typographical errors. Changes are periodically made to the information herein to correct such errors, and these changes are incorporated into new editions of the publication.

  • Page 7: Technical Support And Assistance

    Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain an RMA number from us. Our staff is available at any time to provide you with the most friendly and immediate service. ◼...

  • Page 8: Conventions Used In This Manual

    about the product. 2. Contact your distributor or our technical support team or sales representative for technical support if you need additional assistance. Please have following information ready before you call: ⚫ Product name and serial number ⚫ Description of your peripheral attachments ⚫...
  • Page 9 to the power outlet. Use a power cord that has been approved for using with the product and that it matches the voltage and current marked on the product’s electrical range label. The voltage and current rating of the cord must be greater than the voltage and current rating marked on the product.

  • Page 10: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty Panel PC Panel Mounting Kit (The quantity varies with the size of the display module, please refer to the datasheet for the actual quantity) DIO Terminal Block Connector Power Terminal Block Connector...
  • Page 11 10.4" TFT XGA 4:3 Panel PC with Resistive 5-wire Touch, CV-110HR/P1001 w/ Intel Atom E3845 Quad Core, 4x USB, 2x COM, 1x VGA and 1x DisplayPort and 2x Universal bracket 12.1" TFT XGA 4:3 Panel PC with Resistive 5-wire Touch, CV-112HR/P1001 w/ Intel Atom E3845 Quad Core, 4x USB, 2x COM, 1x VGA and 1x DisplayPort...
  • Page 12 21.5" TFT Full HD 16:9 Panel PC with Resistive 5-wire CV-W121R/P1001E Touch and Intel Atom E3845 Quad Core, 4x USB, 2x COM, 1x VGA, 1x DisplayPort, 2x Universal bracket 24" TFT Full HD 16:9 Panel PC with Resistive 5-wire CV-W124R/P1001 Touch and Intel®...
  • Page 13 12.1" TFT XGA 4:3 Panel PC with Projected Capacitive Touch, w/ Intel Atom E3845 Quad Core, 4x USB, 2x CV-112HC/P1001E COM, 1x VGA and 1x DisplayPort and 2x Universal bracket 15" TFT XGA 4:3 Panel PC with Projected Capacitive CV-115C/P1001 Touch, w/ Intel Atom E3845 Quad Core, 4x USB, 2x COM, 1x VGA and 1x DisplayPort 15"...
  • Page 14 bracket 24" TFT Full HD 16:9 Panel PC with Projected Capacitive CV-W124C/P1001 Touch and Intel® Atom™ E3845 Quad Core PC Module, 4x USB, 2x COM, 1x VGA, 1x DisplayPort 24" TFT Full HD 16:9 Panel PC with Projected Capacitive Touch and Intel® Atom™ E3845 Quad Core PC Module, CV-W124C/P1001E 4x USB, 2x COM, 1x VGA, 1x DisplayPort, 2x Universal Brackets...

  • Page 15: Chapter 1 Product Introductions

    Chapter 1 Product Introductions P1001 Series | User Manual CV-100/...

  • Page 16: Overview

    1.1 Overview The CV-100/P1000 Series all-in-one panel PC offers LED backlight LCD. It features flat surface and IP65 dust/waterproof front panel. In addition, designed with aluminum die-cast front frame with rugged body structure that can be able to apply in industrial applications. The CV-100/P1000 Series supports Convertible Display System (CDS) technology which makes it more flexible in system maintaining and upgrading.

  • Page 17: Hardware Specification

    1.3 Hardware Specification 1.3.1 CV-108/P1001 Series The table on this page refers to the specifications of CV-108 alone Model Name CV-108R CV-108C Display • 8.4" (4:3) LCD Size • 800 x 600 Max. Resolution • 400 Brightness( cd/m2) • 600 : 1 Contract Ratio •...
  • Page 18 Model Name P1001 P1001E System Processor • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Memory • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) • Support up to 8 GB BIOS • AMI 64Mbit SPI BIOS Graphics •...
  • Page 19 Physical • 204.5 X 149 X 37.5 mm • 204.5 x 150 x 60 mm Dimension( W x D x H ) • 1.34kg • 1.54kg Weight Information • Extruded Aluminum with Heavy Duty Metal Mechanical Construction • Wall / VESA / CDS Mounting Mounting Reliability &...
  • Page 20 Dimension CV-108/P1001 Unit: mm P1001 Series | User Manual CV-100/...
  • Page 21 CV-108/P1001E Unit: mm P1001 Series | User Manual CV-100/...

  • Page 22: Cv-110/P1001 Series

    1.3.2 CV-110/P1001 Series The table on this page refers to the specifications of CV-110 alone Model Name CV-110R CV-110C Display • 10.4" (4:3) LCD Size • 800 x 600 Max. Resolution • 400 Brightness( cd/m2) • 700 : 1 Contract Ratio •...
  • Page 23 Model Name P1001 P1001E System Processor • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Memory • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) • Support up to 8 GB BIOS • AMI 64Mbit SPI BIOS Graphics •...
  • Page 24 Physical • 204.5 X 149 X 37.5 mm • 204.5 x 150 x 60 mm Dimension( W x D x H ) • 1.34kg • 1.54kg Weight Information • Extruded Aluminum with Heavy Duty Metal Mechanical Construction • Wall / VESA / CDS Mounting Mounting Reliability &...
  • Page 25 Dimension CV-110/P1001 Unit: mm P1001 Series | User Manual CV-100/...
  • Page 26 CV-110/P1001E Unit: mm P1001 Series | User Manual CV-100/...

  • Page 27: Cv-110H/P1001 Series

    1.3.3 CV-110H/P1001 Series The table on this page refers to the specifications of CV-110H alone Model Name CV-110HR CV-110HC Display • 10.4" (4:3) LCD Size • Max. Resolution 1024 x 768 • 400 Brightness( cd/m2) • Contract Ratio 1400 : 1 •...
  • Page 28 Model Name P1001 P1001E System Processor • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Memory • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) • Support up to 8 GB BIOS • AMI 64Mbit SPI BIOS Graphics •...
  • Page 29 • 1x Optional AC/DC 12V/5A, 60W Power Adapter Power Adapter (Optional) Physical • 204.5 X 149 X 37.5 mm • 204.5 x 150 x 60 mm Dimension( W x D x H ) • 1.34kg • 1.54kg Weight Information • Extruded Aluminum with Heavy Duty Metal Mechanical Construction •...
  • Page 30 Dimension CV-110H/P1001 Unit: mm P1001 Series | User Manual CV-100/...
  • Page 31 CV-110H/P1001E Unit: mm P1001 Series | User Manual CV-100/...

  • Page 32: Cv-112H/P1001 Series

    1.3.4 CV-112H/P1001 Series The table on this page refers to the specifications of CV-112H alone Model Name CV-112HR CV-112HC Display • 12.1" (4:3) LCD Size • Max. Resolution 1024 x 768 • 500 Brightness( cd/m2) • Contract Ratio 700 : 1 •...
  • Page 33 Model Name P1001 P1001E System Processor • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Memory • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) • Support up to 8 GB BIOS • AMI 64Mbit SPI BIOS Graphics •...
  • Page 34 Physical • 204.5 X 149 X 37.5 mm • 204.5 x 150 x 60 mm Dimension( W x D x H ) • 1.34kg • 1.54kg Weight Information • Extruded Aluminum with Heavy Duty Metal Mechanical Construction • Wall / VESA / CDS Mounting Mounting Reliability &...
  • Page 35 Dimension CV-112H/P1001 Unit: mm P1001 Series | User Manual CV-100/...
  • Page 36 CV-112H/P1001E Unit: mm P1001 Series | User Manual CV-100/...

  • Page 37: Cv-115/P1001 Series

    1.3.5 CV-115/P1001 Series The table on this page refers to the specifications of CV-115 alone Model Name CV-115R CV-115C Display • 15" (4:3) LCD Size • Max. Resolution 1024 x 768 • 350 Brightness( cd/m2) • Contract Ratio 800 : 1 •...
  • Page 38 Model Name P1001 P1001E System Processor • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Memory • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) • Support up to 8 GB BIOS • AMI 64Mbit SPI BIOS Graphics •...
  • Page 39 Physical • 204.5 X 149 X 37.5 mm • 204.5 x 150 x 60 mm Dimension( W x D x H ) • 1.34kg • 1.54kg Weight Information • Extruded Aluminum with Heavy Duty Metal Mechanical Construction • Wall / VESA / CDS Mounting Mounting Reliability &...
  • Page 40 Dimension CV-115/P1001 Unit: mm P1001 Series | User Manual CV-100/...
  • Page 41 CV-115/P1001E Unit: mm P1001 Series | User Manual CV-100/...

  • Page 42: Cv-W115/P1001 Series

    1.3.6 CV-W115/P1001 Series The table on this page refers to the specifications of CV-W115 alone Model Name CV-W115R CV-W115C Display • 15.6" (16:9) LCD Size • Max. Resolution 1366 x 768(WXGA) • 400 Brightness( cd/m2) • Contract Ratio 500 : 1 •...
  • Page 43 Model Name P1001 P1001E System Processor • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Memory • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) • Support up to 8 GB BIOS • AMI 64Mbit SPI BIOS Graphics •...
  • Page 44 Physical • 204.5 X 149 X 37.5 mm • 204.5 x 150 x 60 mm Dimension( W x D x H ) • 1.34kg • 1.54kg Weight Information • Extruded Aluminum with Heavy Duty Metal Mechanical Construction • Wall / VESA / CDS Mounting Mounting Reliability &...
  • Page 45 Dimension CV-W115/P1001 Unit: mm P1001 Series | User Manual CV-100/...
  • Page 46 CV-W115/P1001E Unit: mm P1001 Series | User Manual CV-100/...

  • Page 47: Cv-117/P1001 Series

    1.3.7 CV-117/P1001 Series The table on this page refers to the specifications of CV-117 alone Model Name CV-117R CV-117C CV-117G Display • 17" (5:4) LCD Size • Max. Resolution 1280 x 1024 • 350 Brightness( cd/m2) • Contract Ratio 800 : 1 •...
  • Page 48 Model Name P1001 P1001E System Processor • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Memory • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) • Support up to 8 GB BIOS • AMI 64Mbit SPI BIOS Graphics •...
  • Page 49 Physical • 204.5 X 149 X 37.5 mm • 204.5 x 150 x 60 mm Dimension( W x D x H ) • 1.34kg • 1.54kg Weight Information • Extruded Aluminum with Heavy Duty Metal Mechanical Construction • Wall / VESA / CDS Mounting Mounting Reliability &...
  • Page 50 Dimension CV-117/P1001 Unit: mm P1001 Series | User Manual CV-100/...
  • Page 51 CV-117/P1001E Unit: mm P1001 Series | User Manual CV-100/...

  • Page 52: Cv-119/P1001 Series

    1.3.8 CV-119/P1001 Series The table on this page refers to the specifications of CV-119 alone Model Name CV-119R CV-119C CV-119G Display • 19" (5:4) LCD Size • Max. Resolution 1280 x 1024 • 350 Brightness( cd/m2) • Contract Ratio 1000 : 1 •...
  • Page 53 Model Name P1001 P1001E System Processor • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Memory • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) • Support up to 8 GB BIOS • AMI 64Mbit SPI BIOS Graphics •...
  • Page 54 Physical • 204.5 X 149 X 37.5 mm • 204.5 x 150 x 60 mm Dimension( W x D x H ) • 1.34kg • 1.54kg Weight Information • Extruded Aluminum with Heavy Duty Metal Mechanical Construction • Wall / VESA / CDS Mounting Mounting Reliability &...
  • Page 55 Dimension CV-119/P1001 Unit: mm P1001 Series | User Manual CV-100/...
  • Page 56 CV-119/P1001E Unit: mm P1001 Series | User Manual CV-100/...

  • Page 57: Cv-W121/P1001 Series

    1.3.9 CV-W121/P1001 Series The table on this page refers to the specifications of CV-W121 alone Model Name CV-W121R CV-W121C CV-W121G Display • 21.5" (16:9) LCD Size • Max. Resolution 1920 x 1080 • 350 Brightness( cd/m2) • Contract Ratio 5000 : 1 •...
  • Page 58 Model Name P1001 P1001E System Processor • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Memory • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) • Support up to 8 GB BIOS • AMI 64Mbit SPI BIOS Graphics •...
  • Page 59 Physical • 204.5 X 149 X 37.5 mm • 204.5 x 150 x 60 mm Dimension( W x D x H ) • 1.34kg • 1.54kg Weight Information • Extruded Aluminum with Heavy Duty Metal Mechanical Construction • Wall / VESA / CDS Mounting Mounting Reliability &...
  • Page 60 Dimension CV-W121/P1001 Unit: mm P1001 Series | User Manual CV-100/...
  • Page 61 CV-W121/P1001E Unit: mm P1001 Series | User Manual CV-100/...

  • Page 62: Cv-W124/P1001 Series

    1.3.10 CV-W124/P1001 Series The table on this page refers to the specifications of CV-W124 alone Model Name CV-W124R CV-W124C CV-W124G Display • 24" (16:9) LCD Size • Max. Resolution 1920 x 1080 • 350 Brightness( cd/m2) • Contract Ratio 5000 : 1 •...
  • Page 63 Model Name P1001 P1001E System Processor • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Memory • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) • Support up to 8 GB BIOS • AMI 64Mbit SPI BIOS Graphics •...
  • Page 64 Physical • 204.5 X 149 X 37.5 mm • 204.5 x 150 x 60 mm Dimension( W x D x H ) • 1.34kg • 1.54kg Weight Information • Extruded Aluminum with Heavy Duty Metal Mechanical Construction • Wall / VESA / CDS Mounting Mounting Reliability &...
  • Page 65 Dimension CV-W124/P1001 Unit: mm P1001 Series | User Manual CV-100/...
  • Page 66 CV-W124/P1001E Unit: mm P1001 Series | User Manual CV-100/...

  • Page 67: System I/O

    1.4 System I/O 1.4.1 Front ATX Power On/Off CFast and SIM card Slot Used to power-on or power-off the system Used to insert a CFast card and SIM card Antenna Hole Removable HDD Bay Used to connect an antenna for optional wireless Used to insert a 2.5”...

  • Page 68: Rear

    1.4.2 Rear DC IN USB 2.0 port Used to plug a DC power input with terminal Used to connect USB 2.0/1.1 device LAN port block Reset Button Used to connect the system to a local area Used to reset the system network Mic-in Used to connect a microphone...

  • Page 69: Side (Left)

    1.4.3 Side (Left) USB 3.2 GEN1 port Digital I/O Terminal Block Used to connect USB 3.2 GEN1/2.0/1.1 device The Digital I/O terminal block supports 4 digital USB 2.0 port input and 4 digital output AT/ATX mode select switch Used to connect USB 2.0/1.1 device Used to select AT or ATX power mode P1001 Series | User Manual CV-100/...

  • Page 70: Side (Right)

    1.4.4 Side (Right) COM port OSD Function: COM 2 supports RS232/422/485 serial device LCD On/Off DisplayPort Press to turn-on or turn-off the display Used to connect a DisplayPort devices Increase Brightness Power LED Press to increase brightness of the screen Indicates the power status of the system Decrease Brightness HDD LED...

  • Page 71: Top

    1.4.5 Top VESA Mounting Hole These are mounting holes for VESA mount (75x75mm and 100x100mm) P1001 Series | User Manual CV-100/...

  • Page 72: Chapter 2 Jumpers, Switches & Connectors

    Chapter 2 Jumpers, Switches & Connectors P1001 Series | User Manual CV-100/...

  • Page 73: Jumpers Settings

    2.1 Jumpers Settings When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open. Refer to below for examples of the 2-pin and 3-pin jumpers when they are short (on) and open (off).

  • Page 74: Bottom View

    2.2.2 Bottom View P1001 Series | User Manual CV-100/...

  • Page 75: Definition Of Jumpers/Switches/Connectors

    2.3 Definition of Jumpers/Switches/Connectors List of Jumpers/Switches/Connectors Location Definition AT_ATX1 AT / ATX Power Mode Switch BL_PWR1 Backlight Power on / off switching BL_UP1 Backlight Increase BL_DN1 Backlight Decrease CFAST1 CFast Connector CLR_CMOS1 Clear BIOS Switch COM1_1, COM2_1 RS232 / RS422 / RS485 Connector COM12_SEL1 COM1 / COM2 with Power Select DC_IN1...

  • Page 76: Definition Of Jumpers

    2.4 Definition of Jumpers COM12_SEL1: COM1 / COM2 with Power Select Connector Type: 2X5 10-pin Header, 2.0mm pitch COM1 COM2 Definition Definition 1-3 On 2-4 On 3-5 On +12V 4-6 On +12V 7-9 On 8-10 On Reserved Reserved (Default) (Default) 2.5 Definition of Switches AT_ATX1: AT / ATX Power Mode Switch Definition...

  • Page 77: Definition Of Connectors

    RESET1: Reset Switch Switch Definition Push Reset System 2.6 Definition of Connectors CFAST1: CFast Connector Definition Definition Definition PC10 SATA_TX2+ PC11 SATA_TX2- PC12 PC13 +3.3V SATA_RX2- PC14 +3.3V SATA_RX2+ PC15 PC16 PC17 COM1~COM2: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 RS485 RS232...
  • Page 78 DC_IN1: DC Power Input Connector (+9~48V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition +9~48VIN Chassis GND Please disconnect the power source before mounting the DC power cables or connecting the DC power connector to system. DP1: DisplayPort Connector Definition Definition DP_LANE0_P...
  • Page 79 LED1: Power / HDD Access LED Status Definition HDD LED+ HDD LED- POWER LED+ POWER LED- LED Status LED Color Yellow POWER Green LINE_OUT1: Line-out Jack (Green) Connector Type: 5-pin Phone Jack Definition OUT_R OUT_L MIC1: Microphone Jack (Pink) Connector Type: 5-pin Phone Jack Definition MIC_R MIC_L...
  • Page 80 POWER1: Power Connector Connector Type: 1X4-pin Wafer, 2.0mm pitch Definition +12V SATA1: SATA with Power Connector Definition Definition SATA_TX1+ SATA_TX1- SATA_RX1- SATA_RX1+ +3.3V +3.3V +12V +3.3V +12V +12V SIM1：SIM Card Socket Definition UIM_PWR UIM_RESET UIM_CLK UIM_VPP UIM_DATA P1001 Series | User Manual CV-100/...
  • Page 81 SPK_L1: Left Internal Speaker Connector Definition OUT_L SPK_R1: Right Internal Speaker Connector Definition OUT_R USB1_2_1：USB2.0 Connector, Type A Definition Definition USB_DATA0- USB_DATA_1- USB_DATA0+ USB_DATA_1+ USB2_1: USB2.0 Connector, Type A Definition USB2_DATA1- USB2_DATA1+ USB3_1: USB 3.0 Connector, Type A Definition Definition USB3_RX0+ USB2_D0- USB2_D0+...
  • Page 82 MINIPCIE1: Mini PCI-Express Socket Pin Definition Pin Definition Pin Definition WAKE# +3.3V +3.3V USB2_3P +3.3V MINIPCIE RST# MINIPCIE_RXN +3.3V +1.5V +3.3V CLKREQ# MINIPCIE_RXP UIM_PWR UIM_DATA +1.5V MINIPCIE_CLKN 29 UIM_CLK SMB_CLK +1.5V MINIPCIE_CLKP 31 MINIPCIE_TXN UIM_RESET SMB_DATA MINIPCIE_TXP UIM_VPP +3.3V USB2_3N P1001 Series | User Manual CV-100/...

  • Page 83: Chapter 3 System Setup

    Chapter 3 System Setup P1001 Series | User Manual CV-100/...

  • Page 84: Removing The Top Cover

    This chapter takes P1001 as an example to demonstrate the installation of hardware components. 3.1 Removing the Top Cover Loosen the 8 screws of front and rear panel, then place them aside. Remove the cover from the chassis. Place the top cover gently. P1001 Series | User Manual CV-100/...

  • Page 85: Installing A Half Size Mini Pcie Card

    3.2 Installing a Half Size Mini PCIe Card Locate the Mini PCIe slot. Use provided two screws on bracket to fasten the module and bracket together. Tilt the Mini PCIe module at 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot.

  • Page 86: Installing A Full Size Mini Pcie Card

    Press down the module and use the two screws to fix the module. 3.3 Installing a Full Size Mini PCIe Card 1. Locate the Mini PCIe slot. 2. Tilt the Mini PCIe module at 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot.

  • Page 87: Installing Antennas

    3. Press down the module and use the two screws to fix the module. 3.4 Installing Antennas Remove the antenna hole covers at front panel. Have antenna jack penetrate through the hole. P1001 Series | User Manual CV-100/...
  • Page 88 Put on washer and fasten the nut with antenna jack. Assemble the antenna and antenna jack together. Attach the RF connector at another end of cable onto the module. P1001 Series | User Manual CV-100/...

  • Page 89: Installing A So-Dimm

    3.5 Installing a SO-DIMM 1. Locate SO-DIMM socket. 2. Tilt the SODIMM module at a 45-degree angle and insert it to SODIMM socket until the gold-pated connector of module contacted firmly with the socket. 3. Press the module down until its fixed firmly by the two locking latches on each side. P1001 Series | User Manual CV-100/...

  • Page 90: Installing The Top Cover

    3.6 Installing the Top Cover 1. Put on the cover. 2. Fasten the 8 screws to fix the cover. P1001 Series | User Manual CV-100/...

  • Page 91: Installing A Sata Hard Drive

    3.7 Installing a SATA Hard Drive 1. Locate the removable HDD bay and loosen the 3 screws. 2. Pull out the HDD bracket. 3. Make the PCB side of the HDD face up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to assemble HDD and HDD bracket together.

  • Page 92: Installing A Sim Card

    4. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket until the connector of HDD contact the SATA connector firmly. 3.8 Installing a SIM Card 1. SIM card slot is at the front panel of the system. 2.

  • Page 93: Installing A Cfast Card

    3.9 Installing a CFast Card 1. Locate the CFast card slot. 2. Remove the mounting cover by unscrewing the two screws. 3. Insert the CFast card until it clicks. P1001 Series | User Manual CV-100/...

  • Page 94: Connecting With Cs Display Module

    3.10 Connecting with CS Display Module 1. Locate the module connector slot and loosen the 1 screw. 2. Turn over the unit to have the bottom side face up, loosen the 2 screws of the module connector bracket. The photos show the male connector (on display module) and female connector (on PC module) P1001 Series | User Manual CV-100/...
  • Page 95 3. Connect the modules. 4. Fasten the 6 screws to fix the PC module on the display module. P1001 Series | User Manual CV-100/...

  • Page 96: Vesa Mount Bracket

    3.11 VESA Mount Bracket The following picture indicates VESA mounting hole pattern on P1000, which is compliant with VESA mounting standard. 1. The following picture uses a panel PC (P1000+CV display module) as a demonstration. To attach the panel PC to a VESA stand, please fasten eight screws as indicated to fix it on the stand.

  • Page 97: Installing Panel Mount

    3.12 Installing Panel Mount 1. Accessories provided by Cincoze are as follows. (Please note that the quantity of mounting kits varies with the size of the display module, please refer to the datasheet for the actual quantity) P1001 Series | User Manual...
  • Page 98 2. All mounting kits displayed are to be inserted into holes. 3. Installation preparation and steps. P1001 Series | User Manual CV-100/...
  • Page 99 P1001 Series | User Manual CV-100/...
  • Page 100 4. Apply all mount kits to the rest of holes. And you have completed the panel mount installation, as shown below. P1001 Series | User Manual CV-100/...

  • Page 101: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup P1001 Series | User Manual CV-100/...

  • Page 102: Bios Introduction

    4.1 BIOS Introduction The BIOS (Basic Input/ Output System) is a program located on a Flash Memory on the motherboard. When you start the computer, the BIOS program will gain control. The BIOS first operates an auto-diagnostic test called POST (power on self-test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization.

  • Page 103: Main Setup

    4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. 4.2.1 System Date Set the date.

  • Page 104: Advanced Setup

    4.3 Advanced Setup 4.3.1 ACPI Settings Enable or disable ACPI Auto Configuration. P1001 Series | User Manual CV-100/...

  • Page 105: Super Io Configuration

    4.3.2 Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. ■ Serial Port 1 Configuration ❑ Serial Port This item will allow users to enable or disable serial port. ❑...

  • Page 106: Hardware Monitor

    ■ Watch Dog Function You can setup the system watch-dog timer, a hardware timer that generates a reset when the software that it monitors does not respond as expected each time the watch dog polls it. ❑ Watch Dog Mode Change the Watch dog mode.

  • Page 107: Serial Port Console Redirection

    4.3.4 Serial Port Console Redirection ■ Console Redirection This item allows users to enable or disable console redirection. 4.3.5 CPU Configuration ■ Socket 0 CPU Information This section provides information on your CPU, frequency, and cache memory. ■ Active Processor Cores Change the active processor cores.

  • Page 108: Thermal Configuration

    This option is only useful if you are using an operating system that does not recognize all of the features of your processor. Allows user to determine whether to limit CPUID maximum value. Set this item to Disabled: For Windows XP operating system. Enabled: For legacy operating system such as Windows NT4.0.

  • Page 109: Sata Configuration

    ■ Passive Trip Point Allows user to set the CPU temperature threshold. If the CPU temperature reaches this value, the CPU frequency will be automatically reduced. This item is configurable only when DTS is enabled. ■ DTS Enables or disables the CPU overheating protection function. (Default: Disabled) 4.3.7 SATA Configuration ■...

  • Page 110: Os Selection

    4.3.8 OS Selection This allows you to configure Windows OS version to install. The purpose of this is to enable USB 3.0 controller interface. If you set Windows 7 and install the OS, you will need to install USB 3.0 driver at the OS level to fully support USB 3.0 interfaces. If you set Windows 8.x and install it or later OS, the Windows OS will easily support USB 3.0 interfaces.

  • Page 111: Usb Configuration

    ■ CSM Support Enables or disables UEFI CSM (Compatibility Support Module) to support a legacy PC boot process. ■ Boot option filter Allows user to select which type of operating system to boot. UEFI and Legacy: Allows booting from operating systems that support legacy option ROM or UEFI option ROM.
  • Page 112 ■ Legacy USB Support Allows USB keyboard/ mouse to be used in MS-DOS. ■ XHCI Hand-off Determines whether to enable XHCI (USB3.0) Hand-off feature for an operating system without XHCI (USB3.0) Hand-off support. ■ EHCI Hand-off Determines whether to enable EHCI Hand-off feature for an operating system without EHCI Hand-off support.

  • Page 113: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics-related configuration options. ■ Intel IGD Configuration This section provides onboard graphics-related configuration options. P1001 Series | User Manual CV-100/...
  • Page 114 ❑ GOP Driver This item will allow users to enable or disable GOP Driver. ❑ Integrated Graphics Device This item will allow users to enable or disable Integrated Graphics Device. ❑ IGD Turbo Enable This item will allow users to enable or disable IGD Turbo. ❑...

  • Page 115: South Bridge

    4.4.2 South Bridge ■ Azalia HD Audio Control detection of the Azalia device. ❑ Audio Controller Enabled: Azalia will be unconditionally enabled. Disabled: Azalia will be unconditionally disabled. ■ USB Configuration ❑ XHCI Mode This setting disables/enables the USB XHCI controller. The eXtensible Host Controller Interface (XHCI) is a computer interface specification that defines a register-level description of a Host Controller for Universal Serial Bus (USB), which is capable of interfacing to USB 1.0, 2.0, and 3.0 compatible devices.
  • Page 116 ❑ USB Port 3 This item will allow users to enable or disable USB Port 3. ■ Wake On LAN Enable This item enables or disables Wake On LAN (WOL) function. ■ PCI Express Configuration ❑ PCI Express Port 0 This item will allow users to enable or disable PCI Express Port 0.

  • Page 117: Security Setup

    This setting specifies whether your system will reboot after a power failure or interrupt occurs. Available settings are: Power Off: Leave the computer in the power off state. Power On: Leave the computer in the power on state. Last State: Restore the system to the previous status before power failure or interrupt occurred.

  • Page 118: Boot Setup

    4.6 Boot Setup This section allows you to configure Boot settings. 4.6.1 Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. 4.6.2 Bootup NumLock State Allows users to select the power-on state for keyboard NumLock. 4.6.3 Full Screen Logo Show This item allows user to enable or disable full screen logo show.

  • Page 119: Save & Exit

    4.7 Save & Exit 4.7.1 Save Changes and Reset This item allows user to reset system setup after saving changes. 4.7.2 Discard Changes and Reset This item allows users to reset system setup without saving any changes. 4.7.3 Restore Defaults This item allows user to restore/ load default values for all the options.

  • Page 120: Chapter 5 Product Application

    Chapter 5 Product Application P1001 Series | User Manual CV-100/...

  • Page 121: Digital I/O (Dio) Application

    This section describes DIO application of the product. The content and application development are better understood and implemented by well experienced professionals or developers. 5.1.1 Digital I/O Programming Guide 5.1.1.1 Pins for Digital I/O of Cincoze P1001 series product Item Standard GPIO74 (Pin107)
  • Page 122 -o 4e 87 -o 4e 87 (enable configuration) -o 4e aa (disable configuration) 5.1.1.3 Relative Registers To program the F81866A configuration registers, see the following configuration procedures. P1001 Series | User Manual CV-100/...
  • Page 123 5.1.1.4 Sample Code in C Language 5.1.1.4.1 Control of GP74 to GP77 (DI1 ~ DI4) #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) // Select logic device 06h...
  • Page 124 <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) 5.1.1.4.2 Control of GP80 to GP83 (DO1 ~ DO4) #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(DataPort, 0x06) // Select logic device 06h...
  • Page 125 5.1.1.5 Change base address - DIO base address (Cincoze default 0xA00) <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) // Select logic device 06h...
  • Page 126 5.1.1.6 DATA Bit Table (DIO) 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0 = DI1 = DO1 0 0 0 1 - - - - value - - - - 0 0 0 1 value 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0...
  • Page 127 5.2 Digital I/O (DIO) Hardware Specification XCOM+: Isolated power in V+ ⚫ XCOM-: Isolated power in V- ⚫ Isolated power in DC voltage: 9~30V ⚫ 4x Digital Input (Source Type) ⚫ Input Signal Voltage Level ⚫ Signal Logic 0: XCOM+ = 9V, Signal Low <...
  • Page 128 P1001 Series | User Manual CV-100/...
  • Page 129 © 2020 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.

This manual is also suitable for:

Power efficient seriesCv-108/p1001 seriesCv-110/p1001 seriesCv-110h/p1001 seriesCv-112h/p1001 seriesCv-115/p1001 series ... Show all

Table of Contents
